Product Information Packet |
|||
|
|
|
EMM10034-PP |
|||
|
|
|
M3BP 100LKB 4P B3 3KW |
|||
|
|
|
|
|
|
|
|
Specs |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Catalog Number: |
EMM10034-PP |
|
|
|
|
|
|
|
|
|
|
|
|
Enclosure: |
TEFC |
|
|
|
|
|
|
|
|
|
|
|
|
Frame: |
|
100 |
|
|
|
|
|
|
|
|
|
|
|
Output @ Frequency: |
3.00 KW @ 50 HZ |
|
|
|
|
|
|
|
|
|
|
|
|
Synchronous Speed @ Frequency: |
1500 RPM @ 50 HZ |
|
|
|
|
|
|
|
|
|
|
|
|
Voltage @ Frequency: |
230 V @ 50 HZ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
380 V @ 50 HZ |
|
|
|
|
|
|
|
|
|
|
|
|
|
400 V @ 50 HZ |
|
|
|
|
|
|
|
|
|
|
|
Auxillary Box: |
D-End Top |
|
|
|
|
|
|
|
|
|
|
|
|
CE: |
Copyright © All product information |
CE |
|
Motors and Mechanical Inc. copyright © |
protection, unless otherwise noted. |
|
|
within this document is subject to ABB |
|
Product Information Packet: EMM10034-PP - M3BP 100LKB 4P B3 3KW
Current @ Voltage: |
10.10 A @ 230 V |
|
|
|
5.80 A @ 400 V |
|
|
|
6.10 A @ 380 V |
|
|
Duty Rating: |
S1 |
|
|
Insulation Class: |
F |
|
|
IP Rating: |
IP55 |
|
|
PTC Thermistor Conn Diagram: |
3GZF321200-1D |
|
|
Speed Code: |
Single Speed |
|
|
Motor Standards: |
IEC |
|
|
