Product Information Packet
M3155T
2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
Part Detail
Revision: G Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGT478 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 35T680 Layout: 35LYT680 Poles: 02 Created Date: 06-22-2007
Base: RG Eff. Date: 02-03-2010 Leads: 9#18
Specs
Catalog Number: M3155T
Enclosure: ODP
Frame: 145T
Frame Material: Steel
Output @ Frequency: 2.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
208.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: K
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3522M
Mounting Arrangement: F1
Power Factor: 87
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Current @ Voltage: 2.600 A @ 460.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 11
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
5.200 A @ 230.0 V
5.600 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 11
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
Nameplate NP1256L
CAT.NO. M3155T
SPEC. 35T680T478H1
HP 2
VOLTS 208-230/460
AMP 5.6-5.2/2.6
RPM 3450
FRAME 145T HZ 60 PH 3
SER.F. 1.15 CODE K DES B CLASS B
NEMA-NOM-EFF 84 PF 87
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 5.6
DE 6205 ODE 6203
ENCL OPSB SN
Page 4 of 11
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
Parts List
Part Number Description Quantity
SA107727 SA 35T680T478H1 1.000 EA
RA099329 RA 35T680T478H1 1.000 EA
S/P101-000-000 EPACT PROCEDURES-FS PLANT-POLYREX EM, NO 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
35CB3007 35 CB CASTING W/.88 DIA. LEAD HOLE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
35EP3209A00 FREP ASSEMBLY FOR ROUTING 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3210A00 PUEP ASSEMBLY FOR ROUTING PURPOSES 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
XY1032A02 10-32 HEX NUT DIRECTIONAL SERRATION 4.000 EA
35CB4521 35 LIPPED CB LID (GALV & PHOSPH) 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
10XF0440S02 04-40 X 1/8 TYPE F HEX HD STAINLESS STIC 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.017 GA
35AD2005A01 BAFFLE PLATE,MOD 35-SLTD BAND MTRS GL.F. 2.000 EA
HA3100A45 THRUBOLT 10-32 X 8.875 4.000 EA
LB1125C04 STD-E (STOCK CTN LABEL STD-E WITH FLAG) 1.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
Page 5 of 11
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
Parts List (continued)
Part Number Description Quantity
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
PA1000 PACKING GROUP 3500 SHORT 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 11
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
Accessories
Part Number Description Multiplier
35-8764 C FACE KIT A8
35EP1604A01SP D-FLANGE KIT
Page 7 of 11
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
AC Induction Motor Performance Data
Record # 9420 - Typical performance - not guaranteed values
Winding: 35WGT478-R002 Type: 3522M Enclosure: OPSB
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 2 Full Load Torque 3 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 5.6-5.2/2.6 Breakdown Torque 14 LB-FT
R.P.M. 3450 Pull-up Torque 9 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 12 LB-FT
NEMA Design Code B KVA Code K Starting Current 22 A
Service Factor (S.F.) 1.15 No-load Current 1.2 A
NEMA Nom. Eff. 84 Power Factor 87 LinelineRes.@25ºC 7.99Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 26°C
S.F. Amps Temp. Rise @ S.F. Load 35°C
Locked-rotor Power Factor 55
Rotor inertia 0.0603 LB-FT2
Load Characteristics 460 V, 60 Hz, 2 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 50 71 81 87 89 91 0
Efficiency 72.6 81.7 84.3 84.9 84.5 83.5 0
Speed 3570 3542 3513 3482 3448 3412 0
Line amperes 1.3 1.6 2.1 2.6 3.1 3.7 2.9
Page 8 of 11
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
Performance Graph at 460V, 60Hz, 2.0HP Typical performance - Not guaranteed values
Page 9 of 11
Product Information Packet: M3155T - 2HP,3450RPM,3PH,60HZ,145T,3522M,OPSB,F1
2.60
.8750
.8745
510-520 = 11.13
521-524 = 11.63
525-528 = 12.13
529-535 = 13.00
536-546 = 14.38
2.50
2.25
4.00 2.25
5.00 .50
5.94
.19 KEY
1.38 LONG
6 HOLES
Ø.38
NAMEPLATE
6.62
5.61
3.50
3.44
6.76
2.75
2.75
4.56
3.25
6.50
LEAD HOLE
Ø.88
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
35LYT680
B
HORZ 35M OPSB 143-5T 2 POLE "W" BASE (35BA4009)
SH 1 of 1
REV. DESC:
REV:
BY:
REVISED:
MODEL NO.
VERSION:
TDR:
REF:
35LYT680
LOADING OF SWD DWG FOR 2D TO 3D CONVERSION - PKG11
ENSTEK0
D
08:58:06 12/03/2018
-
000001092572
04
35LYT680
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
