Product Information Packet
CEM3154T
1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Part Detail
Revision: P Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGM495 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 35BB102 Layout: 35LYBB102 Poles: 04 Created Date: 10-20-2010
Base: RG Eff. Date: 01-03-2019 Leads: 9#18
Specs
Catalog Number: CEM3154T
Enclosure: OPSB
Frame: 145TC
Frame Material: Steel
Output @ Frequency: 1.500 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA EEV
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Inverter Ready
KVA Code: L
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3522M
Mounting Arrangement: F1
Power Factor: 72
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Blower: None
Shaft Extension Location: Pulley End
Page 2 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Current @ Voltage: 2.200 A @ 460.0 V
4.400 A @ 230.0 V
4.500 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Nameplate NP3553LUA
CAT.NO. CEM3154T
SPEC. 35BB102M495G1
HP 1.5
VOLTS 230/460
AMPS 4.4/2.2
RPM 1755
FRAME 145TC HZ 60 PH 3
SF 1.15 CODE L DES B CLASS F
NEMA NOM. EFF 86.5 PF 72
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 4.5
DE 6205 ODE 6203
ENCL OPSB SN
VPWM INVERTER READY
CT30-60(2:1) VT3-60(20:1)
USABLE AT 50HZ 1.5HP 190/380V 5.2/2.6A SF1.0
Page 4 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Parts List
Part Number Description Quantity
SA204971 SA 35BB102M495G1 1.000 EA
RA192219 RA 35BB102M495G1 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
35CB3009 35 CB W/1.09 DIA. LEAD HOLE @ 6: 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
35EP3209A00 MASTER ODE,203 BRG,GRSR 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3402B00 MASTER DE,205 BRG,OPEN,W/GREASER 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
35CB4521 35 LIPPED CB LID (GALV & PHOSPH) 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
MG1000Y03 MUNSELL 2.53Y 6.70/ 4.60, GLOSS 20, 0.017 GA
35AD2005A01 BAFFLE PLATE,MOD 35-SLTD BAND MTRS GL.F. 2.000 EA
HA3100A14 THRUBOLT 10-32 X 7.875 4.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
NP3553LUA ALUM SUPER-E VPWM INVERTER READY UL 1.000 EA
35PA1066 PKG GRP, PRINT PK1008A06 1.000 EA
Page 5 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Parts List (continued)
Part Number Description Quantity
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
FE-0000001 ZRTG FE ASSEMBLY 1.000 EA
PE-0000001 ZRTG PE ASSEMBLY 1.000 EA
Page 6 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
AC Induction Motor Performance Data
Record # 32593 - Typical performance - not guaranteed values
Winding: 35WGM495-R001 Type: 3522M Enclosure: OPSB
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 1.5 Full Load Torque 4.46 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 4.50/2.25 Breakdown Torque 17.7 LB-FT
R.P.M. 1755 Pull-up Torque 10.8 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 12.6 LB-FT
NEMA Design Code B KVA Code L Starting Current 17.5 A
Service Factor (S.F.) 1.15 No-load Current 1.43 A
NEMA Nom. Eff. 86.5 Power Factor 72 LinelineRes.@25ºC 10.73Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 34°C
S.F. Amps Temp. Rise @ S.F. Load 40°C
Load Characteristics 460 V, 60 Hz, 1.5 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 32 50 63 72 78 81 76
Efficiency 74.7 83.5 86 86.6 86.3 85.3 86.4
Speed 1789.9 1780.2 1769.2 1758.4 1746.3 1732.6 1751
Line amperes 1.5 1.67 1.93 2.24 2.61 3.05 2.46
Page 7 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Performance Graph at 460V, 60Hz, 1.5HP Typical performance - Not guaranteed values
Page 8 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
AC Induction Motor Performance Data
Record # 60670 - Typical performance - not guaranteed values
Winding: 35WGM495-R001 Type: 3522M Enclosure: OPSB
Nameplate Data
230 V, 60 Hz:
Low Voltage Connection
Rated Output (HP) 1.5 Full Load Torque 4.46 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 4.4/2.2 Breakdown Torque 17.7 LB-FT
R.P.M. 1755 Pull-up Torque 10.8 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 12.6 LB-FT
NEMA Design Code B KVA Code L Starting Current 35 A
Service Factor (S.F.) 1.15 No-load Current 2.86 A
NEMA Nom. Eff. 86.5 Power Factor 72 LinelineRes.@25ºC 2.59Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 34°C
S.F. Amps Temp. Rise @ S.F. Load 40°C
Locked-rotor Power Factor 52.5
Rotor inertia 0.13 LB-FT2
Load Characteristics 230 V, 60 Hz, 1.5 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 32 50 63 72 78 81 76
Efficiency 74.7 83.3 85.9 86.5 86.1 85.2 86.3
Speed 1790 1780 1769 1758 1746 1733 1751
Line amperes 3 3.34 3.86 4.48 5.22 6.1 4.92
Page 9 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Performance Graph at 230V, 60Hz, 1.5HP Typical performance - Not guaranteed values
Page 10 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
510-524 = 11 63
525-528 = 12 13
529-535 = 13 01
536-546 = 14 38
4 500
4 497
6 49
8750
8745
2 12
13
4 00
5 00
5 94
50
2 60
13
2 75
19 KEY
1 38 LONG
6 HOLES
38
GREASE FITTING
(EA END)
45° 45°
5 62
3 50
3 44
6 78
6 61
2 75 2 75
4 56
3 25
6 50
4 X 38-16 TAP
ON
5 88 B C
LEAD HOLE
1 09
NAMEPLATE
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
35LYBB102
B
HOR 143-5TC OPSB M W/ 1.09 DIA LEAD HOLE
SH 1 of 1
REV. DESC
REV
BY
REVISED
MODEL NO.
VERSION
TDR
REF
35LYBB102
LOADING OF SWD DWG FOR 2D TO 3D CONVERSION - PKG15
ENSTEK0
B
10 55 49 01/22/2019
-
000001096905
02
35LYBB102
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
Page 11 of 12
Product Information Packet: CEM3154T - 1.5HP,1755RPM,3PH,60HZ,145TC,3522M,OPSB
Page 12 of 12
