Baldor CFSWDM41900T Product Information Sheet

Product Information Packet

CFSWDM41900T

15HP,1180RPM,3PH,60HZ,284TC,4072M,TEFC,F

Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.

Product Information Packet: CFSWDM41900T - 15HP,1180RPM,3PH,60HZ,284TC,4072M,TEFC,F

Part Detail

Revision: G Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 40WGX382 CD Diagram: CD0180 Mfg Plant:
Mech. Spec: 40E429 Layout: 40LYE429 Poles: 06 Created Date: 06-06-2017
Base: RG Eff. Date: 07-05-2020 Leads: 9#10 Y

Specs

Catalog Number: CFSWDM41900T
Enclosure: TEFC
Frame: 284TC
Frame Material: Stainless Steel
Output @ Frequency: 15.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1200 RPM @ 60 HZ
Voltage @ Frequency: 230.0 V @ 60 HZ

460.0 V @ 60 HZ

Agency Approvals: UR

CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 20.000 A @ 460.0 V

40.000 A @ 230.0 V

Inverter Code: Inverter Ready
KVA Code: H
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 10 AWG
Motor Lead Termination: Flying Leads
Motor Type: 4072M
Mounting Arrangement: F1
Power Factor: 78
Product Family: WD All SD Non-Encapsulated
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible

Design Code: A

Shaft Slinger Indicator: No Slinger

Page 2 of 11

Product Information Packet: CFSWDM41900T - 15HP,1180RPM,3PH,60HZ,284TC,4072M,TEFC,F

Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: H

Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None

Page 3 of 11

Product Information Packet: CFSWDM41900T - 15HP,1180RPM,3PH,60HZ,284TC,4072M,TEFC,F

Nameplate NP1953A02

CAT.NO. CFSWDM41900T

SPEC. 40E429X382G1

HP 15

VOLTS 230/460

AMP 40/20
RPM 1180

FRAME 284TC HZ 60 PH 3

SER.F. 1.15 CODE H DES A CLASS H

NEMA-NOM-EFF 91.7 PF 78

RATING 40C AMB-CONT

CC 010A USABLE AT 208V
DE 6311 ODE 6311

ENCL TEFC SN

Page 4 of 11
