Product Information Packet
CESSWDM3610T
3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
Part Detail
Revision: W Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 36WGT861 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 36L738 Layout: 36LYL738 Poles: 02 Created Date: 02-15-2010
Base: RG Eff. Date: 08-12-2019 Leads: 9#16
Specs
Catalog Number: CESSWDM3610T
Enclosure: TEFC
Frame: 182TC
Frame Material: Stainless Steel
Output @ Frequency: 3.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Insulation Class: F
Inverter Code: Inverter Ready
KVA Code: M
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 16 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3624M
Mounting Arrangement: F1
Power Factor: 87
Product Family: Wash Down All Stainless Steel
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Shaft Extension Location: Pulley End
Current @ Voltage: 3.700 A @ 460.0 V
Shaft Ground Indicator: No Shaft Grounding
Page 2 of 10
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
7.400 A @ 230.0 V
7.900 A @ 208.0 V
Design Code: A
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
Nameplate NP1951B01
CAT.NO. CESSWDM3610T
SPEC. 36L738T861G1
HP 3
VOLTS 230/460
AMP 7.4/3.7
RPM 3500
FRAME 182TC HZ 60 PH 3
SER.F. 1.15 CODE M DES A CLASS F
NEMA-NOM-EFF 88.5 PF 87
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 7.9
DE 6206 ODE 6205
ENCL TEFC SN
Page 4 of 10
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
Parts List
Part Number Description Quantity
SA190872 SA 36L738T861G1 1.000 EA
RA178537 RA 36L738T861G1 1.000 EA
34FN3002B02 EXTERNAL FAN, PLASTIC, .905/.907 HUB W/ 1.000 EA
36CB1003A01 CONDUIT BOX 1.000 EA
36GS1025 36 MOLDED GASKET W/LIP, LEAD SEAL, FOR 1.000 EA
10XN2520A10 1/4-20X 5/8 HEX HD X 2.000 EA
HA5027A02 HA4054 T-DRAIN X2 BAGGED WITH LABEL 1.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HW3001B02 BRASS CUP WASHER W/GROUND SYMBOL TAB, 1.000 EA
36FE1907A01 FR EP ASSY W/EP FROM SOUTHERN TOOL STAIN 1.000 EA
HW4606A02 JM CLIPPER/SEAL (LWE-0938-1624-AL23) 1.000 EA
HW5100A05 WVY WSHR F/205 & 304 BRGS 1.000 EA
36PE1908A03 PU ENDPLATE ASSY 1.000 EA
10XN2520S28 1/4-20X 1 3/4 HEX HD SS X 4.000 EA
HA1049A02 DUBO LOK WASHER SIZE 1/4 (NYLON LOCK SEA 4.000 EA
HA1049A02 DUBO LOK WASHER SIZE 1/4 (NYLON LOCK SEA 4.000 EA
36FH4011 WASHDOWN FAN COVER #304 STAINLESS W/NOTC 1.000 EA
10XN1032S06 HEX HD CAP SCREW, SS 3.000 EA
36CB4517 LIPPED CB LID #304 STAINLESS - CLEANED 1.000 EA
37GS3010SP 1/16"WHITE LID GASKET 1.000 EA
59XN0832S07 8/32 X 7/16 HX WS HD SER X 4.000 EA
HW4606A03 JM CLIPPER/SEAL (LWE-1156-1875-AL44) 1.000 EA
HW2502E16 #303 SS,SQ KEY 1/4 X 1.750 1.000 EA
HA7000A02 KEY RETAINER RING, 1 1/8 DIA, 1 3/8 DIA 1.000 EA
Page 5 of 10
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
MJ5001A02 732 CL SEALANT 3 OZ DIXIE BEARING 289100 0.001 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
HA3101S42 THRUBOLT-1/4-20 X11.50 SSTDR#94334 4.000 EA
36PA1001 PKG GRP, PRINT PK1017A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 6 of 10
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
AC Induction Motor Performance Data
Record # 57423 - Typical performance - not guaranteed values
Winding: 36WGT861-R028 Type: 3624M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 3 Full Load Torque 4.6 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 7.4/3.7 Breakdown Torque 29.8 LB-FT
R.P.M. 3500 Pull-up Torque 16.5 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 17.7 LB-FT
NEMA Design Code A KVA Code M Starting Current 37.7 A
Service Factor (S.F.) 1.15 No-load Current 1.27 A
NEMA Nom. Eff. 88.5 Power Factor 87 LinelineRes.@25ºC 3.35Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 40°C
S.F. Amps Temp. Rise @ S.F. Load 48°C
Locked-rotor Power Factor 45.3
Rotor inertia 0.107 LB-FT2
Load Characteristics 460 V, 60 Hz, 3 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 57 77 86 91 93 95 92
Efficiency 82.8 88.1 89.6 89.8 89 87.8 89.3
Speed 3575 3551 3526 3501 3473 3445 3484
Line amperes 1.58 2.15 2.82 3.53 4.32 5.12 4
Page 7 of 10
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
Performance Graph at 460V, 60Hz, 3.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
Page 9 of 10
Product Information Packet: CESSWDM3610T - 3HP,3500RPM,3PH,60HZ,182TC,3624M,TEFC,F1
Page 10 of 10
