Baldor CEWDM22976T Product Information Sheet

Product Information Packet

CEWDM22976T

7.5HP,1180RPM,3PH,60HZ,254TC,3954M,TEFC

Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.

Product Information Packet: CEWDM22976T - 7.5HP,1180RPM,3PH,60HZ,254TC,3954M,TEFC

Part Detail

Revision: X Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 39WGX718 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 39R098 Layout: 39LYR098 Poles: 06 Created Date: 06-16-2010
Base: RG Eff. Date: 03-06-2020 Leads: 9#12

Specs

Catalog Number: CEWDM22976T
Enclosure: TEFC
Frame: 254TC
Frame Material: Steel
Output @ Frequency: 7.500 HP @ 60 HZ
Synchronous Speed @ Frequency: 1200 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ

230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR

CSA EEV

CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)

Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Inverter Ready
KVA Code: K
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 12 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3954M
Mounting Arrangement: F1
Power Factor: 69
Product Family: Wash Down
Pulley End Bearing Type: Sealed Bearing
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None

Blower: None

Shaft Extension Location: Pulley End

Page 2 of 11

Product Information Packet: CEWDM22976T - 7.5HP,1180RPM,3PH,60HZ,254TC,3954M,TEFC

Current @ Voltage: 11.000 A @ 460.0 V

22.000 A @ 230.0 V

23.000 A @ 208.0 V
Design Code: A
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None

Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None

Page 3 of 11

Product Information Packet: CEWDM22976T - 7.5HP,1180RPM,3PH,60HZ,254TC,3954M,TEFC

Nameplate NP1669L

CAT.NO. CEWDM22976T

SPEC. 39R098X718G1

HP 7.5

VOLTS 230/460

AMP 22/11
RPM 1180

FRAME 254TC HZ 60 PH 3

SER.F. 1.15 CODE K DES A CLASS F

NEMA-NOM-EFF 91 PF 69

RATING 40C AMB-CONT

CC 010A USABLE AT 208V 23
DE 6309 ODE 6208

ENCL TEFC SN

BLANK 20:1 CT 20:1 VT
