Baldor HFM3313T Product Information Sheet

Product Information Packet

HFM3313T

10HP,1765RPM,3PH,60HZ,215T,3733M,OPSB,F2

Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.

Product Information Packet: HFM3313T - 10HP,1765RPM,3PH,60HZ,215T,3733M,OPSB,F2

Part Detail

Revision: E Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 37WGS131 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 37L724 Layout: 37LYL724 Poles: 04 Created Date: 10-05-2006
Base: RG Eff. Date: 01-14-2010 Leads: 9#14

Specs

Catalog Number: HFM3313T
Enclosure: ODP
Frame: 215T
Output @ Frequency: 10.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 208.0 V @ 60 HZ

230.0 V @ 60 HZ

460.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: UR

CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 13.400 A @ 460.0 V

Heater Indicator: No Heater
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: J
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 14 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3733M
Mounting Arrangement: F2
Power Factor: 78
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None

26.800 A @ 230.0 V

Shaft Extension Location: Pulley End

Page 2 of 10

Product Information Packet: HFM3313T - 10HP,1765RPM,3PH,60HZ,215T,3733M,OPSB,F2

29.000 A @ 208.0 V
Design Code: A
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None

Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor

Page 3 of 10
