Product Information Packet
M1223T
3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Part Detail
Revision: Z Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 36WGY048 CD Diagram: CD0013 Mfg Plant:
Mech. Spec: 36B001 Layout: 36LYB001 Poles: 04/06 Created Date:
Base: RG Eff. Date: 01-30-2020 Leads: 6#16
Specs
Catalog Number: M1223T
Enclosure: OPEN
Frame: 184T
Frame Material: Steel
Output @ Frequency: 3.000 HP @ 60 HZ
1.300 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Insulation Class: F
Inverter Code: Not Inverter
KVA Code: G
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 6 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3634M
Mounting Arrangement: F1
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Current @ Voltage: 4.000 A @ 460.0 V
Shaft Rotation: Reversible
Page 2 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Slinger Indicator: No Slinger
Speed Code: 2S-2W-VT
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Nameplate NP1256L
CAT.NO. M1223T
SPEC. 36B01Y48
HP 3/1.3
VOLTS 460
AMP 4/2.6
RPM 1725/1140
FRAME 184T HZ 60 PH 3
SER.F. 1.15 CODE G DES B CLASS F
NEMA-NOM-EFF PF
RATING 40C AMB-CONT
CC USABLE AT 208V
DE 6206 ODE 6205
ENCL OPEN SN
Page 4 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Parts List
Part Number Description Quantity
SA034238 SA 36B01Y48 1.000 EA
RA030266 RA 36B01Y48 1.000 EA
36CB3004 36 CB CASTING W/1.09 DIA LEAD HOLE @ 6:0 1.000 EA
51XB1016A08 10-16X 1/2HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
36EP3204B00 MASTER ODE,205 BRG,GRSR 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA
36EP3205D00 MASTER DE,206 BRG,1.197SH,GRSR 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
XY2520A12 1/4-20 HEX NUT, DIRECTIONAL SERRATIONS 4.000 EA
36CB4516 36 LIPPED CB LID - GALVANNEAL 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501E16 KEY, 1/4 SQ X 1.750 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.022 GA
HA3101A25 THRUBOLT 1/4-20 X 11.000 OHIO ROD 4.000 EA
LB1119N WARNING LABEL 1.000 EA
LC0013 CONNECTION LABEL 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
Page 5 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Parts List (continued)
Part Number Description Quantity
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
PE-0000001 ZRTG PE ASSEMBLY 1.000 EA
FE-0000001 ZRTG FE ASSEMBLY 1.000 EA
Page 6 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Accessories
Part Number Description Multiplier
36-3403 C FACE KIT A8
36EP1405A09SP D-FLANGE KIT A8
Page 7 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
AC Induction Motor Performance Data
Record # 61406 - Typical performance - not guaranteed values
Winding: 36WGY048-R005 Type: 3634M Enclosure: OPEN
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 3/1.3 Full Load Torque 9.2 LB-FT
Volts 460 Start Configuration direct on line
Full Load Amps 4/2.6 Breakdown Torque 28 LB-FT
R.P.M. 1725/1140 Pull-up Torque 13 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 19 LB-FT
NEMA Design Code B KVA Code G Starting Current 24 A
Service Factor (S.F.) 1.15 No-load Current 1.5 A
NEMA Nom. Eff. 0 Power Factor 0 LinelineRes.@25ºC 9.82Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 52°C
S.F. Amps Temp. Rise @ S.F. Load 66°C
Locked-rotor Power Factor 65.1
Rotor inertia 0.319 LB-FT2
Load Characteristics 460 V, 60 Hz, 3 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 56 77 87 90 91 89 91
Efficiency 74.3 81.5 82.4 81.2 78.7 75.2 86.9
Speed 1781 1763 1742 1718 1690 1655 3384
Line amperes 1.75 2.3 3 3.85 4.85 6.1 16.9
Page 8 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Performance Graph at 460V, 60Hz, 3.0HP Typical performance - Not guaranteed values
Page 9 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
AC Induction Motor Performance Data
Record # 61407 - Typical performance - not guaranteed values
Winding: 36WGY048-R005 Type: 3634M Enclosure: OPEN
Nameplate Data
460 V, 60 Hz:
Low Speed Connection
Rated Output (HP) 3/1.3 Full Load Torque 5.86 LB-FT
Volts 460 Start Configuration direct on line
Full Load Amps 4/2.6 Breakdown Torque 20.2 LB-FT
R.P.M. 1725/1140 Pull-up Torque 990 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 12 LB-FT
NEMA Design Code B KVA Code G Starting Current 12.6 A
Service Factor (S.F.) 1.15 No-load Current 1.71 A
NEMA Nom. Eff. 0 Power Factor 0 LinelineRes.@25ºC 17.7Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load
Locked-rotor Power Factor 65.1
Rotor inertia 0.319 LB-FT2
Load Characteristics 460 V, 60 Hz, 1.3 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 31 46 59 68 75 80 72
Efficiency 57.1 70.7 75.9 77.9 78.4 77.9 78.2
Speed 1192 1184 1176 1167 1158 1147 1162
Line amperes 1.75 1.86 2.05 2.29 2.59 2.94 2.47
Page 10 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Performance Graph at 460V, 60Hz, 1.3HP Typical performance - Not guaranteed values
Page 11 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Page 12 of 13
Product Information Packet: M1223T - 3/1.3HP,1725/1140RPM,3PH,60HZ,184T,3634M
Page 13 of 13
