Product Information Packet
M2333T-5
15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Part Detail
Revision: L Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 07WGX922 CD Diagram: CD0006 Mfg Plant:
Mech. Spec: 07H203 Layout: 07LYH203 Poles: 04 Created Date: 03-19-2009
Base: RG Eff. Date: 03-08-2016 Leads: 3#14
Specs
Catalog Number: M2333T-5
Enclosure: TEFC
Frame: 254T
Frame Material: Iron
Output @ Frequency: 15.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 575.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 15.200 A @ 575.0 V
Design Code: A
KVA Code: J
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 3 @ 14 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 0756M
Mounting Arrangement: F1
Power Factor: 83
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Drip Cover: No Drip Cover
Shaft Slinger Indicator: No Slinger
Page 2 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: H
Inverter Code: Not Inverter
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Nameplate NP1256L
CAT.NO. M2333T-5
SPEC. 07H203X922H1
HP 15
VOLTS 575
AMP 15.2
RPM 1760
FRAME 254T HZ 60 PH 3
SER.F. 1.15 CODE J DES A CLASS H
NEMA-NOM-EFF 91 PF 83
RATING 40C AMB-CONT
CC 010A USABLE AT 208V
DE 6309 ODE 6307
ENCL TEFC SN
Page 4 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Parts List
Part Number Description Quantity
SA180524 SA 07H203X922H1 1.000 EA
RA168485 RA 07H203X922H1 1.000 EA
37FN3002B01 EXFN, PLASTIC, 7.50 OD, 1.155 ID 1.000 EA
HW3201A01 1/2-13 EYEBOLT 1.000 EA
09CB3002SP CB W/1.38 LEAD HOLE FOR 37, 39, 307 & 30 1.000 EA
09GS1000SP GASKET-CONDUIT BOX, 1/16 THICK LEXIDE 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
WD1000B17 T&B CX35TN OR L35P TERMINAL LUG 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
37PE1101A03 FR/PU ENDPLATE, MACH 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A08 W3118-035 WVY WSHR (WB) 1.000 EA
07EP1116A01 ENDPLATE, MACH 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
XY3118A12 5/16-18 HEX NUT DIRECTIONAL SERRATION 4.000 EA
51XB1214A20 12-14X1.25 HXWSSLD SERTYB 1.000 EA
07FH4007SP PRIMED 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
09CB3501SP CONDUIT BOX LID FOR 09CB3001 & 09CB3002 1.000 EA
09GS1013SP 09 GS FOR 09CB3501 LID - LEXIDE 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
HW2501G25 KEY, 3/8 SQ X 2.875 1.000 EA
HA7000A03 KEY RETAINER RING 1.62 & 1.88 DIA. SH 1.000 EA
Page 5 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.036 GA
HA3104A58 THRUBOLT- 5/16-18 X 14.500 4.000 EA
LB1119N WARNING LABEL 1.000 EA
LC0006 CONNECTION LABEL 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
07PA1011 PKG GRP, 07 CAST IRON PK1181 1.000 EA
10XL3807A32 3/8 X 2" LAG SCREW TDR #49106 2.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Accessories
Part Number Description Multiplier
37-1302 C FACE KIT A8
Page 7 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
AC Induction Motor Performance Data
Record # 36502 - Typical performance - not guaranteed values
Winding: 07WGX922-R001 Type: 0756M Enclosure: TEFC
Nameplate Data
575 V, 60 Hz:
Single Voltage Motor
Rated Output (HP) 15 Full Load Torque 44.6 LB-FT
Volts 575 Start Configuration direct on line
Full Load Amps 15.2 Breakdown Torque 177 LB-FT
R.P.M. 1760 Pull-up Torque 76.4 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 108 LB-FT
NEMA Design Code A KVA Code J Starting Current 126 A
Service Factor (S.F.) 1.15 No-load Current 6.46 A
NEMA Nom. Eff. 91 Power Factor 83 LinelineRes.@25ºC 0.946Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 66°C
S.F. Amps Temp. Rise @ S.F. Load 78°C
Locked-rotor Power Factor 35
Rotor inertia 1.38 LB-FT2
Load Characteristics 575 V, 60 Hz, 15 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 44 66 76 81 84 85 83
Efficiency 86.2 91.1 91.7 91.4 90.5 89.3 90.9
Speed 1791 1784 1776 1767 1757 1746 1761
Line amperes 7.27 9.3 11.9 15.2 18.5 22.3 17.2
Page 8 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Performance Graph at 575V, 60Hz, 15.0HP Typical performance - Not guaranteed values
Page 9 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Page 10 of 11
Product Information Packet: M2333T-5 - 15HP,1760RPM,3PH,60HZ,254T,0756M,TEFC,F1
Page 11 of 11
