Product Information Packet
EM7036T
3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Part Detail
Revision: J Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 37WGS519 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 37H239 Layout: 37LYH239 Poles: 06 Created Date: 06-21-2010
Base: RG Eff. Date: 07-18-2019 Leads: 9#14
Specs
Catalog Number: EM7036T
Enclosure: XPFC
Frame: 213T
Frame Material: Steel
Output @ Frequency: 3.000 HP @ 60 HZ
2.000 HP @ 50 HZ
Synchronous Speed @ Frequency: 1200 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
190.0 V @ 50 HZ
230.0 V @ 60 HZ
380.0 V @ 50 HZ
XP Class and Group: CLI GP D; CLII GP F,G
XP Division: Division I
Agency Approvals: UL
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: L
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 14 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: X3738M
Mounting Arrangement: F1
Power Factor: 68
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Base Indicator: Rigid
Rodent Screen: None
Page 2 of 10
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 4.000 A @ 380.0 V
4.600 A @ 460.0 V
8.000 A @ 190.0 V
9.200 A @ 230.0 V
9.600 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
RoHS Status: ROHS COMPLIANT
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Normally Closed Thermostat
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
XP Temp Code: T3C
Page 3 of 10
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Nameplate NP1426XPSLEV
NO. CC 010A
SER.
SPEC. 37H239S519G1
CAT.NO. EM7036T
HP 3//2 T. CODE T3C
VOLTS 230/460//190/380
AMPS 9.2/4.6//8/4
RPM 1160//960
HZ 60//50 PH 3 CL B
SER.F. 1.00 DES B CODE L
RATING 40C AMB-CONT
FRAME 213T NEMA-NOM-EFF 89.5
USABLE AT 208V 9.6 PF 68
BLANK
Page 4 of 10
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Parts List
Part Number Description Quantity
SA199226 SA 37H239S519G1 1.000 EA
RA186564 RA 37H239S519G1 1.000 EA
37FN3002C01 EXFN, PLASTIC, 6.00 OD, 1.155 ID 1.000 EA
35CB3001A02SP EXPL PROOF CONDUIT BOX, 3/4"PIPE TAP LEA 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
37EP1102A01 STD FR EP, XPFC 1.000 EA
HW4500A19 1/4-28X1/4 SLOTTED PLUG F/S 2.000 EA
HW5100A06 W2420-025 WVY WSHR (WB) 1.000 EA
37EP1701A02 PU ENDPLATE,TEFC, 1 FAN, W/GREASER, MACH 1.000 EA
HW4500A19 1/4-28X1/4 SLOTTED PLUG F/S 2.000 EA
XY5013A12 NUT,1/2-13,HEX,STEEL,ZINCPLATED 4.000 EA
37FH3001 FAN COVER, DIE CAST 1.000 EA
10XN2520A12 1/4-20 X 3/4 HEX HEAD CAP 4.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 4.000 EA
35CB3500A01SP CONDUIT BOX LID, MACH 1.000 EA
51XN2520A16 SCREW, HEX WS SLT, ZN, 1/4-20 X 1.00 4.000 EA
HW2501F21 KEY, 5/16 SQ X 2.375 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 6.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
NP0018F ALUM UL XP CONDUIT BOX NAMEPLATE 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
51XB1214A20 12-14X1.25 HXWSSLD SERTYB 1.000 EA
Page 5 of 10
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Parts List (continued)
Part Number Description Quantity
XY2520A12 1/4-20 HEX NUT, DIRECTIONAL SERRATIONS 1.000 EA
MG1025G29 WILKOFAST, 789.229, DARK CHARCOAL GRAY 0.028 GA
HA3106A04 THRUBOLT- 1/2-13 X 12.625 4.000 EA
LB1119N WARNING LABEL 1.000 EA
LC0145B01 CONNECTION LABEL 1.000 EA
NP1426XPSLEV SS XP UL CSA-EEV CC CL-I GP-D 1.000 EA
37PA1039 PALLET PACK GRP, PRINT PK1026A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
AC Induction Motor Performance Data
Record # 35765 - Typical performance - not guaranteed values
Winding: 37WGS519-R004 Type: 3738M Enclosure: XPFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 3//2 Full Load Torque 13.4 LB-FT
Volts 230/460//190/380 Start Configuration direct on line
Full Load Amps 9.2/4.6//8/4 Breakdown Torque 50.4 LB-FT
R.P.M. 1160//960 Pull-up Torque 31.8 LB-FT
Hz 60//50 Phase 3 Locked-rotor Torque 33.9 LB-FT
NEMA Design Code B KVA Code L Starting Current 34 A
Service Factor (S.F.) 1 No-load Current 2.56 A
NEMA Nom. Eff. 89.5 Power Factor 68 LinelineRes.@25ºC 2.67Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 38°C
Locked-rotor Power Factor 22.9
Rotor inertia 0.945 LB-FT2
Load Characteristics 460 V, 60 Hz, 3 HP
% of Rated Load 25 50 75 100 125 150
Power Factor 30 50 62 69 73 75
Efficiency 82.1 88.6 89.5 89.8 89.1 87.6
Speed 1193 1186 1178 1170 1160 1149
Line amperes 2.74 3.19 3.82 4.53 5.44 6.41
Page 7 of 10
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Performance Graph at 460V, 60Hz, 3.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Page 9 of 10
Product Information Packet: EM7036T - 3//2HP,1160//960RPM,3PH,60//50HZ,213T,37
Page 10 of 10
