KM3454-57
.25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Part Detail
Revision: H Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 34WGS886 CD Diagram: CD0022 Mfg Plant:
Mech. Spec: 34A063 Layout: 34LYA063 Poles: 04 Created Date: 09-02-2011
Base: N Eff. Date: 04-06-2020 Leads: 6#18
Specs
Catalog Number: KM3454-57
Enclosure: TEFC
Frame: 56C
Frame Material: Steel
Output @ Frequency: .250 HP @ 50 HZ
Synchronous Speed @ Frequency: 1500 RPM @ 50 HZ
Voltage @ Frequency: 400.0 V @ 50 HZ
230.0 V @ 50 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
WEEE
CSA
CE
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: No Mounting
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: L
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 6 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3410M
Mounting Arrangement: F1
Power Factor: 59
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
Bearing Grease Type: Polyrex EM (-20F +300F)
Shaft Extension Location: Pulley End
Page 2 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Blower: None
Current @ Voltage: .700 A @ 400.0 V
1.200 A @ 230.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Nameplate NP1372L
CAT.NO. KM3454-57
SPEC. 34A063S886G1
HP .25/KW .18
VOLTS 230/400
AMP 1.2/.7
RPM 1425 IP54 KG9
FRAME 56C HZ 50 PH 3
SER.F. 1.25 CODE L DES B CL B
NEMA-NOM-EFF 64 PF 59
RATING 40C AMB-CONT
CC USABLE AT 208V
DE 6203 ODE 6203
ENCL TEFC SN
SFA 1.3/.75
Page 4 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Parts List
Part Number Description Quantity
SA230020 SA 34A063S886G1 1.000 EA
RA217054 RA 34A063S886G1 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
34CB3002A CB CAST W/.88 DIA HOLE 1.000 EA
34GS1029A01 GASKET, CONDUIT BOX 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
34EP3102A01SP FR ENDPLATE, MACH 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
34EP3300A24SP PU ENDPLATE, MACH 1.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
34FN3002A01SP EXTERNAL FAN, PLASTIC, .637/.639 HUB W/ 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
34CB4517 CB LID 4 MTG HOLES .22 DIA STAMPED, FOR 1.000 EA
34GS1031A01 GASKET, FLAT CONDUIT BOX LID (LEXIDE) 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
34FH4002A01SP IEC FH NO GREASER PRIMED 1.000 EA
HA7000A04 KEY RETAINER 0.625 DIA SHAFTS 1.000 EA
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.014 GA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
HA4067A01 PUSH IN DRAIN FITTING (BLACK) 1.000 EA
HA4067A01 PUSH IN DRAIN FITTING (BLACK) 1.000 EA
HA3100A12 THRUBOLT 10-32 X 7.375 4.000 EA
Page 5 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Parts List (continued)
Part Number Description Quantity
LB1119N WARNING LABEL 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
LC0034 CONNECTION LABEL 1.000 EA
NP1372L ALUM UL CSA CE CC 1.000 EA
35PA1000 PKG GRP, PRINT PK1008A06 1.000 EA
Page 6 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
AC Induction Motor Performance Data
Record # 35108 - Typical performance - not guaranteed values
Winding: 34WGS886-R001 Type: 3410M Enclosure: TEFC
Nameplate Data
400 V, 50 Hz:
High Voltage Connection
Rated Output (HP) .25 Full Load Torque 0.901 LB-FT
Volts 230/400 Start Configuration direct on line
Full Load Amps 1.2/.7 Breakdown Torque 2.93 LB-FT
R.P.M. 1425 Pull-up Torque 1.97 LB-FT
Hz 50 Phase 3 Locked-rotor Torque 2.16 LB-FT
NEMA Design Code B KVA Code L Starting Current 2.75 A
Service Factor (S.F.) 1.25 No-load Current 0.59 A
NEMA Nom. Eff. 64 Power Factor 59 LinelineRes.@25ºC 72Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 53°C
S.F. Amps 1.3/.75 Temp. Rise @ S.F. Load 60°C
Locked-rotor Power Factor 80
Rotor inertia 0.0238 LB-FT2
Load Characteristics 400 V, 50 Hz, 0.25 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 30 42 51 59 67 74 67
Efficiency 37.9 53.7 61.9 66.1 68.2 68.2 68.2
Speed 1483 1470 1456 1440 1423 1404 1423
Line amperes 0.592 0.603 0.635 0.678 0.723 0.769 0.723
Page 7 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Performance Graph at 400V, 50Hz, 0.25HP Typical performance - Not guaranteed values
Page 8 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
AC Induction Motor Performance Data
Record # 46459 - Typical performance - not guaranteed values
Winding: 34WGS886-R001 Type: 3410M Enclosure: TEFC
Nameplate Data
230 V, 50 Hz:
Low Voltage Connection
Rated Output (HP) .25 Full Load Torque 0.901 LB-FT
Volts 230/400 Start Configuration direct on line
Full Load Amps 1.2/.7 Breakdown Torque 2.91 LB-FT
R.P.M. 1425 Pull-up Torque 1.95 LB-FT
Hz 50 Phase 3 Locked-rotor Torque 2.14 LB-FT
NEMA Design Code B KVA Code L Starting Current 4.74 A
Service Factor (S.F.) 1.25 No-load Current 1.01 A
NEMA Nom. Eff. 64 Power Factor 59 LinelineRes.@25ºC 24.1Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 52°C
S.F. Amps 1.3/.75 Temp. Rise @ S.F. Load 59°C
Locked-rotor Power Factor 80
Rotor inertia 0.0238 LB-FT2
Load Characteristics 230 V, 50 Hz, 0.25 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 30 42 52 60 68 74 68
Efficiency 38.4 54.1 62.3 66.3 68.4 68.3 68.4
Speed 1483 1470 1456 1440 1422 1403 1422
Line amperes 1.02 1.04 1.09 1.17 1.24 1.33 1.24
Page 9 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Performance Graph at 230V, 50Hz, 0.25HP Typical performance - Not guaranteed values
Page 10 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Page 11 of 12
Product Information Packet: KM3454-57 - .25HP,IP54,1425RPM,3PH,50HZ,56C,3410M
Page 12 of 12
