Product Information Packet
M1208T
5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Part Detail
Revision: W Status: PRD/A Change #: Proprietary: No Type: AC Elec. Spec: 36WGW582 CD Diagram: CD0032 Mfg Plant: Mech. Spec: 36B001 Layout: 36LYB001 Poles: 04/08 Created Date: Base: RG Eff. Date: 01-30-2020 Leads: 6#16
Specs
Catalog Number: M1208T Enclosure: OPEN Frame: 184T Frame Material: Steel Output @ Frequency: 5.000 HP @ 60 HZ
1.300 HP @ 60 HZ Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ Voltage @ Frequency: 460.0 V @ 60 HZ XP Class and Group: None XP Division: Not Applicable Agency Approvals: UR
CSA Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: Rigid Bearing Grease Type: Polyrex EM (-20F +300F) Blower: None
Insulation Class: F Inverter Code: Not Inverter KVA Code: J Lifting Lugs: No Lifting Lugs Locked Bearing Indicator: No Locked Bearing Motor Lead Quantity/Wire Size: 6 @ 16 AWG Motor Lead Exit: Ko Box Motor Lead Termination: Flying Leads Motor Type: 3634M Mounting Arrangement: F1 Product Family: General Purpose Pulley End Bearing Type: Ball Pulley Face Code: Standard Pulley Shaft Indicator: Standard Rodent Screen: None Shaft Extension Location: Pulley End Shaft Ground Indicator: No Shaft Grounding
Current @ Voltage: 6.600 A @ 460.0 V
Shaft Rotation: Reversible
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Design Code: B Drip Cover: No Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Face Code: Standard Front Shaft Indicator: None Heater Indicator: No Heater
Shaft Slinger Indicator: No Slinger Speed Code: 2S-1W-VT Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: None Vibration Sensor Indicator: No Vibration Sensor Winding Thermal 1: None Winding Thermal 2: None
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Nameplate NP1256L
CAT.NO. M1208T
SPEC. 36B01W582
HP 5/1.3
VOLTS 460
AMP 6.6/2.5 RPM 1725/850
FRAME 184T HZ 60 PH 3
SER.F. 1.15 CODE J DES B CLASS F
NEMA-NOM-EFF PF
RATING 40C AMB-CONT
CC USABLE AT 208V DE 6206 ODE 6205
ENCL OPEN SN
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Parts List
Part Number Description Quantity SA034217 SA 36B01W582 1.000 EA RA030245 RA 36B01W582 1.000 EA 36CB3004 36 CB CASTING W/1.09 DIA LEAD HOLE @ 6:0 1.000 EA 51XB1016A08 10-16X 1/2HXWSSLD SERTYB 2.000 EA 11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA 36EP3204B00 MASTER ODE,205 BRG,GRSR 1.000 EA HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA 36EP3205D00 MASTER DE,206 BRG,1.197SH,GRSR 1.000 EA HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA XY2520A12 1/4-20 HEX NUT, DIRECTIONAL SERRATIONS 4.000 EA 36CB4516 36 LIPPED CB LID - GALVANNEAL 1.000 EA 51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA HW2501E16 KEY, 1/4 SQ X 1.750 1.000 EA HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.022 GA HA3101A25 THRUBOLT 1/4-20 X 11.000 OHIO ROD 4.000 EA LB1119N WARNING LABEL 1.000 EA LC0032 CONNECTION LABEL 1.000 EA NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA 36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Parts List (continued)
Part Number Description Quantity MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA PE-0000001 ZRTG PE ASSEMBLY 1.000 EA FE-0000001 ZRTG FE ASSEMBLY 1.000 EA
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Accessories
Part Number Description Multiplier 36-3403 C FACE KIT A8 36EP1405A09SP D-FLANGE KIT A8
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
AC Induction Motor Performance Data
Record # 36961 - Typical performance - not guaranteed values
Winding: 36WGW582-R001 Type: 3634M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Speed Connection Rated Output (HP) 5/1.3 Full Load Torque 15.3 LB-FT Volts 460 Start Configuration direct on line Full Load Amps 6.6/2.5 Breakdown Torque 50 LB-FT R.P.M. 1725/850 Pull-up Torque 31 LB-FT Hz 60 Phase 3 Locked-rotor Torque 34 LB-FT NEMA Design Code B KVA Code J Starting Current 48 A Service Factor (S.F.) 1 No-load Current 3.2 A NEMA Nom. Eff. 0 Power Factor 0 LinelineRes.@25ºC 3.95Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 67°C
Load Characteristics 460 V, 60 Hz, 5 HP
% of Rated Load 25 50 75 100 125 150 Power Factor 48 69 80 86 87 87 Efficiency 72.3 80.9 83.2 82.9 81.6 80 Speed 1780 1762 1743 1720 1698 1670 Line amperes 3.5 4.3 5.4 6.6 8.1 9.8
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Performance Graph at 460V, 60Hz, 5.0HP Typical performance - Not guaranteed values
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
AC Induction Motor Performance Data
Record # 36962 - Typical performance - not guaranteed values
Winding: 36WGW582-R001 Type: 3634M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
Low Speed Connection Rated Output (HP) 5/1.3 Full Load Torque 8 LB-FT Volts 460 Start Configuration direct on line Full Load Amps 6.6/2.5 Breakdown Torque 19 LB-FT R.P.M. 1725/850 Pull-up Torque 10 LB-FT Hz 60 Phase 3 Locked-rotor Torque 11.5 LB-FT NEMA Design Code B KVA Code J Starting Current 9.6 A Service Factor (S.F.) 1 No-load Current 1.8 A NEMA Nom. Eff. 0 Power Factor 0 LinelineRes.@25ºC 15.8Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 54°C
Load Characteristics 460 V, 60 Hz, 1.3 HP
% of Rated Load 25 50 75 100 125 150 Power Factor 32 47 59 67 71 73 Efficiency 51.8 65.8 71 72.6 72.2 70.3 Speed 886 875 863 849 833 812 Line amperes 1.9 2 2.2 2.5 2.9 3.4
Page 10 of 13
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Performance Graph at 460V, 60Hz, 1.3HP Typical performance - Not guaranteed values
Page 11 of 13
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Page 12 of 13
Product Information Packet: M1208T - 5/1.3HP,1725/850RPM,3PH,60HZ,184T,3634M
Page 13 of 13
