Baldor M3303T Product Information Sheet

Product Information Packet

M3303T

2HP,865RPM,3PH,60HZ,213T,3732M,OPSB,F1,N

Product Information Packet: M3303T - 2HP,865RPM,3PH,60HZ,213T,3732M,OPSB,F1,N

Part Detail

Revision: G Status: INA/A Change #: Proprietary: No Type: AC Elec. Spec: 37WGS277 CD Diagram: CD0005 Mfg Plant: Mech. Spec: 37B101 Layout: 37LYB101 Poles: 08 Created Date: 01-18-2007 Base: RG Eff. Date: 03-08-2016 Leads: 9#14

Specs

Catalog Number: M3303T Enclosure: ODP Frame: 213T Frame Material: Steel Output @ Frequency: 2.000 HP @ 60 HZ Synchronous Speed @ Frequency: 900 RPM @ 60 HZ Voltage @ Frequency: 460.0 V @ 60 HZ

230.0 V @ 60 HZ

208.0 V @ 60 HZ XP Division: Not Applicable Agency Approvals: CSA

UR Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: RG Bearing Grease Type: Polyrex EM (-20F +300F) Blower: None

Insulation Class: B Inverter Code: Not Inverter KVA Code: H Lifting Lugs: No Lifting Lugs Locked Bearing Indicator: No Locked Bearing Motor Lead Quantity/Wire Size: 9 @ 14 AWG Motor Lead Exit: Ko Box Motor Lead Termination: Flying Leads Motor Type: 3732M Mounting Arrangement: F1 Power Factor: 62 Product Family: General Purpose Pulley End Bearing Type: Ball Pulley Face Code: Standard Pulley Shaft Indicator: Standard Rodent Screen: None Shaft Extension Location: Pulley End

Current @ Voltage: 3.500 A @ 460.0 V

Shaft Ground Indicator: No Shaft Grounding

Page 2 of 10

Product Information Packet: M3303T - 2HP,865RPM,3PH,60HZ,213T,3732M,OPSB,F1,N

7.000 A @ 230.0 V

7.600 A @ 208.0 V Design Code: B Drip Cover: No Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Face Code: Standard Front Shaft Indicator: None Heater Indicator: No Heater

Shaft Rotation: Reversible Shaft Slinger Indicator: No Slinger Speed Code: Single Speed Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: None Vibration Sensor Indicator: No Vibration Sensor Winding Thermal 1: None Winding Thermal 2: None

Page 3 of 10

Product Information Packet: M3303T - 2HP,865RPM,3PH,60HZ,213T,3732M,OPSB,F1,N

Nameplate NP1256L

CAT.NO. M3303T

SPEC. 37B101S277

HP 2

VOLTS 208-230/460

AMP 7.6-7/3.5 RPM 865

FRAME 213T HZ 60 PH 3

SER.F. 1.15 CODE H DES B CLASS B

NEMA-NOM-EFF 85.5 PF 62

RATING 40C AMB-CONT

CC 010A USABLE AT 208V DE 6307 ODE 6206

ENCL OPSB SN

Page 4 of 10

Product Information Packet: M3303T - 2HP,865RPM,3PH,60HZ,213T,3732M,OPSB,F1,N

Parts List

Part Number Description Quantity SA152510 SA 37B101S277 1.000 EA RA141285 RA 37B101S277 1.000 EA HA6361A01 LIFTING LUG FOR 37, 39 & 40 FRAME ZINC 2.000 EA 37CB3006 37 CB CASTING W/1.38 LEAD HOLE @ 6:00 1.000 EA 51XW2520A10 .25-20 X .62, TAPTITE II, HEX WSHR SLTD 2.000 EA 11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA 37EP3200A01SP FR ENDPLATE, FOR ROUTING PURPOSES 1.000 EA HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA HW5100A06 W2420-025 WVY WSHR (WB) 1.000 EA 37EP3204D00 PU ENDPLATE ASSEMBLY FOR ROUTING 1.000 EA HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA XY3118A12 5/16-18 HEX NUT DIRECTIONAL SERRATION 4.000 EA 37CB4516 LIPPED LID FOR 37 FRAME NEC KOBX 1.000 EA 51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA HW2501F21 KEY, 5/16 SQ X 2.375 1.000 EA HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.028 GA 37AD2001A01 BAFFLE PLATE, PLASTIC 0.63" WIDTH 2.000 EA HA3104A39 THRUBOLT-5/16-18 X 12.250 4.000 EA LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
