Product Information Packet
M3218TA
5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
Part Detail
Revision: E Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 36WGT858 CD Diagram: CD0007 Mfg Plant:
Mech. Spec: 36H827 Layout: 36LYH827 Poles: 04 Created Date:
Base: RG Eff. Date: 10-06-2010 Leads: 12#16
Specs
Catalog Number: M3218TA
Enclosure: ODP
Frame: 184T
Output @ Frequency: 5.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
208.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 14.000 A @ 208.0 V
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: J
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 12 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3628M
Mounting Arrangement: F1
Power Factor: 76
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
14.000 A @ 230.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 11
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
14.100 A @ 208.0 V
7.000 A @ 460.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Do Not Use Eve-Not Valiid
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: Automatic Thermal Overload
Winding Thermal 1 Location: KO
Winding Thermal 2: None
Page 3 of 11
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
Nameplate NP1257L
CAT.NO. M3218TA
SPEC. 36H827T858H2
HP 5
VOLTS 208-230/460
AMP 14.1-14/7
RPM 1750
FRAME 184T HZ 60 PH 3
SER.F. 1.15 CODE J DES B CL B
NEMA-NOM-EFF 87.5 PF 76
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 14
DE 6206 ODE 6205
ENCL OPSB SN
Page 4 of 11
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
Parts List
Part Number Description Quantity
SA121029 SA 36H827T858H2 1.000 EA
RA111708 RA 36H827T858H2 1.000 EA
TPBYV34DX THERMAL 3PH 1.25 AUT 120C 1.000 EA
S/P101-000-000 EPACT PROCEDURES-FS PLANT-POLYREX EM, NO 1.000 EA
TP5059 GENERIC THERMAL KIT 1.000 EA
36CB3004A42 36 CB 1.09 @ 6, 1.25 ATO @ 3 1.000 EA
36GS1000SP GASKET-CONDUIT BOX, .06 THICK #SV-330 LE 1.000 EA
51XB1016A08 10-16X 1/2HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HA6015A09 THERMAL RETAINER PLATED 1.000 EA
51XB1214A10 12-14 X 5/8HX WS SL SR TYBX 2.000 EA
36EP3204B00 FR ENDPLATE, ASSEMBLY FOR ROUTING 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA
36EP3205D00 PU ENDPLATE, ASSEMBLY FOR ROUTING 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
XY2520A12 1/4-20 HEX NUT, DIRECTIONAL SERRATIONS 4.000 EA
36CB4516 36 LIPPED CB LID - GALVANNEAL 1.000 EA
37GS1001SP GASKET, CONDUIT BOX LID, .06 THICK LEXID 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501E16 KEY, 1/4 SQ X 1.750 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
10XF0440S02 04-40 X 1/8 TYPE F HEX HD STAINLESS STIC 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
Page 5 of 11
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
Parts List (continued)
Part Number Description Quantity
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.022 GA
36AD2004A01 BAFFLE PLATE,MOD 36-SLTD BAND MTRS DELTA 2.000 EA
HA3101A25 THRUBOLT 1/4-20 X 11.000 OHIO ROD 4.000 EA
LB1118 LABEL,WARNING (ROLL LABEL) 1.000 EA
LB1125C04 STD-E (STOCK CTN LABEL STD-E WITH FLAG) 1.000 EA
LC0007 CONNECTION LABEL 1.000 EA
NP1257L ALUM UL CSA CC THERMAL REV MTG 1.000 EA
36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 11
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
Accessories
Part Number Description Multiplier
36-3403 C FACE KIT A8
36EP1405A09SP D-FLANGE KIT A8
Page 7 of 11
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
AC Induction Motor Performance Data
Record # 20257 - Typical performance - not guaranteed values
Winding: 36WGT858-R001 Type: 3628M Enclosure: OPSB
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 5 Full Load Torque 14.9 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 14.1-14/7 Breakdown Torque 54.7 LB-FT
R.P.M. 1750 Pull-up Torque 30.6 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 36.1 LB-FT
NEMA Design Code B KVA Code J Starting Current 49.9 A
Service Factor (S.F.) 1.15 No-load Current 4.15 A
NEMA Nom. Eff. 87.5 Power Factor 76 LinelineRes.@25ºC 3.03Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 46°C
S.F. Amps Temp. Rise @ S.F. Load 55°C
Locked-rotor Power Factor 56
Rotor inertia 0.26 LB-FT2
Load Characteristics 460 V, 60 Hz, 5 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 34 55 69 76 82 85 80
Efficiency 79 86 87.8 87.7 87 85.7 87.3
Speed 1787 1777 1765 1752 1737 1722 1743
Line amperes 4.32 4.89 5.77 6.98 8.22 9.63 7.72
Page 8 of 11
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
Performance Graph at 460V, 60Hz, 5.0HP Typical performance - Not guaranteed values
Page 9 of 11
Product Information Packet: M3218TA - 5HP,1750RPM,3PH,60HZ,184T,3628M,OPSB,F1
6.50
.50 5.50
4.50 2.75
3.56
2.75
1.1250
1.1245
614-623 = 13.61
624-634 = 14.99
635-646 = 16.49
3.03
6 HOLES
.41
.25 KEY
1.75 LONG
GREASE FITTING
(EA. END)
NAMEPLATE
1.25"
AUTO
THERMAL
3.75 3.75
4.31
8.63
4.50
4.44
8.41
6.90
5.78
4.35
7.87
4.35
LEAD
HOLE
1.09
1 LUG EA. END
DIAGONALLY SPACED
(635-646 STACKS ONLY)
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
36LYH827
B
HOR 182-4T OPSB M W/1.25" ATO IN KO BOX
REV. DESC:
REV:
BY:
REVISED:
MODEL NO.
VERSION:
TDR:
REF:
36LYH827
LOAD INOPC CREATED SWD DRG INTO BUS - PACKAGE 37
ENSTEK0
F
04:34:04 09/19/2019
-
000001120280
04
36LYH827
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
