Product Information Packet
IDM3584T
1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
Part Detail
Revision: P Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 05WGX008 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 05E535 Layout: 05LYE535 Poles: 04 Created Date: 03-05-2008
Base: RG Eff. Date: 06-26-2019 Leads: 9#18
Specs
Catalog Number: IDM3584T
Enclosure: TEBC
Frame: 145TC
Frame Material: Iron
Output @ Frequency: 1.500 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: BLOWER
Insulation Class: H
Inverter Code: Inverter Duty
KVA Code: L
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 0530M
Mounting Arrangement: F1
Power Factor: 76
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Current @ Voltage: 2.100 A @ 460.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 10
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
4.200 A @ 230.0 V
4.600 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Encoder/Feedback Device
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Rotation: Reversible
Shaft Slinger Indicator: Shaft Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Normally Closed Thermostat
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
Nameplate NP1162L
CAT NO IDM3584T
SPEC. 05E535X008G1
FRAME 145TC HP 1.5 TE
VOLTS 230/460
MAG CUR 2.4/1.2 FLA 4.2/2.1
RPM 1760 RPM MAX 6000
HZ 60 PH 3 CLASS H
SER.F. 1.00 DES B SL HZ 1.3
NEMA-NOM-EFF 88.5 WK2 0.18
BLWR V 115 PH 1 HZ 60 A .5
RATING 40C AMB-CONT
DE BRG 6205 ODE BRG 6203
CC 010A SN
Page 4 of 10
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
Parts List
Part Number Description Quantity
SA169124 SA 05E535X008G1 1.000 EA
RA157407 RA 05E535X008G1 1.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
HW3201A05 3/8-16 EYEBOLT 1.000 EA
WD1000B16 T&B CX70TN OR L70P TERMINAL LUG 1.000 EA
10XN2520A06 1/4 20X3/8 HX HD CAP 2.000 EA
06CB3000 BALDOR CONDUIT BOX CAST 1.000 EA
06GS1000 GASKET,CONDUIT BOX 1.000 EA
51XW2520A12 SCREW, HEX SER SLT HD, ZN, 1/4-20 X .75 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
35EP1100B21 FRONT TEBC 203 BRG W/ GREASER & THRU-SHA 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP1329A01 PU EP ENCL 143-5TC 205 BRG W/GRSR & STD 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
HA3100A28 THRUBOLT 10-32 X 8.187 4.000 EA
10XN2520A08 1/4-20X1/2 HEX HEAD CAP 1.000 EA
HA3218A04 MALE-FEMALE STANDOFF .25-.20 .38 HEX 3.000 EA
10XN2520A04 1/4-20 X 1/4 HEX HD MACH SCREW 3.000 EA
HW1003A25 WASHER, 1/4 EX TH LK, ZN X 3.000 EA
06CB3500 BALDOR CONDUIT BOX LID 1.000 EA
06GS1001 BALDOR CONDUIT BOX GASKET 1.000 EA
Page 5 of 10
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
Parts List (continued)
Part Number Description Quantity
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
HA1005A05SP SLINGER, OD 1.50, ID .659, 203 BRG 1.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
MJ5004A05 #242-21 LOCTITE GENERAL PURPOSE MED. STR 0.005 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1009N LABEL,ROTATION DIRECTION (ON ROLLS) 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
05FH5001A03 BLOWER KIT,05FH4002,EF0008,35CB3002 1.000 EA
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.022 GA
LC0035B01 1PH, SV, FIX, 2 LEAD 1.000 EA
LB1119N WARNING LABEL 1.000 EA
LC0145B01 CONNECTION LABEL 1.000 EA
NP1162L SS INV UL CSA CC 1.000 EA
G7PA1000 PKG GRP, PRINT PK1034A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
Load Characteristics at 460 Volts, 60 Hz, 1.5 HP
AC Induction Motor Performance Data
Record # 36453
Typical performance - not guaranteed values
Winding: 05WGX008 Type: 0530M Enclosure: TEBC
Nameplate Data
General Characteristics at 460 V, 60 Hz:
High Volt Connection
Rated Output (HP) 1.5
Full Load
Torque
4.49 LB-FT
Volts 230/460
Start
Configuration
DOL
Full Load Amps 4.2/2.1
Break Down
Torque
18.9 LB-FT
R.P.M. 1760
Pull-Up
Torque
10.1 LB-FT
Hz 60 Phase 3
Locked-rotor
Torque
13.8 LB-FT
NEMA Design
Code
B KVA Code L
Starting
Current
18 Amps
Service Factor 1
No-load
Current
1.21 Amps
NEMA Nom. Eff. 88.5 P.F. 76
Line-line Res. @ 25°C.
9.69 Ohms
Rating - Duty 40C AMB-CONT
Temp. Rise
@ Rated Load
30°C
S.F. Amps
Temp. Rise
@ S.F. Load
% of Rated
Load
25 50 75 100 125 150 S.F.
Power Factor 33 54 67 75 80 83
Efficiency 78.6 86.5 88.3 89 87.9 86.7
Speed 1791 1782 1773 1761 1751 1738
Line Amperes 1.29 1.49 1.76 2.1 2.49 2.91
Baldor Electric Company Fort Smith, Arkansas
Page
1
of
1
AC Induction Motor Performance Data
2/26/2013
Page 7 of 10
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
Catalog IDM3584T NP VOLTS 230/460 ENCLOSURE TEBC
FRAME 145TC NP AMPS 4.2/2.1 Base Volts 460 R1 4.750 X1 9.269
HP 1.5 HP DUTY Cont Base AMPS 2.1 R2 2.890 X2 8.117
BASE SPEED 1800 MAX SAFE RPM 6000 Slip Hz 1.30 XM 224.937
PHASE/HZ 3/60
AMB
0
C/INSUL
40/F
WK
2
(lb-ft
2
)
0.177
Remarks: Calculated Data
DR BY ENR
CK BY
APP BY ENR
DATE
2/26/2013
ISSUE DATE
WYE CONN EQ CKT OHMS PER PHASE (BASE RATING, 20C)
A-C MOTOR
PERFORMANCE CURVES
05E535X008G1
2/26/2013
Rated Torque
PeakTorque
Amps
Base
Maximum Rating
Horsepower
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
0.00
2.00
4.00
6.00
8.00
10.00
12.00
14.00
16.00
18.00
20.00
0 1000 2000 3000 4000 5000 6000
Horsepower & Amps
Torque (Lb-Ft)
Speed (RPM)
Page 8 of 10
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
10.37
6.63
7.49
5.19
2.75
2.75
6.37
45°
45°
3.50
-
.06
+
.00
2.05
LEAD HOLE
1.09 DIA.
4 HOLES
.38-16 TAP ON
5.88 DIA. B.C.
2.75
4.500
4.497
.13
2.13
6.48
5.88
.8750
.8745
5.00
4.00
4.00
11.58
19.08
.12
9.98
GREASE FITTING
(EACH END)
8 HOLES
.38 DIA.
.19 KEY
1.38 LONG
(510-535)
SLINGER
LEAD HOLE
.88 DIA.
MILITARY CONNECTOR
(VECTOR MOTORS ONLY)
CONNECTION LABEL
(FAN LEADS)
LB1009
CCW FAN
ROTATION
GRD LUG
(THIS SIDE ONLY)
AUX NP
(WHEN REQ'D)
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
05LYE535
000001107505
05LYE535
0122 27 0507 2019
C
ENBILT0
05SF1100A11 WAS A01 PAM PART CONSOLIDAT ON
05LYE535
REF
TDR
VERSION
MODEL NO
REVISED
BY
REV
REV DESC
STD HORZ 143 5TC TEBC 05M STD "BA" INV VEC (THRU-SHAFT ENC)
BALDOR ELECTRIC Co.
D
02
Page 9 of 10
Product Information Packet: IDM3584T - 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC
