Product Information Packet
M3107
.5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M3107 - .5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
Part Detail
Revision: B Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 34WG0232 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 34F779 Layout: 34LYF779 Poles: 02 Created Date: 08-09-2011
Base: RG Eff. Date: 01-21-2015 Leads: 9#18
Specs
Catalog Number: M3107
Enclosure: ODP
Frame: 56
Frame Material: Steel
Output @ Frequency: .500 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 1.000 A @ 460.0 V
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: L
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3410M
Mounting Arrangement: F1
Power Factor: 63
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
2.000 A @ 230.0 V
Shaft Extension Location: Pulley End
Page 2 of 9
Product Information Packet: M3107 - .5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
2.600 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Page 3 of 9
Product Information Packet: M3107 - .5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
Nameplate NP1256L
CAT.NO. M3107
SPEC. 34F779-0232
HP .5
VOLTS 230/460
AMP 2/1
RPM 3450
FRAME 56 HZ 60 PH 3
SER.F. 1.25 CODE J DES B CLASS B
NEMA-NOM-EFF 68 PF 63
RATING 40C AMB-CONT
CC USABLE AT 208V 2.6
DE 6203 ODE 6203
ENCL OPEN SN
SFA 2.4/1.2
Page 4 of 9
Product Information Packet: M3107 - .5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
Parts List
Part Number Description Quantity
SA229078 SA 34F779-0232 1.000 EA
RA216130 RA 34F779-0232 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
34CB3002A CB CAST W/.88 DIA HOLE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
34EP3210A01SP FR ENDPLATE, MACH 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
34EP3212A24 PU ENDPLATE, MODEL 34 OPEN 1.000 EA
XY1032A02 10-32 HEX NUT DIRECTIONAL SERRATION 4.000 EA
34CB4517 CB LID 4 MTG HOLES .22 DIA STAMPED, FOR 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A04 KEY RETAINER 0.625 DIA SHAFTS 1.000 EA
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.014 GA
10XF0440S02 04-40 X 1/8 TYPE F HEX HD STAINLESS STIC 2.000 EA
HA3100A12 THRUBOLT 10-32 X 7.375 4.000 EA
LB1125C01 STD (STOCK) CARTON LABEL BALDOR WITH FLA 1.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
34PA1002 PKG GRP, PRINT PK1001A01 1.000 EA
Page 5 of 9
Product Information Packet: M3107 - .5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
AC Induction Motor Performance Data
Record # 6559 - Typical performance - not guaranteed values
Winding: 34WG0232-R001 Type: 3410M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) .5 Full Load Torque 0.75 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 2/1 Breakdown Torque 3.4 LB-FT
R.P.M. 3450 Pull-up Torque 2.7 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 3 LB-FT
NEMA Design Code B KVA Code L Starting Current 6 A
Service Factor (S.F.) 1.25 No-load Current 0.9 A
NEMA Nom. Eff. 68 Power Factor 63 LinelineRes.@25ºC 35.1Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 58°C
S.F. Amps 2.4/1.2 Temp. Rise @ S.F. Load 69°C
Locked-rotor Power Factor 78
Rotor inertia 0.0093 LB-FT2
Load Characteristics 460 V, 60 Hz, 0.5 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 33 44 56 64 70 77 70
Efficiency 41.4 56.3 64 67.2 68.4 68.5 68.4
Speed 3563 3535 3501 3466 3432 3381 3432
Line amperes 0.91 0.97 1.01 1.1 1.2 1.33 1.2
Page 6 of 9
Product Information Packet: M3107 - .5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
Performance Graph at 460V, 60Hz, 0.5HP Typical performance - Not guaranteed values
Page 7 of 9
Product Information Packet: M3107 - .5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
Page 8 of 9
Product Information Packet: M3107 - .5HP,3450RPM,3PH,60HZ,56,3410M,OPEN,F1,N
Page 9 of 9
