Baldor M1557T Product Information Sheet
Product Information Packet
M1557T
3/.75HP,1725/850RPM,3PH,60HZ,184T,3628M
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M1557T - 3/.75HP,1725/850RPM,3PH,60HZ,184T,3628M
Part Detail
Revision: |
W |
Status: |
PRD/A |
Change #: |
|
Proprietary: |
No |
|
|
|
|
|
|
|
|
Type: |
AC |
Elec. Spec: |
36WGX365 |
CD Diagram: |
CD0032 |
Mfg Plant: |
|
|
|
|
|
|
|
|
|
Mech. Spec: |
36A001 |
Layout: |
36LYA001 |
Poles: |
04/08 |
Created Date: |
|
|
|
|
|
|
|
|
|
Base: |
RG |
Eff. Date: |
01-23-2020 |
Leads: |
6#16 |
|
|
|
|
|
|
|
|
|
|
Specs
Catalog Number: |
M1557T |
|
|
Enclosure: |
TEFC |
|
|
Frame: |
184T |
|
|
Frame Material: |
Steel |
|
|
Output @ Frequency: |
3.000 HP @ 60 HZ |
|
|
|
.750 HP @ 60 HZ |
|
|
Synchronous Speed @ Frequency: |
900 RPM @ 60 HZ |
|
|
Voltage @ Frequency: |
208.0 V @ 60 HZ |
|
|
|
230.0 V @ 60 HZ |
|
|
XP Class and Group: |
None |
|
|
XP Division: |
Not Applicable |
|
|
Agency Approvals: |
UR |
|
|
|
CSA |
|
|
Auxillary Box: |
No Auxillary Box |
|
|
Auxillary Box Lead Termination: |
None |
|
|
Base Indicator: |
Rigid |
|
|
Bearing Grease Type: |
Polyrex EM (-20F +300F) |
|
|
Blower: |
None |
|
|
Heater Indicator: |
No Heater |
|
|
Insulation Class: |
F |
|
|
Inverter Code: |
Not Inverter |
|
|
KVA Code: |
G |
|
|
Lifting Lugs: |
No Lifting Lugs |
|
|
Locked Bearing Indicator: |
No Locked Bearing |
|
|
Motor Lead Quantity/Wire Size: |
6 @ 16 AWG |
|
|
Motor Lead Exit: |
Ko Box |
|
|
Motor Lead Termination: |
Flying Leads |
|
|
Motor Type: |
3628M |
|
|
Mounting Arrangement: |
F1 |
|
|
Product Family: |
General Purpose |
|
|
Pulley End Bearing Type: |
Ball |
|
|
Pulley Face Code: |
Standard |
|
|
Pulley Shaft Indicator: |
Standard |
|
|
Rodent Screen: |
None |
|
|
Shaft Extension Location: |
Pulley End |
|
|
Shaft Ground Indicator: |
No Shaft Grounding |
|
|
of 13 2
Page
Product Information Packet: M1557T - 3/.75HP,1725/850RPM,3PH,60HZ,184T,3628M
Current @ Voltage: |
3.000 A @ 230.0 V |
|
|
|
8.000 A @ 208.0 V |
|
|
Design Code: |
B |
|
|
Drip Cover: |
No Drip Cover |
|
|
Duty Rating: |
CONT |
|
|
Electrically Isolated Bearing: |
Not Electrically Isolated |
|
|
Feedback Device: |
NO FEEDBACK |
|
|
Front Face Code: |
Standard |
|
|
Front Shaft Indicator: |
None |
|
|
Shaft Rotation: |
Reversible |
|
|
Shaft Slinger Indicator: |
No Slinger |
|
|
Speed Code: |
2S-1W-VT |
|
|
Motor Standards: |
NEMA |
|
|
Starting Method: |
Direct on line |
|
|
Thermal Device - Bearing: |
None |
|
|
Thermal Device - Winding: |
None |
|
|
Vibration Sensor Indicator: |
No Vibration Sensor |
|
|
Winding Thermal 1: |
None |
|
|
Winding Thermal 2: |
None |
|
|
of 13 3
Page
Product Information Packet: M1557T - 3/.75HP,1725/850RPM,3PH,60HZ,184T,3628M
Nameplate NP1256L
CAT.NO. |
M1557T |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SPEC. |
36A01X365 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
HP |
3/.75 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VOLTS |
208-230 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AMP |
8/3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RPM |
1725/850 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FRAME |
184T |
|
|
|
|
HZ |
60 |
|
|
|
|
|
|
|
PH |
3 |
|
SER.F. |
1.15 |
|
|
CODE |
G |
|
|
DES |
B |
|
|
|
|
CLASS |
F |
|
|
NEMA-NOM-EFF |
|
|
|
PF |
|
|
|
|
|
|
|
|
|
|
|
|
|
RATING |
40C AMB-CONT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CC |
|
|
|
|
|
|
|
|
|
USABLE AT 208V |
|
|
|||||
DE |
6206 |
|
|
|
|
ODE |
6205 |
|
|
|
|
|
|
|
|
||
ENCL |
TEFC |
|
SN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
of 13 4
