Baldor M1761T Product Information Sheet

Product Information Packet

M1761T

15/3.75HP,1760/880RPM,3PH,60HZ,254T

Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.

Product Information Packet: M1761T - 15/3.75HP,1760/880RPM,3PH,60HZ,254T

Part Detail

Revision: AH Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 09WGX185 CD Diagram: CD0032 Mfg Plant:
Mech. Spec: 09C101 Layout: 09LYC101 Poles: 04/08 Created Date:
Base: RG Eff. Date: 02-06-2020 Leads: 6#12

Specs

Catalog Number: M1761T
Enclosure: TEFC
Frame: 254T
Frame Material: Iron
Output @ Frequency: 15.000 HP @ 60 HZ

3.750 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR

CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None

Inverter Code: Not Inverter
IP Rating: NONE
KVA Code: G
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 6 @ 12 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 0934M
Mounting Arrangement: F1
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding

Current @ Voltage: 19.600 A @ 460.0 V

Shaft Rotation: Reversible

Page 2 of 14

Product Information Packet: M1761T - 15/3.75HP,1760/880RPM,3PH,60HZ,254T

Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: F

Shaft Slinger Indicator: Shaft Slinger
Speed Code: 2S-1W-VT
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None

Page 3 of 14

Product Information Packet: M1761T - 15/3.75HP,1760/880RPM,3PH,60HZ,254T

Nameplate NP1256L

CAT.NO. M1761T

SPEC. 09C101X185

HP 15/3.75

VOLTS 460

AMP 19.6/8.3
RPM 1760/880

FRAME 254T HZ 60 PH 3

SER.F. 1.15 CODE G DES B CLASS F

NEMA-NOM-EFF PF

RATING 40C AMB-CONT

CC USABLE AT 208V
DE 6309 ODE 6208

ENCL TEFC SN
