Product Information Packet
M3153T
.75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
Part Detail
Revision: R Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 34WGW012 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 34-3482 Layout: 34LY3482 Poles: 06 Created Date:
Base: RG Eff. Date: 11-08-2018 Leads: 9#18
Specs
Catalog Number: M3153T
Enclosure: OPEN
Frame: 143T
Frame Material: Steel
Output @ Frequency: .750 HP @ 60 HZ
Synchronous Speed @ Frequency: 1200 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: K
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3428M
Mounting Arrangement: F1
Power Factor: 59
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
Current @ Voltage: 1.500 A @ 460.0 V
Shaft Extension Location: Pulley End
Page 2 of 10
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
3.000 A @ 230.0 V
3.300 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
Nameplate NP1256L
CAT.NO. M3153T
SPEC. 34-3482W12
HP .75
VOLTS 230/460
AMP 3/1.5
RPM 1140
FRAME 143T HZ 60 PH 3
SER.F. 1.15 CODE K DES B CLASS B
NEMA-NOM-EFF 77 PF 59
RATING 40C AMB-CONT
CC USABLE AT 208V 3.3
DE 6205 ODE 6203
ENCL OPEN SN
Page 4 of 10
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
Parts List
Part Number Description Quantity
SA008824 SA 34-3482W12 1.000 EA
RA005271 RA 34-3482W12 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
34CB3002A CB CAST W/.88 DIA HOLE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
34EP3200A01SP FR ENDPLATE, MACH 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
34EP3904A01 PU ENDPLATE, CAST 1.000 EA
XY1032A02 10-32 HEX NUT DIRECTIONAL SERRATION 4.000 EA
34CB4517 CB LID 4 MTG HOLES .22 DIA STAMPED, FOR 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.014 GA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
HA3100A38 THRUBOLT 10-32 X 9.375 4.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
35PA1000 PKG GRP, PRINT PK1008A06 1.000 EA
Page 5 of 10
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
Accessories
Part Number Description Multiplier
34-3903A C FACE KIT A8
Page 6 of 10
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
AC Induction Motor Performance Data
Record # 57255 - Typical performance - not guaranteed values
Winding: 34WGW012-R038 Type: 3428M Enclosure: OPEN
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) .75 Full Load Torque 3.4 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 3-1.5 Breakdown Torque 11.8 LB-FT
R.P.M. 1140 Pull-up Torque 9.3 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 9.7 LB-FT
NEMA Design Code B KVA Code K Starting Current 7.4 A
Service Factor (S.F.) 1.15 No-load Current 1.1 A
NEMA Nom. Eff. 77 Power Factor 59 LinelineRes.@25ºC 21.9Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load
Locked-rotor Power Factor 55.5
Load Characteristics 460 V, 60 Hz, 0.75 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 26 40 51 59 65 68 63
Efficiency 60 72 76 77 75 73 76
Speed 1185 1170 1155 1135 1115 1095 1125
Line amperes 1.1 1.2 1.4 1.5 1.7 2 1.6
Page 7 of 10
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
Performance Graph at 460V, 60Hz, 0.75HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
Page 9 of 10
Product Information Packet: M3153T - .75HP,1140RPM,3PH,60HZ,143T,3428M,OPEN
Page 10 of 10
