Product Information Packet
JMEWDM41906T
60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Part Detail
Revision: E Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 39WGX632 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 39K68 Layout: 39LYK068 Poles: 02 Created Date: 10-23-2018
Base: RG Eff. Date: 01-08-2020 Leads: 9#10
Specs
Catalog Number: JMEWDM41906T
Enclosure: TEFC
Frame: 256JM
Frame Material: Steel
Output @ Frequency: 20.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
CSA EEV
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Insulation Class: F
Inverter Code: Not Inverter
KVA Code: G
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 10 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3960M
Mounting Arrangement: F1
Power Factor: 93
Product Family: Wash Down
Pulley End Bearing Type: Sealed Bearing
Pulley Face Code: C-Face
Pulley Shaft Indicator: Tapped & Key
Rodent Screen: None
Shaft Extension Location: Pulley End
Blower: None
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 10
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Current @ Voltage: 21.500 A @ 460.0 V
43.000 A @ 230.0 V
Design Code: A
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Rotation: Reversible
Shaft Slinger Indicator: Shaft Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Nameplate NP1669L
CAT.NO. JMEWDM41906T
SPEC. 39K068X632G1
HP 20
VOLTS 230/460
AMP 43/21.5
RPM 3525
FRAME 256JM HZ 60 PH 3
SER.F. 1.00 CODE G DES A CLASS F
NEMA-NOM-EFF 91 PF 93
RATING 40C AMB-CONT
CC 010A USABLE AT 208V
DE 6309 ODE 6208
ENCL TEFC SN
BLANK 20:1CT, 20:1VT, 1.00SF
Page 4 of 10
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Parts List
Part Number Description Quantity
SA362237 SA 39K068X632G1 1.000 EA
RA351455 RA 39K068X632G1 1.000 EA
09FN3001C01 EXTERNAL FAN, PLASTIC 1.000 EA
HA6016P ADAPTER, CAST CONDUT BOX EPOXY PRIMER 1.000 EA
09GS1006 GASKET, CONDUIT BOX, NEOP-1/16 THICK-BLA 1.000 EA
09CB3000A02P SPL 309 CONDUIT BOX W/1.25 N.P.T. W/PRI 1.000 EA
RM1017 LEAD SEPERATOR GASKET MODEL 307 1/8" THK 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 2.000 EA
WD1000B16 T&B CX70TN OR L70P TERMINAL LUG 1.000 EA
59XW2520G07 .25-20X.44,HEX SER WSHR,TAPTITE 2,GREEN 1.000 EA
39EP1100A08WP FR ENDPLATE, MACH W/WHITE EPOXY, PRIMED 1.000 EA
HW4032A01 BLACK DRAIN PLUG FOR WASH DOWN MOTORS 3.000 EA
HW4600B44 V-RING SLINGER 1.500 X 1.810 X .28 VITON 1.000 EA
HW5100A08 W3118-035 WVY WSHR (WB) 1.000 EA
10XN2520S28 1/4-20X 1 3/4 HEX HD SS X 4.000 EA
39EP1500A06P PU ENDPLATE, MACH W/EPOXY PRIMER 1.000 EA
HW4600A27 SEAL 1.750 X 2.441 X 0.313 SINGLE LIP 1.000 EA
HW4600B67 V-RING SLINGER 1.770 X 2.170 X .28 VITON 1.000 EA
HA3154S02 THRUBOLT STUD 3/8-16 X 15.875 SS 4.000 EA
XY3816S12 3/8-16 HEX FINISHED NUT SS 8.000 EA
HA2101A05 SS SPACER,SCH 40,.25" SS PIPE,.625" LONG 3.000 EA
10XN2520S20 1/4-20X 1 1/4 HEX HD CAP SS 3.000 EA
09CB3500P CONDUIT BOX LID, CAST W/PRIMER 1.000 EA
Page 5 of 10
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Parts List (continued)
Part Number Description Quantity
09GS1001A01 GASKET, BOX LID, 1/8 THICK BLACK NEOPREN 1.000 EA
19XT2520S12 1/4-20X3/4 HWH NO SLOT TY.23 18-8 S.S. 2.000 EA
HW1001S25 WASHER, 1/4 SPLT LK, STAINLESS STEEL 2.000 EA
HW2502E18 #303 SS,SQ KEY 1/4 X 2.000 1.000 EA
MJ5001A27 32220KN GRAY SEALER *MIN BUY 4 QTS=1GAL 0.016 QT
MJ5002A01 SILICON RUBBER SEALANT, 732CL 10.3 OZ TU 0.025 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
LB1164 LABEL,WARNING AND DRAIN 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.085 LB
HW4032A01 BLACK DRAIN PLUG FOR WASH DOWN MOTORS 3.000 EA
HW2500A25 WOODRUFF KEY USA #1008 #BLOW CARBON STEE 1.000 EA
51XB1214A20 12-14X1.25 HXWSSLD SERTYB 1.000 EA
09FH4000A23MWP FAN COVER, MACH W/WHITE EPOXY 1.000 EA
MG1025W01 WILKOFAST, 781.01, SIGNAL WHITE #9003 0.050 GA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1119N WARNING LABEL 1.000 EA
LC0005 CONN.DIA.,TY M,9-LD,DUAL VOLT,REVERSING 1.000 EA
NP1669L SS WD SUPER-E UL CSA-EEV PREM REV MTG 1.000 EA
40PA1000 PACKAGING GROUP 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
AC Induction Motor Performance Data
Record # 26903 - Typical performance - not guaranteed values
Winding: 39WGX632-R001 Type: 3960M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 20 Full Load Torque 29.6 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 43/21.5 Breakdown Torque 114 LB-FT
R.P.M. 3525 Pull-up Torque 35.3 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 51 LB-FT
NEMA Design Code B KVA Code G Starting Current 152 A
Service Factor (S.F.) 1.15 No-load Current 4.75 A
NEMA Nom. Eff. 91 Power Factor 93 LinelineRes.@25ºC 0.437Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 75°C
S.F. Amps Temp. Rise @ S.F. Load 97°C
Locked-rotor Power Factor 27
Rotor inertia 1.53 LB-FT2
Load Characteristics 460 V, 60 Hz, 20 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 71 88 92 93 93 92 93
Efficiency 91 93.5 93.3 92.5 91.2 89.7 91.7
Speed 3581 3562 3541 3519 3492 3465 3503
Line amperes 6.84 11.2 16.2 21.5 27.6 33.8 25.2
Page 7 of 10
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Performance Graph at 460V, 60Hz, 20.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Page 9 of 10
Product Information Packet: JMEWDM41906T - 60M 2P TEFC HOR 256JM SP9 HOSE DOWN SE
Page 10 of 10
