Product Information Packet
CESWDM3711T
10HP,3500RPM,3PH,60HZ,215TC,3744M,TEFC,F
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: CESWDM3711T - 10HP,3500RPM,3PH,60HZ,215TC,3744M,TEFC,F
Part Detail
Revision: M Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 37WGT383 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 37H888 Layout: 37LYH888 Poles: 02 Created Date: 02-17-2010
Base: RG Eff. Date: 08-12-2019 Leads: 9#14
Specs
Catalog Number: CESWDM3711T
Enclosure: TEFC
Frame: 215TC
Frame Material: Stainless Steel
Output @ Frequency: 10.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA EEV
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Inverter Ready
KVA Code: L
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 14 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3744M
Mounting Arrangement: F1
Power Factor: 94
Product Family: Wash Down Paint Free
Pulley End Bearing Type: Sealed Bearing
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Blower: None
Shaft Extension Location: Pulley End
Page 2 of 10
Product Information Packet: CESWDM3711T - 10HP,3500RPM,3PH,60HZ,215TC,3744M,TEFC,F
Current @ Voltage: 10.600 A @ 460.0 V
21.200 A @ 230.0 V
23.000 A @ 208.0 V
Design Code: A
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: Shaft Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: CESWDM3711T - 10HP,3500RPM,3PH,60HZ,215TC,3744M,TEFC,F
Nameplate NP1669L
CAT.NO. CESWDM3711T
SPEC. 37H888T383G1
HP 10
VOLTS 230/460
AMP 21.2/10.6
RPM 3500
FRAME 215TC HZ 60 PH 3
SER.F. 1.15 CODE L DES A CLASS F
NEMA-NOM-EFF 91.7 PF 94
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 23
DE 6307 ODE 6206
ENCL TEFC SN
BLANK
Page 4 of 10
Product Information Packet: CESWDM3711T - 10HP,3500RPM,3PH,60HZ,215TC,3744M,TEFC,F
Parts List
Part Number Description Quantity
SA191060 SA 37H888T383G1 1.000 EA
RA178724 RA 37H888T383G1 1.000 EA
HW3200S01 EYEBOLT 3/8-16 X3/4 S.S. TDR #35988 1.000 EA
37CB3005A04MU K.O. BOX-MODEL 37 .75 NPT LEAD 1.000 EA
37GS1025 37 MOLDED GASKET W/LIP, LEAD SEAL 1.000 EA
51XW2520A12 .25-20 X .75, TAPTITE II, HEX WSHR SLTD 2.000 EA
HA5027A04 HA4054 T-DRAIN X2 BAGGED 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
37EP3101A49MU FR EP 37 L & M TEFC (FOR S.P. #9D) 1.000 EA
HW4500S33 1/8 NPT STAINLESS #304 SS PLUG 3.000 EA
HW5100A06 W2420-025 WVY WSHR (WB) 1.000 EA
37EP3300A25MU FACE MT EP-ENCL-307 BRG-213TC-215TC NO G 1.000 EA
HW4500S33 1/8 NPT STAINLESS #304 SS PLUG 3.000 EA
HW4606A04 JM CLIPPER/SEAL (LWE-1376-2125-AL45) 1.000 EA
10XN2520S30 1/4-20 X 1 7/8 HEX HEAD SS 4.000 EA
XY3118S12 5/16-18 HEX NUT, STAINLESS STEEL 4.000 EA
51XB1214A20 12-14X1.25 HXWSSLD SERTYB 1.000 EA
37FH4000A45 STAINLESS FAN COVER, NO GREASER SLOT (FO 1.000 EA
11XW1032S06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 3.000 EA
37CB4514 37 CB LID - STAINLESS STEEL 1.000 EA
37GS1008A02 37 GS FOR CB LID - WHITE NEOPRENE 1.000 EA
59XW0832S07 TAPTITE II,HEX WSHR UNSLTD SER,410 S.S., 4.000 EA
HW4600B74 V-RING SLINGER 1.125 X 1.445 X .24 VITON 1.000 EA
HW2502F21 #303 SS,SQ KEY 5/16 X 2.375 1.000 EA
Page 5 of 10
Product Information Packet: CESWDM3711T - 10HP,3500RPM,3PH,60HZ,215TC,3744M,TEFC,F
Parts List (continued)
Part Number Description Quantity
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
MJ5001A02 732 CL SEALANT 3 OZ DIXIE BEARING 289100 0.001 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1115N LABEL,LIFTING DEVICE (ON ROLLS) 1.000 EA
LB1164 LABEL,WARNING AND DRAIN 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
36FN3000C02SP EXFN, PLASTIC, 5.25 OD, 1.175 ID 1.000 EA
HA3104S17 THRUBOLT 13.250LG SS 4.000 EA
LC0005 CONN.DIA.,TY M,9-LD,DUAL VOLT,REVERSING 1.000 EA
NP1669L SS WD SUPER-E UL CSA-EEV PREM REV MTG 1.000 EA
37PA1039 PALLET PACK GRP, PRINT PK1026A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: CESWDM3711T - 10HP,3500RPM,3PH,60HZ,215TC,3744M,TEFC,F
AC Induction Motor Performance Data
Record # 57397 - Typical performance - not guaranteed values
Winding: 37WGT383-R007 Type: 3744M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 10 Full Load Torque 15 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 21.2/10.6 Breakdown Torque 79 LB-FT
R.P.M. 3500 Pull-up Torque 37 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 47 LB-FT
NEMA Design Code A KVA Code L Starting Current 115 A
Service Factor (S.F.) 1.15 No-load Current 3.4 A
NEMA Nom. Eff. 91.7 Power Factor 94 LinelineRes.@25ºC 0.659Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 57°C
S.F. Amps Temp. Rise @ S.F. Load 70°C
Locked-rotor Power Factor 31.5
Rotor inertia 0.402 LB-FT2
Load Characteristics 460 V, 60 Hz, 10 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 65 86 95 96 95 94 95
Efficiency 88.1 92 92.8 91.8 91 89.4 91.3
Speed 3578 3555 3533 3507 3479 3448 3490
Line amperes 4.2 6 8.1 10.6 13.5 16.4 12.3
Page 7 of 10
Product Information Packet: CESWDM3711T - 10HP,3500RPM,3PH,60HZ,215TC,3744M,TEFC,F
Performance Graph at 460V, 60Hz, 10.0HP Typical performance - Not guaranteed values
