Product Information Packet
EBM3218T
5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Part Detail
Revision: K Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 36WGY404 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 36B021 Layout: 36LYB021 Poles: 04 Created Date: 04-09-2010
Base: RG Eff. Date: 01-17-2019 Leads: 9#16
Specs
Catalog Number: EBM3218T
Enclosure: OPEN
Frame: 184T
Frame Material: Steel
Output @ Frequency: 5.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
CSA EEV
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Insulation Class: F
Inverter Code: Inverter Ready
KVA Code: J
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3640M
Mounting Arrangement: F1
Power Factor: 81
Product Family: General Purpose
Product Type: BRAKE MOTOR
Pulley End Bearing Type: Ball
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Blower: None
RoHS Status: ROHS COMPLIANT
Page 2 of 10
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Current @ Voltage: 12.800 A @ 230.0 V
13.600 A @ 208.0 V
6.400 A @ 460.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Brake Mounting
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Nameplate NP1259L
CAT.NO. EBM3218T
SPEC. 36B021Y404G1
HP 5
VOLTS 230/460
AMP 12.8/6.4
RPM 1750
FRAME 184T HZ 60 PH 3
SER.F. 1.15 CODE J DES B CL F
NEMA-NOM-EFF 89.5 PF 81
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 13.6
DE 6206 ODE 6205
ENCL OPEN SN
Page 4 of 10
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Parts List
Part Number Description Quantity
SA193359 SA 36B021Y404G1 1.000 EA
RA180972 RA 36B021Y404G1 1.000 EA
36CB3004 36 CB CASTING W/1.09 DIA LEAD HOLE @ 6:0 1.000 EA
51XB1016A08 10-16X 1/2HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA
36EP1403A18 FR EP, FACE OPEN W/BRAKE W/O TIGHTSLEEVE 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA
36EP3205D00 MASTER DE,206 BRG,1.197SH,GRSR 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW2501D08 KEY, 3/16 SQ X .875 AUTO 1.000 EA
36CB4516 36 LIPPED CB LID - GALVANNEAL 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501E16 KEY, 1/4 SQ X 1.750 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
HW3200A01 3/8-16X3/4 I-BLT WELDED F/S 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000Y03 MUNSELL 2.53Y 6.70/ 4.60, GLOSS 20, 0.022 GA
HA3101A28 THRUBOLT 1/4-20 X 12.500 OHIO ROD 4.000 EA
84XN3816J36 3/8-16X2-1/4 SOCK HD, BK OX 4.000 EA
76BK6100DQF 1-056-061-00-DQF BRAKE TDR 96653 1.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
Page 5 of 10
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Parts List (continued)
Part Number Description Quantity
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
NP1259L ALUM SUPER-E UL CSA-EEV CC NEMA PREMIUM 1.000 EA
G0PA1000 PKG GRP, PRINT PK1026A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
PE-0000001 ZRTG PE ASSEMBLY 1.000 EA
Page 6 of 10
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
AC Induction Motor Performance Data
Record # 53376 - Typical performance - not guaranteed values
Winding: 36WGY404-R037 Type: 3640M Enclosure: OPSB
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 5 Full Load Torque 15 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 12.8/6.4 Breakdown Torque 52 LB-FT
R.P.M. 1750 Pull-up Torque 30 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 32 LB-FT
NEMA Design Code B KVA Code J Starting Current 48 A
Service Factor (S.F.) 1.15 No-load Current 3.2 A
NEMA Nom. Eff. 89.5 Power Factor 81 LinelineRes.@25ºC 2.5Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 38°C
S.F. Amps Temp. Rise @ S.F. Load 46°C
Locked-rotor Power Factor 52
Rotor inertia 0.372 LB-FT2
Load Characteristics 460 V, 60 Hz, 5 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 38 61 73 81 84 86 83
Efficiency 85 89.8 90.5 90 88.8 87.3 89.3
Speed 1786 1773 1761 1747 1732 1715 1738
Line amperes 3.5 4.2 5.2 6.4 7.8 9.3 7.2
Page 7 of 10
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Performance Graph at 460V, 60Hz, 5.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Page 9 of 10
Product Information Packet: EBM3218T - 5HP,1750RPM,3PH,60HZ,184T,3640M,OPEN,F1
Page 10 of 10
