Product Information Packet
JMM3555T
2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
Part Detail
Revision: F Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGT962 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 35TT921 Layout: 35LYTT921 Poles: 02 Created Date: 06-01-2010
Base: RG Eff. Date: 03-08-2016 Leads: 9#18
Specs
Catalog Number: JMM3555T
Enclosure: TEFC
Frame: 145JM
Frame Material: Steel
Output @ Frequency: 2.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 208.0 V @ 60 HZ
230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: RG
Bearing Grease Type: Polyrex EM (-20F +300F)
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Not Inverter
KVA Code: L
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3526M
Mounting Arrangement: F1
Power Factor: 88
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Tapped & Key
Rodent Screen: None
Blower: None
Shaft Extension Location: Pulley End
Page 2 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
Current @ Voltage: 2.600 A @ 460.0 V
5.200 A @ 230.0 V
5.600 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: Shaft Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
Nameplate NP1256L
CAT.NO. JMM3555T
SPEC. 35TT921T962H1
HP 2
VOLTS 208-230/460
AMP 5.6-5.2/2.6
RPM 3450
FRAME 145JM HZ 60 PH 3
SER.F. 1.15 CODE L DES B CLASS F
NEMA-NOM-EFF 84 PF 88
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 5.6
DE 6206 ODE 6203
ENCL TEFC SN
Page 4 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
Parts List
Part Number Description Quantity
SA197376 SA 35TT921T962H1 1.000 EA
RA184765 RA 35TT921T962H1 1.000 EA
34FN3002A01SP EXTERNAL FAN, PLASTIC, .637/.639 HUB W/ 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
35CB3009 35 CB W/1.09 DIA. LEAD HOLE @ 6: 1.000 EA
36GS1000SP GASKET-CONDUIT BOX, .06 THICK #SV-330 LE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
35EP3122G00 FREP TEFC 203BRG,GRSR,RLF(RAISED FH PADS 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3401T05 FACE ENCL 206 BRG W/GRS, RELIEF & TGHSLV 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
35FH4005A86 IEC FH W/GRSR, NO DIMPLES W/PRIMER 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
HA1005A02 SLINGER, OD 2.00, ID 1.14, 206 BRG, 1.000 EA
35CB4521 35 LIPPED CB LID (GALV & PHOSPH) 1.000 EA
35GS1030 35 GS FOR CB LID - LEXIDE 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
Page 5 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
10XF0440S02 04-40 X 1/8 TYPE F HEX HD STAINLESS STIC 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.017 GA
HA3100A15 THRUBOLT 10-32 X 8.375 4.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
35PA1007 PKG GRP, PRINT PK1034A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
AC Induction Motor Performance Data
Record # 20593 - Typical performance - not guaranteed values
Winding: 35WGT962-R005 Type: 3526M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 2 Full Load Torque 3 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 5.6-5.2/2.6 Breakdown Torque 12.4 LB-FT
R.P.M. 3450 Pull-up Torque 7.6 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 11 LB-FT
NEMA Design Code B KVA Code L Starting Current 24.3 A
Service Factor (S.F.) 1.15 No-load Current 1.1 A
NEMA Nom. Eff. 84 Power Factor 88 LinelineRes.@25ºC 7.86Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 47°C
S.F. Amps Temp. Rise @ S.F. Load 55°C
Locked-rotor Power Factor 54
Rotor inertia 0.0712 LB-FT2
Load Characteristics 460 V, 60 Hz, 2 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 50 73 80 85 89 89 87
Efficiency 72.7 81.2 83.8 84.2 83.7 82.6 83.9
Speed 3563 3537 3507 3475 3440 3402 3454
Line amperes 1.3 1.6 2.1 2.6 3.1 3.7 2.9
Page 7 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
Performance Graph at 460V, 60Hz, 2.0HP Typical performance - Not guaranteed values
Page 8 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
AC Induction Motor Performance Data
Record # 36865 - Typical performance - not guaranteed values
Winding: 35WGT962-R002 Type: 3526M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 2 Full Load Torque 3 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 5.6-5.2/2.6 Breakdown Torque 12.4 LB-FT
R.P.M. 3450 Pull-up Torque 7.6 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 11 LB-FT
NEMA Design Code B KVA Code L Starting Current 24.3 A
Service Factor (S.F.) 1.15 No-load Current 1.1 A
NEMA Nom. Eff. 84 Power Factor 88 LinelineRes.@25ºC 7.1Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 47°C
S.F. Amps Temp. Rise @ S.F. Load 55°C
Locked-rotor Power Factor 54
Rotor inertia 0.0712 LB-FT2
Load Characteristics 460 V, 60 Hz, 2 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 50 73 80 85 89 89 87
Efficiency 72.7 81.2 83.9 84.2 83.7 82.6 83.9
Speed 3563 3537 3507 3475 3440 3402 3454
Line amperes 1.3 1.6 2.1 2.6 3.1 3.7 2.9
Page 9 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
Performance Graph at 460V, 60Hz, 2.0HP Typical performance - Not guaranteed values
Page 10 of 12
Product Information Packet: JMM3555T - 2HP,3450RPM,3PH,60HZ,145JM,3526M,TEFC,F1
8750
8745
1 0000
9995
4 500
4 497
6 54
4 283
4 221
2 892
2 862
642
612
13
510-528 = 15 41
529-535 = 16 29
536-546 = 17 66
1 156
1 154
7 19
4 00
5 00
5 94
3 75
50
2 88
GREASE FITTINGS
(EACH END)
6 HOLES
Ø 34
GREASE RELIEF
(EACH END)
SLINGER
NAMEPLATE
38-16 UNC
CL 3 R H TAP
88 DEEP
CHECK WITH
GAGE T-9038
19 KEY
1 38 LONG
2 75 2 75
4 59 3 25
6 50
3 50
3 44
6 81
5 71
45° 45°
6 63
LEAD HOLE
Ø1 09
4 HOLES
38-16 TAP
ON Ø5 88 B C
1 25
PULLEY END DETAIL
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
35LYTT921
B
HORZ FACE MTD 143-5JM TEFC 35M, 2 POLE "W" BASE(35BA4009)
SH 1 of 1
REV. DESC
REV
BY
REVISED
MODEL NO.
VERSION
TDR
REF
35LYTT921
LOADING OF SWD DWG FOR 2D TO 3D CONVERSIONS PKG 13
ENALEM0
C
07 41 51 01/02/2019
-
000001094435
03
35LYTT921
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
Page 11 of 12
