Product Information Packet
EHM9146T
30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Part Detail
Revision: J Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 10WGX121 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 10F140 Layout: 10LYF140 Poles: 04 Created Date:
Base: RG Eff. Date: 08-24-2010 Leads: 9#10
Specs
Catalog Number: EHM9146T
Enclosure: TEFC
Frame: 286T
Frame Material: Iron
Output @ Frequency: 30.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 36.000 A @ 460.0 V
Insulation Class: F
Inverter Code: Not Inverter
KVA Code: H
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 10 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 1056M
Mounting Arrangement: F1
Power Factor: 84
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
72.000 A @ 230.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 10
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Rotation: Reversible
Shaft Slinger Indicator: Shaft Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Page 3 of 10
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Nameplate NP1371
CAT.NO. EHM9146T
SPEC. 10F140X121G1
HP 30
VOLTS 230/460
AMP 72/36
RPM 1770
FRAME 286T HZ 60 PH 3
SER.F. 1.15 CODE H DES B CLASS F
NEMA-NOM-EFF 93 PF 84
RATING 40C AMB-CONT
CC 010A USABLE AT 208V
DE 6311 ODE 6309
ENCL TEFC SN
Page 4 of 10
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Parts List
Part Number Description Quantity
SA071117 SA 10F140X121G1 1.000 EA
RA064979 RA 10F140X121G1 1.000 EA
S/P111-000-001 S/P111-000-001 CORONA TEST 1.000 EA
10CB3000SP KOBX, CAST W/2.00 LEAD HOLE 1.000 EA
12GS1000 GASKET 1.000 EA
10XN3118K12 5/16-18 X .75 GRADE 5, ZINC PLATED 4.000 EA
HW1001A31 LOCKWASHER 5/16, ZINC PLT.591 OD, .319 I 4.000 EA
WD1000B16 T&B CX70TN OR L70P TERMINAL LUG 1.000 EA
51XF2520A08 SCREW, HEX SER SLT HD, ZN 1/4-20 X .50 L 1.000 EA
10EP1106A14 FREP MACH, NO RET. RING HLS, NO SH HL 1.000 EA
10XN3816K32 BOLT, 3/8-16X2 HH YZ(5) 4.000 EA
HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA
HA4017A01 1/8 X 4 GREASE EXT (F/S) 1.000 EA
HW5100A11 W3917-042 WVY WSHR (WB) 1.000 EA
10EP1105A09 ENDPLATE, SPL PU MOD 310 TEFC-311 BRG,NO 1.000 EA
10XN3816K28 3/8-16 X 1.75 HEX HD CAP SCREW, GRADE 5 4.000 EA
HW1001A38 LOCKWASHER 3/8, ZINC PLT .688 OD, .382 I 4.000 EA
HA1005A04 SLINGER, OD 3.620, ID 1.98, 1.000 EA
10FH4000 310 FAN HOUSING STAMPED 1.000 EA
10XN2520K08 1/4-20 X .50 GRADE #5, STL, ZINC PLATE 4.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 4.000 EA
10CB3500SP CONDUIT BOX LID, CAST 1.000 EA
10GS1000SP GASKET, CONDUIT BOX LID 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 4.000 EA
Page 5 of 10
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
HW2501H28 KEY, 1/2 SQ X 3.250 1.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
LB5040 INSTRUCTION TAG, AC & DC 1.000 EA
HW4500A35 1/8 NPT STEEL .50 HEX CAP 1.000 EA
HW4500A17 317400 ALEMITE GREASE RELIEF 1.000 EA
HA4001A01SP DRAIN PLUG, PLASTIC (MICRO PLAS) 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.130 LB
HW4500A20 1/8NPT SL PIPE PLUG 2.000 EA
HA4001A01SP DRAIN PLUG, PLASTIC (MICRO PLAS) 1.000 EA
85XU0407A04 #4-7 X 1/4 DRIVE PIN 2.000 EA
09FN3001C02 EXTERNAL FAN, PLASTIC 1.000 EA
HW2500A25 WOODRUFF KEY USA #1008 #BLOW CARBON STEE 1.000 EA
51XB1214A20 12-14X1.25 HXWSSLD SERTYB 1.000 EA
MG1000G59 PAINT, 689.959 WILKO SILVER 0.070 GA
LB1125C04 STD-E (STOCK CTN LABEL STD-E WITH FLAG) 4.000 EA
LC0005E02 SPL CONN.DIA./WARN.LABEL(LC0005/LB1119) 1.000 EA
NP1371 ALUM, HVAC, PREM EFF, UL CSA, W/O 1.000 EA
10PA1000 PACKAGING GROUP COMBINED PRINT PK1023A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
LB1417 LABEL CARTON 6X4 PERFORATED BLANK ROLLS 1.000 EA
Page 6 of 10
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
AC Induction Motor Performance Data
Record # 2493 - Typical performance - not guaranteed values
Winding: 10WGX121-R005 Type: 1056M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 30 Full Load Torque 89 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 72/36 Breakdown Torque 256 LB-FT
R.P.M. 1770 Pull-up Torque 124 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 152 LB-FT
NEMA Design Code B KVA Code H Starting Current 238 A
Service Factor (S.F.) 1.15 No-load Current 14.5 A
NEMA Nom. Eff. 93 Power Factor 84 LinelineRes.@25ºC 0.231Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 76°C
S.F. Amps Temp. Rise @ S.F. Load 92°C
Locked-rotor Power Factor 33
Rotor inertia 4.44 LB-FT2
Load Characteristics 460 V, 60 Hz, 30 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 47 68 77 81 83 84 82
Efficiency 88.2 92 92.6 92.4 91.7 90.8 92
Speed 1790 1784 1777 1770 1762 1753 1765
Line amperes 17 22.6 29.8 37.7 46 54.9 42.68
Page 7 of 10
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Performance Graph at 460V, 60Hz, 30.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Page 9 of 10
Product Information Packet: EHM9146T - 30HP,1770RPM,3PH,60HZ,286T,1056M,TEFC,F1
Page 10 of 10
