Product Information Packet
EHM9155T
60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Part Detail
Revision: F Status: INA/A Change #: Proprietary: No Type: AC Elec. Spec: 14WGX332 CD Diagram: CD0180 Mfg Plant: Mech. Spec: 14R060 Layout: 14LYR060 Poles: 04 Created Date: Base: RG Eff. Date: 08-24-2010 Leads: 9#6
Specs
Catalog Number: EHM9155T Enclosure: TEFC Frame: 364T Frame Material: Iron Output @ Frequency: 60.000 HP @ 60 HZ Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ Voltage @ Frequency: 230.0 V @ 60 HZ
460.0 V @ 60 HZ XP Division: Not Applicable Agency Approvals: UR
CSA Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: Rigid Bearing Grease Type: Polyrex EM (-20F +300F) Blower: None Current @ Voltage: 140.000 A @ 230.0 V
Insulation Class: F Inverter Code: Not Inverter KVA Code: G Lifting Lugs: Standard Lifting Lugs Locked Bearing Indicator: No Locked Bearing Motor Lead Quantity/Wire Size: 9 @ 6 AWG Motor Lead Exit: Ko Box Motor Lead Termination: Flying Leads Motor Type: 1460M Mounting Arrangement: F1 Power Factor: 86 Product Family: General Purpose Pulley End Bearing Type: Ball Pulley Face Code: Standard Pulley Shaft Indicator: Standard Rodent Screen: None Shaft Extension Location: Pulley End
70.000 A @ 460.0 V
Shaft Ground Indicator: No Shaft Grounding
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Design Code: B Drip Cover: No Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Face Code: Standard Front Shaft Indicator: None Heater Indicator: No Heater
Shaft Rotation: Reversible Shaft Slinger Indicator: No Slinger Speed Code: Single Speed Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: None Vibration Sensor Indicator: No Vibration Sensor
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Nameplate NP1371
CAT.NO. EHM9155T
SPEC. 14R060X332G1
HP 60
VOLTS 230/460
AMP 140/70 RPM 1775
FRAME 364T HZ 60 PH 3
SER.F. 1.15 CODE G DES B CLASS F
NEMA-NOM-EFF 94.1 PF 86
RATING 40C AMB-CONT
CC 010A USABLE AT 208V DE 6313 ODE 6312
ENCL TEFC SN
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Parts List
Part Number Description Quantity SA071112 SA 14R060X332G1 1.000 EA RA064974 RA 14R060X332G1 1.000 EA S/P111-000-001 S/P111-000-001 CORONA TEST 1.000 EA 10CB3002A01 CB 309 3.62 LD HOLE, .44 MTG HOLE & 3.50 1.000 EA 14GS1000SP GASKET, CONDUIT BOX 1.000 EA 10XN3816K12 3/8-16 X 3/4 HEX HD CAP GRADE 5 4.000 EA HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA WD1000B16 T&B CX70TN OR L70P TERMINAL LUG 1.000 EA 51XF2520A08 SCREW, HEX SER SLT HD, ZN 1/4-20 X .50 L 1.000 EA 14EP1102A50 FR ENDPLATE, 364-5 312 BRG, LESS RET MTG 1.000 EA 10XN5013K40 1/2-13X 2 1/2 HEX HD X 6.000 EA HW1001A50 LOCKWASHER 1/2, ZINC PLT,.879 OD, .509 I 6.000 EA HW5100A15 W4997-050 WVY WSHR (WB) 1.000 EA 14EP1703A33 PUEP MACH, 364-5T TEFC W/O BRG RET HOLES 1.000 EA 10XN5013K40 1/2-13X 2 1/2 HEX HD X 6.000 EA HW1001A50 LOCKWASHER 1/2, ZINC PLT,.879 OD, .509 I 6.000 EA HA1005A08SP 314-34 NEOPRENE SLINGER 1.000 EA 14FH1002A01 FAN HSG CAST 1.000 EA 10XN3816K24 3/8-16 X 1.50 HEX HD CAP SCREW, GRADE 5 3.000 EA HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 3.000 EA 10CB3500SP CONDUIT BOX LID, CAST 1.000 EA 10GS1000SP GASKET, CONDUIT BOX LID 1.000 EA 51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 4.000 EA HW2501J36 KEY, 5/8 SQ X 4.250 1.000 EA
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Parts List (continued)
Part Number Description Quantity LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA HW4500A35 1/8 NPT STEEL .50 HEX CAP 1.000 EA HA4017A01 1/8 X 4 GREASE EXT (F/S) 1.000 EA HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA HA4001A01SP DRAIN PLUG, PLASTIC (MICRO PLAS) 1.000 EA MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.220 LB HW4500A20 1/8NPT SL PIPE PLUG 2.000 EA HA4001A01SP DRAIN PLUG, PLASTIC (MICRO PLAS) 1.000 EA 85XU0407A04 #4-7 X 1/4 DRIVE PIN 2.000 EA MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA 09FN5001A04 STD EXT FAN ASS'Y W/09FN3001A04 1.000 EA MG1000G59 PAINT, 689.959 WILKO SILVER 0.140 GA LB1119N WARNING LABEL 1.000 EA LB1125C04 STD-E (STOCK CTN LABEL STD-E WITH FLAG) 4.000 EA LC0181 CONNECTION LABEL 1.000 EA NP1371 ALUM, HVAC, PREM EFF, UL CSA, W/O 1.000 EA 14PA1000 PACKAGING 314 GROUP COMBINED PRINT 1.000 EA LB1417 LABEL CARTON 6X4 PERFORATED BLANK ROLLS 1.000 EA
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Accessories
Part Number Description Multiplier 14-1704 C FACE KIT A8 14EP1705A01SP D-FLANGE KIT A8
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
AC Induction Motor Performance Data
Record # 4162 - Typical performance - not guaranteed values
Winding: 14WGX332-R001 Type: 1460M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection Rated Output (HP) 60 Full Load Torque 177 LB-FT Volts 230/460 Start Configuration direct on line Full Load Amps 140/70 Breakdown Torque 540 LB-FT R.P.M. 1775 Pull-up Torque 219 LB-FT Hz 60 Phase 3 Locked-rotor Torque 282 LB-FT NEMA Design Code B KVA Code G Starting Current 449 A Service Factor (S.F.) 1.15 No-load Current 22.6 A NEMA Nom. Eff. 94.1 Power Factor 86 LinelineRes.@25ºC 0.0803Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 60°C S.F. Amps Temp. Rise @ S.F. Load 79°C
Locked-rotor Power Factor 25
Rotor inertia 11.4 LB-FT2
Load Characteristics 460 V, 60 Hz, 60 HP
% of Rated Load 25 50 75 100 125 150 S.F. Power Factor 53 74 82 86 87 87 86 Efficiency 89.3 93.3 94.2 94.1 93.8 93.1 93.9 Speed 1795 1790 1785 1779 1773 1766 1775 Line amperes 29.45 40.9 54.3 69.7 86.3 104.6 79.7
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Performance Graph at 460V, 60Hz, 60.0HP Typical performance - Not guaranteed values
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Page 10 of 11
Product Information Packet: EHM9155T - 60HP,1775RPM,3PH,60HZ,364T,1460M,TEFC,F1
Page 11 of 11
