Product Information Packet
IDCSWDM3710T
7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Part Detail
Revision: Z Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 37WGT864 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 37H885 Layout: 37LYH885 Poles: 04 Created Date: 10-25-2006
Base: RG Eff. Date: 07-18-2019 Leads: 9#14
Specs
Catalog Number: IDCSWDM3710T
Enclosure: TEFC
Frame: 213TC
Frame Material: Stainless Steel
Output @ Frequency: 7.500 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Inverter Code: Inverter Duty
KVA Code: J
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 14 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3740M
Mounting Arrangement: F1
Power Factor: 81
Product Family: Wash Down Paint Free
Pulley End Bearing Type: Sealed Bearing
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
Shaft Extension Location: Pulley End
Current @ Voltage: 19.000 A @ 230.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 10
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
9.500 A @ 460.0 V
Design Code: A
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: H
Shaft Rotation: Reversible
Shaft Slinger Indicator: Shaft Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Normally Closed Thermostat
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Nameplate NP1608L
CAT NO IDCSWDM3710T
SPEC. 37H885T864G1
FRAME 213TC HP 7.5 TE
VOLTS 230/460
MAG CUR 8.8/4.4 FLA 19/9.5
RPM 1770 RPM MAX 6000
HZ 60 PH 3 CLASS H
SER.F. 1.00 DES A SL HZ 1
NEMA-NOM-EFF 91.7 WK2 0.98
BLWR V PH HZ A
RATING 40C AMB-CONT
DE BRG 6307 ODE BRG 6206
CC 010A SN
Page 4 of 10
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Parts List
Part Number Description Quantity
SA151215 SA 37H885T864G1 1.000 EA
RA140041 RA 37H885T864G1 1.000 EA
37FN3002B01 EXFN, PLASTIC, 7.50 OD, 1.155 ID 1.000 EA
HW3200S01 EYEBOLT 3/8-16 X3/4 S.S. TDR #35988 1.000 EA
37CB3000A40MU K.O. BOX-MODEL 37 NEMA 213-5 .75 NPT LEA 1.000 EA
37GS1025 37 MOLDED GASKET W/LIP, LEAD SEAL 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
HA5027A04 HA4054 T-DRAIN X2 BAGGED 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
37EP3101A49MU FR EP 37 L & M TEFC (FOR S.P. #9D) 1.000 EA
HW4500A33 1/8 NPT STAINLESS,HOLO-KROME #13002,PRES 3.000 EA
HW5100A06 W2420-025 WVY WSHR (WB) 1.000 EA
37EP3300A25MU FACE MT EP-ENCL-307 BRG-213TC-215TC NO G 1.000 EA
HW4500A33 1/8 NPT STAINLESS,HOLO-KROME #13002,PRES 3.000 EA
HW4606A04 JM CLIPPER/SEAL (LWE-1376-2125-AL45) 1.000 EA
10XN2520S30 1/4-20 X 1 7/8 HEX HEAD SS 4.000 EA
XY3118S12 5/16-18 HEX NUT, STAINLESS STEEL 4.000 EA
51XB1214A20 12-14X1.25 HXWSSLD SERTYB 1.000 EA
37FH4000A45 STAINLESS FAN COVER, NO GREASER SLOT (FO 1.000 EA
11XW1032S06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 3.000 EA
36CB4517 LIPPED CB LID #304 STAINLESS - CLEANED 1.000 EA
37GS3010SP 1/16"WHITE LID GASKET 1.000 EA
59XW0832S07 TAPTITE II,HEX WSHR UNSLTD SER,410 S.S., 4.000 EA
Page 5 of 10
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Parts List (continued)
Part Number Description Quantity
HW4600B74 V-RING SLINGER 1.125 X 1.445 X .24 VITON 1.000 EA
HW2502F21 #303 SS,SQ KEY 5/16 X 2.375 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
MJ5001A02 732 CL SEALANT 3 OZ DIXIE BEARING 289100 0.001 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
LB1164 LABEL,WARNING AND DRAIN 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
HA3104S17 THRUBOLT 13.250LG SS 4.000 EA
LC0145B01 CONNECTION LABEL 1.000 EA
NP1608L SS WD INV UL CSA CC REV MTG 1.000 EA
G0PA1000 PKG GRP, PRINT PK1026A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Load Characteristics at 460 Volts, 60 Hz, 7.5 HP
AC Induction Motor Performance Data
Record # 37140
Typical performance - not guaranteed values
Winding: 37WGT864 Type: 3739M Enclosure: TEFC
Nameplate Data
General Characteristics at 460 V, 60 Hz:
High Volt Connection
Rated Output (HP) 7.5
Full Load
Torque
22.3 LB-FT
Volts 230/460
Start
Configuration
DOL
Full Load Amps 19/9.5
Break Down
Torque
71.3 LB-FT
R.P.M. 1770
Pull-Up
Torque
38.7 LB-FT
Hz 60 Phase 3
Locked-rotor
Torque
46.5 LB-FT
NEMA Design
Code
A KVA Code J
Starting
Current
73 Amps
Service Factor 1
No-load
Current
4.3 Amps
NEMA Nom. Eff. 91.7 P.F. 81
Line-line Res. @ 25°C.
1.34 Ohms
Rating - Duty 40C AMB-CONT
Temp. Rise
@ Rated Load
69°C
S.F. Amps
Temp. Rise
@ S.F. Load
% of Rated
Load
25 50 75 100 125 150 S.F.
Power Factor 42 65 75 81 83 85
Efficiency 86.9 91.1 92.1 91.7 90.8 89.7
Speed 1793 1786 1778 1770 1760 1750
Line Amperes 4.8 5.95 7.62 9.47 11.6 13.9
Baldor Electric Company Fort Smith, Arkansas
Page
1
of
1
AC Induction Motor Performance Data
3/6/2013
Page 7 of 10
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Catalog IDCSWDM3710T NP VOLTS
230/460
ENCLOSURE TEFC
FRAME 213TC NP AMPS
19/9.5
Base Volts
460 R1 0.633 X1 2.477
HP 7.5 HP DUTY Cont Base AMPS 9.47 R2 0.402 X2 1.907
BASE SPEED 1800 MAX SAFE RPM 6000 Slip Hz 1.00 XM 57.989
PHASE/HZ 3/60
AMB
0
C/INSUL
40/H
WK
2
(lb-ft
2
)
0.959
Remarks: Calculated Data
DR BY ENR
CK BY
APP BY ENR
DATE
3/6/2013
ISSUE DATE
WYE CONN EQ CKT OHMS PER PHASE (BASE RATING, 20C)
A-C MOTOR
PERFORMANCE CURVES
37H885T864G1
3/6/2013
Rated Torque
PeakTorque
Amps
Base
Horsepower
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
0.00
10.00
20.00
30.00
40.00
50.00
60.00
70.00
80.00
0 1000 2000 3000 4000 5000
Horsepower & Amps
Torque (Lb-Ft)
Speed (RPM)
Page 8 of 10
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Page 9 of 10
Product Information Packet: IDCSWDM3710T - 7.5HP,1770RPM,3PH,60HZ,213TC,3740M,TEFC
Page 10 of 10
