Product Information Packet
JMEWDM3615T
5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Part Detail
Revision: F Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 36WGS268 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 36K605 Layout: 36LYK605 Poles: 04 Created Date: 12-04-2014
Base: RG Eff. Date: 01-15-2020 Leads: 9#16
Specs
Catalog Number: JMEWDM3615T
Enclosure: TEFC
Frame: 184JM
Frame Material: Steel
Output @ Frequency: 5.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA EEV
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Inverter Ready
KVA Code: J
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3642M
Mounting Arrangement: F1
Power Factor: 78
Product Family: Wash Down
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Tapped & Key
Rodent Screen: None
Blower: None
Shaft Extension Location: Pulley End
Page 2 of 10
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Current @ Voltage: 13.400 A @ 230.0 V
13.900 A @ 208.0 V
6.700 A @ 460.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: Shaft Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Nameplate NP1669L
CAT.NO. JMEWDM3615T
SPEC. 36K605S268G1
HP 5
VOLTS 230/460
AMP 13.4/6.7
RPM 1750
FRAME 184JM HZ 60 PH 3
SER.F. 1.15 CODE J DES B CLASS F
NEMA-NOM-EFF 89.5 PF 78
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 13.9
DE 6207 ODE 6205
ENCL TEFC SN
BLANK 20:1CT, 20:1VT, 1.00SF
Page 4 of 10
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Parts List
Part Number Description Quantity
SA290729 SA 36K605S268G1 1.000 EA
RA276885 RA 36K605S268G1 1.000 EA
36FN3000C01SP EXFN, PLASTIC, 5.25 OD, .912 ID 1.000 EA
36CB3005A03W 36 CB .75 NPT @ 6 W/WHITE EPOXY 1.000 EA
35GS1022A03 GASKET BOX .125 THK WHITE NEOPRENE 1.000 EA
51XB1016A08 10-16X 1/2HXWSSLD SERTYB 2.000 EA
HA5027A01 HA4066A01 T-DRAIN X2 BAGGED 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
36EP3104A03MW FREP MACH (RAISED FH PADS) WHITE EPOXY 1.000 EA
HW4032A01 BLACK DRAIN PLUG FOR WASH DOWN MOTORS 3.000 EA
HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA
36EP1302A23MW FACE MT EP FOR HOSE DOWN MTR W/WHITE EPO 1.000 EA
HW4600B51 SEAL 1.375 X 2.125 X 0.313 SINGLE LIP DB 1.000 EA
HW4032A01 BLACK DRAIN PLUG FOR WASH DOWN MOTORS 3.000 EA
10XN2520S26 1/4-20X 1 5/8 HEX HD SS 4.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
36FH4010A08 IEC FH NO GREASER - W/PRIMER 1.000 EA
11XW1032S06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 3.000 EA
HW4600B32SP V-RING SLINGER 1.000 X 1.540 X .24 VITON 1.000 EA
HW4600B33 V-RING SLINGER 1.375 X 1.890 X .35 VITON 1.000 EA
36CB4518 36 LIPPED CB LID PRIMED 1.000 EA
37GS3010SP 1/16"WHITE LID GASKET 1.000 EA
59XW0832S07 TAPTITE II,HEX WSHR UNSLTD SER,410 S.S., 4.000 EA
HW2502D13 SS KEY, 3/16 SQ X 1.375 1.000 EA
Page 5 of 10
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
MJ5001A27 32220KN GRAY SEALER *MIN BUY 4 QTS=1GAL 0.001 QT
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1164 LABEL,WARNING AND DRAIN 1.000 EA
HW3200A01 3/8-16X3/4 I-BLT WELDED F/S 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1025Z02 ACTIVATOR WILKOFAST 060.02HF 0.010 GA
MG1025W01 WILKOFAST, 781.01, SIGNAL WHITE #9003 0.022 GA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
HA3101S28 THRUBOLT- 1/4-20 X 12.50 SS 4.000 EA
LC0005 CONN.DIA.,TY M,9-LD,DUAL VOLT,REVERSING 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
NP1669L SS WD SUPER-E UL CSA-EEV PREM REV MTG 1.000 EA
36PA1001 PKG GRP, PRINT PK1017A06 1.000 EA
FE-0000001 ZRTG FE ASSEMBLY 1.000 EA
Page 6 of 10
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
AC Induction Motor Performance Data
Record # 35063 - Typical performance - not guaranteed values
Winding: 36WGS268-R016 Type: 3642M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 5 Full Load Torque 14.9 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 13.4/6.7 Breakdown Torque 52.2 LB-FT
R.P.M. 1750 Pull-up Torque 31.5 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 34.9 LB-FT
NEMA Design Code B KVA Code J Starting Current 49.1 A
Service Factor (S.F.) 1.15 No-load Current 3.24 A
NEMA Nom. Eff. 89.5 Power Factor 78 LinelineRes.@25ºC 2.27Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 71°C
S.F. Amps Temp. Rise @ S.F. Load 87°C
Locked-rotor Power Factor 39.8
Rotor inertia 0.391 LB-FT2
Load Characteristics 460 V, 60 Hz, 5 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 39 60 72 78 83 83 81
Efficiency 85 89.7 90.6 89.6 88.6 87 89
Speed 1789 1776 1762 1750 1733 1714 1740
Line amperes 3.55 4.31 5.43 6.65 7.94 9.64 7.42
Page 7 of 10
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Performance Graph at 460V, 60Hz, 5.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Page 9 of 10
Product Information Packet: JMEWDM3615T - 5HP,1750RPM,3PH,60HZ,184JM,3642M,TEFC,F1
Page 10 of 10
