Product Information Packet
CM3558T
2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: CM3558T - 2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
Part Detail
Revision: H Status: INA/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGP692 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 35A002 Layout: 35LYA002 Poles: 04 Created Date: 01-22-2008
Base: RG Eff. Date: 04-15-2010 Leads: 9#18
Specs
Catalog Number: CM3558T
Enclosure: TEFC
Frame: 145TC
Frame Material: Steel
Output @ Frequency: 2.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 208.0 V @ 60 HZ
230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Not Inverter
KVA Code: L
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3524M
Mounting Arrangement: F1
Power Factor: 72
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Blower: None
Shaft Extension Location: Pulley End
Page 2 of 10
Product Information Packet: CM3558T - 2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
Current @ Voltage: 3.100 A @ 460.0 V
6.200 A @ 230.0 V
6.700 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: CM3558T - 2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
Nameplate NP1256L
CAT.NO. CM3558T
SPEC. 35A002P692H1
HP 2
VOLTS 208-230/460
AMP 6.7-6.2/3.1
RPM 1750
FRAME 145TC HZ 60 PH 3
SER.F. 1.15 CODE L DES B CLASS F
NEMA-NOM-EFF 84 PF 72
RATING 40C AMB-CONT
CC 010A USABLE AT 208V
DE 6205 ODE 6203
ENCL TEFC SN
Page 4 of 10
Product Information Packet: CM3558T - 2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
Parts List
Part Number Description Quantity
SA167323 SA 35A002P692H1 1.000 EA
RA155661 RA 35A002P692H1 1.000 EA
34FN3002A01SP EXTERNAL FAN, PLASTIC, .637/.639 HUB W/ 1.000 EA
S/P101-000-000 EPACT PROCEDURES-FS PLANT-POLYREX EM, NO 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
35CB3007 35 CB CASTING W/.88 DIA. LEAD HOLE 1.000 EA
36GS1000SP GASKET-CONDUIT BOX, .06 THICK #SV-330 LE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
35EP3122A00 FREP TEFC ASSEMBLY FOR ROUTING 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3307D00 PULLEY ENDPLATE, MACH 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
35FH4005A84SP IEC FH W/GRSR, NO DIMPLES PRIMED 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
35CB4521 35 LIPPED CB LID (GALV & PHOSPH) 1.000 EA
35GS1030 35 GS FOR CB LID - LEXIDE 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
Page 5 of 10
Product Information Packet: CM3558T - 2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.017 GA
HA3100A15 THRUBOLT 10-32 X 8.375 4.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
LB1125C01 STD (STOCK) CARTON LABEL BALDOR WITH FLA 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
PA1000 PACKING GROUP 3500 SHORT 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: CM3558T - 2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
AC Induction Motor Performance Data
Record # 25730 - Typical performance - not guaranteed values
Winding: 35WGP692-R001 Type: 3524M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 2 Full Load Torque 5.99 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 6.65-6.16/3.08 Breakdown Torque 24.2 LB-FT
R.P.M. 1750 Pull-up Torque 14.8 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 19 LB-FT
NEMA Design Code B KVA Code L Starting Current 23.8 A
Service Factor (S.F.) 1.15 No-load Current 2.01 A
NEMA Nom. Eff. 84 Power Factor 72 LinelineRes.@25ºC 7.58Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 69°C
S.F. Amps Temp. Rise @ S.F. Load 79°C
Locked-rotor Power Factor 50
Rotor inertia 0.142 LB-FT2
Load Characteristics 460 V, 60 Hz, 2 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 31 50 63 72 78 81 76
Efficiency 70.8 81 83.6 84.1 83.5 82.2 83.7
Speed 1789 1777 1764 1751 1734 1718 1741
Line amperes 2.08 2.33 2.68 3.08 3.61 4.19 3.4
Page 7 of 10
Product Information Packet: CM3558T - 2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
Performance Graph at 460V, 60Hz, 2.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: CM3558T - 2HP,1750RPM,3PH,60HZ,145TC,3524M,TEFC,F1
4.00
5.00
5.94
7.19
3.75
.8750
.8745
4.500
4.497
6.49
.13
2.12
510-528 = 13.29
529-535 = 14.17
536-546 = 15.54
.50
2.75
.13
NAMEPLATE
6 HOLES
Ø.38
.19 KEY
1.38 LONG
GREASE FITTING
(EACH END)
2.75 2.75
3.25 4.63
6.50
3.50
3.44
6.81
45° 45°
5.75
6.61
LEAD HOLE
Ø.88
4 HOLES
.38-16 TAP
ON Ø5.88 B.C.
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
35LYA002
B
STD HORZ 143-5TC TEFC 35M
REV. DESC:
REV:
BY:
REVISED:
MODEL NO.
VERSION:
TDR:
REF:
35LYA002
LOADING OF SWD DWG FOR 2D TO 3D CONVERSION - PKG15
ENSTEK0
U
04:13:32 01/21/2019
-
000001096905
07
35LYA002
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
SH 1 OF 1
