Product Information Packet
CESSWDM3615T-5
5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Part Detail
Revision: Q Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 36WGR058 CD Diagram: CD0006 Mfg Plant:
Mech. Spec: 36L738 Layout: 36LYL738 Poles: 04 Created Date: 02-07-2013
Base: RG Eff. Date: 08-12-2019 Leads: 3#16
Specs
Catalog Number: CESSWDM3615T-5
Enclosure: TEFC
Frame: 184TC
Frame Material: Stainless Steel
Output @ Frequency: 5.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 575.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 5.200 A @ 575.0 V
Inverter Code: Inverter Ready
KVA Code: J
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 3 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3646M
Mounting Arrangement: F1
Power Factor: 81
Product Family: Wash Down All Stainless Steel
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Design Code: A
Shaft Rotation: Reversible
Page 2 of 10
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: F
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Nameplate NP1953B05
CAT.NO.
SPEC. 36L738R058G2
HP 5
VOLTS 575
AMP 5.2
RPM 1750
FRAME 184TC HZ 60 PH 3
SER.F. 1.15 CODE J DES A CLASS F
NEMA-NOM-EFF 89.5 PF 81
RATING 40C AMB-CONT
CC 010A USABLE AT 208V
DE 6206 ODE 6205
ENCL TEFC SN
Page 4 of 10
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Parts List
Part Number Description Quantity
SA258175 SA 36L738R058G2 1.000 EA
RA244951 RA 36L738R058G2 1.000 EA
36FN3000A01SP EXFN, PLASTIC, 7.00 OD, .912 ID 1.000 EA
36CB1003A01 CONDUIT BOX 1.000 EA
36GS1025 36 MOLDED GASKET W/LIP, LEAD SEAL, FOR 1.000 EA
10XN2520A10 1/4-20X 5/8 HEX HD X 2.000 EA
HA5027A02 HA4054 T-DRAIN X2 BAGGED WITH LABEL 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B02 BRASS CUP WASHER W/GROUND SYMBOL TAB, 1.000 EA
36FE1907A01 FR EP ASSY W/EP FROM SOUTHERN TOOL STAIN 1.000 EA
HW4606A02 JM CLIPPER/SEAL (LWE-0938-1624-AL23) 1.000 EA
HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA
36PE1908A03 PU ENDPLATE ASSY 1.000 EA
10XN2520S28 1/4-20X 1 3/4 HEX HD SS X 4.000 EA
HA1049A02 DUBO LOK WASHER SIZE 1/4 (NYLON LOCK SEA 4.000 EA
HA1049A02 DUBO LOK WASHER SIZE 1/4 (NYLON LOCK SEA 4.000 EA
36FH4011 WASHDOWN FAN COVER #304 STAINLESS W/NOTC 1.000 EA
10XN1032S06 HEX HD CAP SCREW, SS 3.000 EA
36CB4517 LIPPED CB LID #304 STAINLESS - CLEANED 1.000 EA
37GS3010SP 1/16"WHITE LID GASKET 1.000 EA
59XN0832S07 8/32 X 7/16 HX WS HD SER X 4.000 EA
HW4606A03 JM CLIPPER/SEAL (LWE-1156-1875-AL44) 1.000 EA
HW2502E16 #303 SS,SQ KEY 1/4 X 1.750 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
Page 5 of 10
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
MJ5001A02 732 CL SEALANT 3 OZ DIXIE BEARING 289100 0.001 EA
HW3200S01 EYEBOLT 3/8-16 X3/4 S.S. TDR #35988 1.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
HA3101S29 THRUBOLT- 1/4-20X13.00 SS 4.000 EA
36PA1001 PKG GRP, PRINT PK1017A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
AC Induction Motor Performance Data
Record # 42690 - Typical performance - not guaranteed values
Winding: 36WGR058-R001 Type: 3646M Enclosure: TEFC
Nameplate Data
575 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 5 Full Load Torque 15 LB-FT
Volts 575 Start Configuration direct on line
Full Load Amps 5.2 Breakdown Torque 50.7 LB-FT
R.P.M. 1750 Pull-up Torque 28.3 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 33 LB-FT
NEMA Design Code A KVA Code J Starting Current 39.5 A
Service Factor (S.F.) 1.15 No-load Current 2.4 A
NEMA Nom. Eff. 89.5 Power Factor 81 LinelineRes.@25ºC 3.61Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 87°C
S.F. Amps Temp. Rise @ S.F. Load 106°C
Load Characteristics 575 V, 60 Hz, 5 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 41 63 74 80 83 84 82
Efficiency 86.1 90.2 90.9 89.8 88.4 86.9 89
Speed 1789 1777 1764 1749 1734 1716 1740
Line amperes 2.68 3.31 4.18 5.19 6.39 7.73 5.91
Page 7 of 10
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Performance Graph at 575V, 60Hz, 5.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Page 9 of 10
Product Information Packet: CESSWDM3615T-5 - 5HP,1750RPM,3PH,60HZ,184TC,3646M,TEFC,F1
Page 10 of 10
