Product Information Packet
JL3501A
.33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: JL3501A - .33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
Part Detail
Revision: AB Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 34WG5597 CD Diagram: CD0094 Mfg Plant:
Mech. Spec: 34-3099 Layout: 34LY3099 Poles: 04 Created Date:
Base: N Eff. Date: 05-22-2018 Leads: 5#18
Specs
Catalog Number: JL3501A
Enclosure: TEFC
Frame: 56J
Frame Material: Steel
Output @ Frequency: .330 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ
115.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: No Mounting
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Inverter Code: Not Inverter
KVA Code: L
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 5 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3414L
Mounting Arrangement: F1
Power Factor: 60
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Ext Thread
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
Shaft Extension Location: Pulley End
Current @ Voltage: 3.000 A @ 230.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 11
Product Information Packet: JL3501A - .33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
3.600 A @ 208.0 V
6.000 A @ 115.0 V
Design Code: N
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: B
Shaft Rotation: Fixed Opposite Standard
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: Automatic Thermal Overload
Winding Thermal 1 Location: ES
Winding Thermal 2: None
Page 3 of 11
Product Information Packet: JL3501A - .33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
Nameplate NP1257L
CAT.NO. JL3501A
SPEC. 34-3099-5597
HP .33
VOLTS 115/230
AMP 6/3
RPM 1725
FRAME 56J HZ 60 PH 1
SER.F. 1.35 CODE L DES N CL B
NEMA-NOM-EFF 60 PF 60
RATING 40C AMB-CONT
CC USABLE AT 208V 3.6
DE 6203 ODE 6203
ENCL TEFC SN
SFA 6.8/3.4
Page 4 of 11
Product Information Packet: JL3501A - .33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
Parts List
Part Number Description Quantity
SA018267 SA 34-3099-5597 1.000 EA
RA014420 RA 34-3099-5597 1.000 EA
EC1189A02SP 61B2D120189NNBA ELEC CAP, 189-227MFD, 12 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
34CB3002A CB CAST W/.88 DIA HOLE 1.000 EA
34GS1029A01 GASKET, CONDUIT BOX 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 2.000 EA
34EP3102A01SP FR ENDPLATE, MACH 1.000 EA
NS2500A01 INSULATOR, AUTO THER PROT 1.000 EA
34CB4800SP CAPACITOR COVER, STAMPED PRIMED 1.000 EA
34GS3000SP GASKET, CAPACITOR BOX 1.000 EA
51XB1016A05 10-16X5/16HX WA SL SR TYB (F/S) 2.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
34EP3300A24SP PU ENDPLATE, MACH 1.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
34FN3002A01SP EXTERNAL FAN, PLASTIC, .637/.639 HUB W/ 1.000 EA
34FH4002A03SP IEC FH NO GREASER W/.88 DIA SHAFT HOLE, 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
WD4100A81 CAPLUG BPF-7/8, FOR .86-.88 HOLE 1.000 EA
34CB4517 CB LID 4 MTG HOLES .22 DIA STAMPED, FOR 1.000 EA
34GS1031A01 GASKET, FLAT CONDUIT BOX LID (LEXIDE) 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
Page 5 of 11
Product Information Packet: JL3501A - .33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
Parts List (continued)
Part Number Description Quantity
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.014 GA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
SP5056A79 MODEL 34 TYPE L STATIONARY SWITCH WITH L 1.000 EA
HA3100A12 THRUBOLT 10-32 X 7.375 4.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
LB1118 LABEL,WARNING (ROLL LABEL) 1.000 EA
LC0031 CONNECTION LABEL 1.000 EA
NP1257L ALUM UL CSA CC THERMAL REV MTG 1.000 EA
34PA1002 PKG GRP, PRINT PK1001A01 1.000 EA
PK3083 STYROFOAM PACKING CRADLE 1.000 EA
PK3088 MICROFOAM, 8"X"8 PERF. SHEETS 5,400/RL 1.000 EA
Page 6 of 11
Product Information Packet: JL3501A - .33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
Accessories
Part Number Description Multiplier
34-171 C FACE KIT A8
Page 7 of 11
Product Information Packet: JL3501A - .33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
AC Induction Motor Performance Data
Record # 6784 - Typical performance - not guaranteed values
Winding: 34WG5597-R001 Type: 3414L Enclosure: TEFC
Nameplate Data
230 V, 60 Hz:
High Voltage Connection
Rated Output (HP) .33 Full Load Torque 1 LB-FT
Volts 115/230 Start Configuration direct on line
Full Load Amps 6/3 Breakdown Torque 2.95 LB-FT
R.P.M. 1725 Pull-up Torque 2.55 LB-FT
Hz 60 Phase 1 Locked-rotor Torque 3.6 LB-FT
NEMA Design Code N KVA Code L Starting Current 13 A
Service Factor (S.F.) 1.35 No-load Current 2.6 A
NEMA Nom. Eff. 60 Power Factor 60 LinelineRes.@25ºC
6.32ΩAPh
4.93ΩBPh
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 59°C
S.F. Amps 6.8/3.4 Temp. Rise @ S.F. Load 73°C
Load Characteristics 230 V, 60 Hz, 0.33 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 31 41 52 60 67 73 71
Efficiency 33 41 52 60 61.5 61.5 61.5
Speed 1780 1760 1745 1725 1705 1680 1690
Line amperes 2.6 2.7 2.8 3 3.3 3.7 3.4
Page 8 of 11
Product Information Packet: JL3501A - .33HP,1725RPM,1PH,60HZ,56J,3414L,TEFC,F1
Performance Graph at 230V, 60Hz, 0.33HP Typical performance - Not guaranteed values
