Baldor DRX21724T Product Information Sheet

Product Information Packet

DRX21724T

7.5HP,3510//2910RPM,3PH,60HZ,213T,XPFC,F

Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.

Product Information Packet: DRX21724T - 7.5HP,3510//2910RPM,3PH,60HZ,213T,XPFC,F

Part Detail

Revision: B Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 07WGY328 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: Layout: 07LYJ231 Poles: 02 Created Date: 04-01-2019
Base: Eff. Date: 03-13-2020 Leads: 9#14

Specs

Catalog Number: DRX21724T
Enclosure: XPFC
Frame: 213T
Frame Material: Iron
Output @ Frequency: 7.500 HP @ 60 HZ

5.000 HP @ 50 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 190.0 V @ 50 HZ

460.0 V @ 60 HZ

230.0 V @ 60 HZ

380.0 V @ 50 HZ
XP Class and Group: CLI GP C,D
XP Division: Division I
Agency Approvals: UR

CSA EEV
CSA

Auxillary Box: No Auxillary Box

Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Inverter Duty
IP Rating: NONE
KVA Code: H
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Termination: Flying Leads
Motor Type: 0726M
Mounting Arrangement: F1
Power Factor: 87
Product Family: General Purpose
Pulley Face Code: Standard
Rodent Screen: None

Auxillary Box Lead Termination: None

Shaft Ground Indicator: No Shaft Grounding

Page 2 of 14

Product Information Packet: DRX21724T - 7.5HP,3510//2910RPM,3PH,60HZ,213T,XPFC,F

Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Constant Torque Speed Range: 6
Current @ Voltage: 9.000 A @ 460.0 V

7.600 A @ 380.0 V

18.000 A @ 230.0 V

15.200 A @ 190.0 V
Design Code: B
Drip Cover: No Drip Cover

Shaft Rotation: Reversible
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Normally Closed Thermostat
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
XP Temp Code: T3C

Page 3 of 14

Product Information Packet: DRX21724T - 7.5HP,3510//2910RPM,3PH,60HZ,213T,XPFC,F

Nameplate NP1401XPSLEV

NO. CC 010A

S/N TEMP CODE T3C

SPEC. 07-0000-0056 INV.TYPE PWM

CAT.NO. DRX21724T C HP FR 60 C HP TO 90

HP 7.5//5 CT HZ FROM 6 CT HZ TO 60

VOLTS 230/460//190/380 VT HZ FROM 6 VT HZ TO 60

AMPS 18/9//15.2/7.6 MAG CUR 9.2/4.6

RPM 3510//2910 MX RPM 5400

HZ 60//50 PH 3 CL F NOM.EFF. 90.7

SER.F. 1.00 DES B SL HZ 1.5 WK2 0.25

FRAME 213T RATING 40C AMB-CONT

55C AMB @ 1.0 SF

1.15 SF SINEWAVE NEMA MG-1 PT 5,IP55
SFA 8.9

Page 4 of 14
