Product Information Packet
EM3158T-8
3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: EM3158T-8 - 3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
Part Detail
Revision: H Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGN342 CD Diagram: CD0006 Mfg Plant:
Mech. Spec: 35T680 Layout: 35LYT680 Poles: 02 Created Date: 07-31-2015
Base: RG Eff. Date: 06-15-2018 Leads: 3#16
Specs
Catalog Number: EM3158T-8
Enclosure: OPSB
Frame: 145T
Frame Material: Steel
Output @ Frequency: 3.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 200.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
CSA EEV
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Inverter Code: Inverter Ready
KVA Code: K
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 3 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3530M
Mounting Arrangement: F1
Power Factor: 87
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
Shaft Extension Location: Pulley End
Current @ Voltage: 8.500 A @ 200.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 10
Product Information Packet: EM3158T-8 - 3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: B
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: EM3158T-8 - 3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
Nameplate NP3553L
CAT.NO. EM3158T-8
SPEC 35T680N342G3
HP 3
VOLTS 200
AMPS 8.5
RPM 3450
FRAME 145T HZ 60 PH 3
SF 1.15 CODE K DES B CLASS B
NEMA NOM. EFF 85.5 PF 87
RATING 40C AMB-CONT
CC 010A USABLE AT 208V
ENCL OPSB SER
DE 6205 ODE 6203
VPWM INVERTER READY
CT30-60(2:1) VT3-60(20:1)
Page 4 of 10
Product Information Packet: EM3158T-8 - 3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
Parts List
Part Number Description Quantity
SA305032 SA 35T680N342G3 1.000 EA
RA292224 RA 35T680N342G3 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
35CB3007 35 CB CASTING W/.88 DIA. LEAD HOLE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
35EP3209A00 MASTER ODE,203 BRG,GRSR 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3210A00 MASTER DE,205 BRG,1.000SH,GRSR 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
XY1032A02 10-32 HEX NUT DIRECTIONAL SERRATION 4.000 EA
35CB4521 35 LIPPED CB LID (GALV & PHOSPH) 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000Y03 MUNSELL 2.53Y 6.70/ 4.60, GLOSS 20, 0.017 GA
HA3100A23 THRUBOLT 10-32 X 10.375 4.000 EA
35AD2005A01 BAFFLE PLATE,MOD 35-SLTD BAND MTRS GL.F. 2.000 EA
LB1119N WARNING LABEL 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
NP3553L ALUM SUPER-E VPWM INVERTER READY UL CSA- 1.000 EA
Page 5 of 10
Product Information Packet: EM3158T-8 - 3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
Parts List (continued)
Part Number Description Quantity
LC0006 CONNECTION LABEL 1.000 EA
36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
FE-0000001 ZRTG FE ASSEMBLY 1.000 EA
PE-0000001 ZRTG PE ASSEMBLY 1.000 EA
Page 6 of 10
Product Information Packet: EM3158T-8 - 3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
AC Induction Motor Performance Data
Record # 52201 - Typical performance - not guaranteed values
Winding: 35WGN342-R003 Type: 3530M Enclosure: OPSB
Nameplate Data
200 V, 60 Hz:
Single Voltage Motor
Rated Output (HP) 3 Full Load Torque 4.5 LB-FT
Volts 200 Start Configuration direct on line
Full Load Amps 8.5 Breakdown Torque 17.8 LB-FT
R.P.M. 3450 Pull-up Torque 11.1 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 14.8 LB-FT
NEMA Design Code B KVA Code K Starting Current 72.1 A
Service Factor (S.F.) 1.15 No-load Current 3.33 A
NEMA Nom. Eff. 85.5 Power Factor 87 LinelineRes.@25ºC 1.03Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 32°C
S.F. Amps Temp. Rise @ S.F. Load 38°C
Locked-rotor Power Factor 55.2
Rotor inertia 0.0822 LB-FT2
Load Characteristics 200 V, 60 Hz, 3 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 52 74 84 88 91 92 90
Efficiency 77 84.5 85.9 86 85 83.3 85.4
Speed 3568 3539 3506 3473 3435 3391 3450
Line amperes 3.86 5.09 6.69 8.45 10.4 12.6 9.62
Page 7 of 10
Product Information Packet: EM3158T-8 - 3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
Performance Graph at 200V, 60Hz, 3.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: EM3158T-8 - 3HP,3450RPM,3PH,60HZ,145T,3530M,OPSB,F1
2 60
8750
8745
510-520 = 11 13
521-524 = 11 63
525-528 = 12 13
529-535 = 13 00
536-546 = 14 38
2 50
2 25
4 00 2 25
5 00 50
5 94
19 KEY
1 38 LONG
6 HOLES
Ø 38
NAMEPLATE
6 62
5 61
3 50
3 44
6 76
2 75
2 75
4 56
3 25
6 50
LEAD HOLE
Ø 88
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
35LYT680
B
HORZ 35M OPSB 143-5T 2 POLE "W" BASE (35BA4009)
SH 1 of 1
REV. DESC
REV
BY
REVISED
MODEL NO.
VERSION
TDR
REF
35LYT680
LOADING OF SWD DWG FOR 2D TO 3D CONVERSION - PKG11
ENSTEK0
D
08 58 06 12/03/2018
-
000001092572
04
35LYT680
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
