Baldor EM4316T-12 Product Information Sheet
Product Information Packet
EM4316T-12
75HP,1780RPM,3PH,60HZ,365T,A36070M,TEFC
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: EM4316T-12 - 75HP,1780RPM,3PH,60HZ,365T,A36070M,TEFC
Part Detail
Revision: |
R |
Status: |
PRD/A |
Change #: |
|
Proprietary: |
No |
|
|
|
|
|
|
|
|
Type: |
AC |
Elec. Spec: |
A36WG1521 |
CD Diagram: |
416820-020 |
Mfg Plant: |
|
|
|
|
|
|
|
|
|
Mech. Spec: |
|
Layout: |
617428-012 |
Poles: |
04 |
Created Date: |
12-17-2010 |
|
|
|
|
|
|
|
|
Base: |
|
Eff. Date: |
04-24-2020 |
Leads: |
12#6 |
|
|
|
|
|
|
|
|
|
|
Specs
Catalog Number: |
EM4316T-12 |
|
|
Enclosure: |
TEFC |
|
|
Frame: |
365T |
|
|
Frame Material: |
Iron |
|
|
Output @ Frequency: |
75.000 HP @ 60 HZ |
|
|
Synchronous Speed @ Frequency: |
1800 RPM @ 60 HZ |
|
|
Voltage @ Frequency: |
230.0 V @ 60 HZ |
|
|
|
460.0 V @ 60 HZ |
|
|
XP Class and Group: |
None |
|
|
XP Division: |
Not Applicable |
|
|
Agency Approvals: |
CCSA US |
|
|
|
CSA EEV |
|
|
Auxillary Box: |
No Auxillary Box |
|
|
Base Indicator: |
Rigid |
|
|
Bearing Grease Type: |
Polyrex EM (-20F +300F) |
|
|
Current @ Voltage: |
171.000 A @ 230.0 V |
|
|
|
85.900 A @ 460.0 V |
|
|
Design Code: |
B |
|
|
Feedback Device: |
NO FEEDBACK |
|
|
Heater Indicator: |
No Heater |
|
|
Insulation Class: |
F |
|
|
Inverter Code: |
Inverter Ready |
|
|
KVA Code: |
G |
|
|
Lifting Lugs: |
No Lifting Lugs |
|
|
Motor Lead Quantity/Wire Size: |
12 @ 6 AWG |
|
|
Motor Type: |
A36070M |
|
|
Mounting Arrangement: |
F1 |
|
|
Power Factor: |
86 |
|
|
Product Family: |
Other |
|
|
Pulley End Bearing Type: |
Ball |
|
|
Pulley Face Code: |
Standard |
|
|
Shaft Ground Indicator: |
No Shaft Grounding |
|
|
Shaft Rotation: |
Reversible |
|
|
Shaft Slinger Indicator: |
No Slinger |
|
|
Speed Code: |
Single Speed |
|
|
Motor Standards: |
NEMA |
|
|
of 11 2
Page
Product Information Packet: EM4316T-12 - 75HP,1780RPM,3PH,60HZ,365T,A36070M,TEFC
Drip Cover: |
No Drip Cover |
|
|
Duty Rating: |
CONT |
|
|
Starting Method: |
Wye Start - Delta Run |
|
|
Thermal Device - Bearing: |
None |
|
|
Thermal Device - Winding: |
None |
|
|
of 11 3
Page
Product Information Packet: EM4316T-12 - 75HP,1780RPM,3PH,60HZ,365T,A36070M,TEFC
Nameplate NP2383L
CAT.NO. |
EM4316T-12 |
|
|
|
|
|
|
|
|
|
|
SPEC NO. |
P36G3433 |
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
HP |
75 |
|
AMPS |
172/85.9 |
|
|
|
|
|
|
|
|
VOLTS |
230/460 |
|
|
|
|
DESIGN B |
|
|
|
|||||||||
FRAME |
365T |
|
|
RPM |
1780 |
|
|
HZ |
60 |
|
|
|
|
AMB |
40 |
|
|
SF |
1.15 |
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DRIVE END BEARING |
65BC03J30X |
|
|
|
|
|
PHASE |
3 |
|
|
|
DUTY |
CONT |
|
|
|
|
INSUL.CLASS F |
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
OPP D.E. BEARING |
65BC03J30X |
|
|
|
|
|
TYPE |
P |
|
|
ENCL |
TEFC |
|
CODE G |
|
|
|
||||||||||||||
SER.NO. |
|
|
|
|
|
|
|
POWER FACTOR |
86 |
|
|
|
|
NEMA-NOM-EFFICIENCY |
95.4 |
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MAX CORR KVAR |
16.0 |
|
GUARANTEED EFFICIENCY |
95.0 |
|||||||
NEMA NOM/CSA QUOTED EFF
MOTOR WEIGHT
of 11 4
Page
