Product Information Packet
IDNM2237T
7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Part Detail
Revision: F Status: PRD/A Change #: Proprietary: No Type: AC Elec. Spec: 09WGT341 CD Diagram: CD0005 Mfg Plant: Mech. Spec: 09F278 Layout: 09LYF278 Poles: 04 Created Date: 06-03-2016 Base: RG Eff. Date: 03-09-2020 Leads: 9#12
Specs
Catalog Number: IDNM2237T Enclosure: TENV Frame: 254TC Frame Material: Iron Output @ Frequency: 7.500 HP @ 60 HZ Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ XP Class and Group: None XP Division: Not Applicable Agency Approvals: CSA
UR Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: Rigid Bearing Grease Type: Polyrex EM (-20F +300F) Blower: None
Insulation Class: H Inverter Code: Inverter Duty IP Rating: NONE KVA Code: H Lifting Lugs: Standard Lifting Lugs Locked Bearing Indicator: Locked Bearing Motor Lead Quantity/Wire Size: 9 @ 12 AWG Motor Lead Termination: Flying Leads Motor Type: 0932M Mounting Arrangement: F1 Power Factor: 81 Product Family: General Purpose Pulley End Bearing Type: Ball Pulley Face Code: C-Face Pulley Shaft Indicator: Standard Rodent Screen: None Shaft Ground Indicator: No Shaft Grounding
Current @ Voltage: 18.200 A @ 230.0 V
Shaft Rotation: Reversible
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
9.100 A @ 460.0 V Design Code: A Drip Cover: No Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Shaft Indicator: None Heater Indicator: No Heater
Shaft Slinger Indicator: Shaft Slinger Speed Code: Single Speed Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: Normally Closed Thermostat Vibration Sensor Indicator: No Vibration Sensor Winding Thermal 1: None Winding Thermal 2: None
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Nameplate NP1163L
CAT NO IDNM2237T
SPEC. 09F278T341G1
FRAME 254TC HP 7.5 TE
VOLTS 230/460
MAG CUR 7.8/3.9 FLA 18.2/9.1
RPM 1765 RPM MAX 5000
HZ 60 PH 3 CLASS H
SER.F. 1.00 DES A SL HZ 1.2
NEMA-NOM-EFF 91.7 WK2 1.4
BLWR V PH HZ A RATING 40C AMB-CONT DE BRG 6309 ODE BRG 6208
CC 010A SN
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Parts List
Part Number Description Quantity SA321559 SA 09F278T341G1 1.000 EA RA309336 RA 09F278T341G1 1.000 EA HW1002A63 0ASHER, 5/8 HI-COLLAR SPRLCKWASHER 1.000 EA 09CB3002SP CB W/1.38 LEAD HOLE FOR 37, 39, 307 & 30 1.000 EA 09GS1000SP GASKET-CONDUIT BOX, 1/16 THICK LEXIDE 1.000 EA 10XN2520K12 1/4-20 X.75 GRD 5 2.000 EA HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 2.000 EA WD1000B16 T&B CX70TN OR L70P TERMINAL LUG 1.000 EA 59XW2520G07 .25-20X.44,HEX SER WSHR,TAPTITE 2,GREEN 1.000 EA 09EP1100A119 FREP TEBC/TENV W/THRU SHAFT ENCODER DESI 1.000 EA 10XN2520K12 1/4-20 X.75 GRD 5 1.000 EA HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 1.000 EA XY3816A12 3/8-16 FINISHED NUT 4.000 EA HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA HW5100A08 W3118-035 WVY WSHR (WB) 1.000 EA 10XN2520K28 1/4-20 X 1.75" HX HD SCRWGRADE 5, ZINC P 2.000 EA HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 2.000 EA 10XN2520K36 1/4-20 X 2.25" HX HD SCRWGRADE 5, ZINC P 4.000 EA HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 4.000 EA 09EP1300A12 ENDPLATE, MACH 1.000 EA HW4600B44 V-RING SLINGER 1.500 X 1.810 X .28 VITON 1.000 EA HA3113A03 THRUBOLT 3/8-16 X 14.125 4.000 EA HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA HA6881 BEI HS35 THRU SHAFT ENCODER PROTECTIVE C 1.000 EA
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Parts List (continued)
Part Number Description Quantity 10XN3816K12 3/8-16 X 3/4 HEX HD CAP GRADE 5 3.000 EA HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 3.000 EA 09CB3501SP CONDUIT BOX LID FOR 09CB3001 & 09CB3002 1.000 EA 09GS1013SP 09 GS FOR 09CB3501 LID - LEXIDE 1.000 EA 51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA HW2501G25 KEY, 3/8 SQ X 2.875 1.000 EA LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA HW4500A03 GREASE FITTING, .125 NPT 1610(ALEMITE) 8 1.000 EA HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA HA4054 SHORT T-DRAIN FITTING, .125" N.P.T. 1.000 EA HA4051A00 PLASTIC CAP FOR GREASE FITTING 1.000 EA MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.080 LB HW4500A03 GREASE FITTING, .125 NPT 1610(ALEMITE) 8 1.000 EA HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA HA4054 SHORT T-DRAIN FITTING, .125" N.P.T. 1.000 EA HA4051A00 PLASTIC CAP FOR GREASE FITTING 1.000 EA MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.050 GA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA LC0005E02 SPL CONN.DIA./WARN.LABEL(LC0005/LB1119) 1.000 EA NP1163L ALUM INV UL CSA CC 1.000 EA 09PA1000 PACKAGING GROUP COMBINED PRINT 1.000 EA MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
AC Induction Motor Performance Data
Record # 59511 - Typical performance - not guaranteed values
Winding: 09WGT341-R001 Type: 0932M Enclosure: TENV
Nameplate Data
460 V, 60 Hz:
High Voltage Connection Rated Output (HP) 7.5 Full Load Torque 22.1 LB-FT Volts 230/460 Start Configuration direct on line Full Load Amps 18.2/9.1 Breakdown Torque 79.6 LB-FT R.P.M. 1765 Pull-up Torque 32.9 LB-FT Hz 60 Phase 3 Locked-rotor Torque 42.5 LB-FT NEMA Design Code A KVA Code H Starting Current 66.3 A Service Factor (S.F.) 1 No-load Current 3.97 A NEMA Nom. Eff. 91.7 Power Factor 81 LinelineRes.@25ºC 1.2929Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 70°C
Locked-rotor Power Factor 35.7
Load Characteristics 460 V, 60 Hz, 7.5 HP
% of Rated Load 25 50 75 100 125 150 Power Factor 44 67 78 83 86 87 Efficiency 87 91.6 92.4 92.2 91.5 90.4 Speed 1792.1 1784.8 1776.6 1768.3 1758.8 1747.9 Line amperes 4.5 5.7 7.35 9.12 11.2 13.5
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Performance Graph at 460V, 60Hz, 7.5HP Typical performance - Not guaranteed values
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
1 625 1 624
8 25
8 25
10 00 4 75
75
11 50
2 86
10 36
(920-956) = 24 11
3 75
25
9 09
8 500 8 497
SLINGER
38 KEY
2 88 LONG
AUTO DRAIN (EA END)
8 HOLES
53
NAMEPLATE
5 00 5 00
11 50
5 75 8 18
6 25 6 19
45° 45°
12 88
12 94
10 18 6 63
2 70
LEAD
HOLE
1 38
4 HOLES
50 - 13 TAP
ON
7 25 B C
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
09LYF278
B
HORZ TENV 254-6TC INV. W/THRU SH ENCODER DESIGN & COVER
REV. DESC
REV
BY
REVISED
MODEL NO.
VERSION
TDR
REF
09LYF278
PACKAGE 46 - LOAD SWD DWG FROM 2D TO 3D
ENALEM0
F
10 21 44 02/24/2020
-
000001133293
04
09LYF278
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Page 10 of 11
Product Information Packet: IDNM2237T - 7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Marketing maintained PDF of MN416:
http://www.baldor.com/support/Literature/Load.ashx/MN416?ManNumber=MN416
Page 11 of 11
