CEL11304

Baldor CEL11304 Product Information Sheet

Download
Product Information Packet
CEL11304
.5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Part Detail
Revision: D Status: PRD/A Change #: Proprietary: No Type: AC Elec. Spec: 34WGR141 CD Diagram: CD0055 Mfg Plant: Mech. Spec: 34F867 Layout: 34LYF867 Poles: 04 Created Date: 10-03-2014 Base: RG Eff. Date: 08-24-2018 Leads: 6#18
Specs
Catalog Number: CEL11304 Enclosure: OPEN Frame: 56C Frame Material: Steel Output @ Frequency: .500 HP @ 60 HZ Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ Voltage @ Frequency: 230.0 V @ 60 HZ
115.0 V @ 60 HZ XP Class and Group: None XP Division: Not Applicable Agency Approvals: CSA
UR Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: Rigid Bearing Grease Type: Polyrex EM (-20F +300F) Blower: None
Insulation Class: B Inverter Code: Not Inverter KVA Code: K Lifting Lugs: No Lifting Lugs Locked Bearing Indicator: Locked Bearing Motor Lead Quantity/Wire Size: 6 @ 18 AWG Motor Lead Exit: Ko Box Motor Lead Termination: Flying Leads Motor Type: 3424LC Mounting Arrangement: F1 Power Factor: 98 Product Family: General Purpose Pulley End Bearing Type: Ball Pulley Face Code: C-Face Pulley Shaft Indicator: Standard Rodent Screen: None RoHS Status: ROHS COMPLIANT
Current @ Voltage: 2.350 A @ 230.0 V
Shaft Extension Location: Pulley End
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
3.200 A @ 208.0 V
4.700 A @ 115.0 V Design Code: N Drip Cover: No Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK Front Face Code: Standard Front Shaft Indicator: None Heater Indicator: No Heater
Shaft Ground Indicator: No Shaft Grounding Shaft Rotation: Reversible Shaft Slinger Indicator: No Slinger Speed Code: Single Speed Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: None Vibration Sensor Indicator: No Vibration Sensor Winding Thermal 1: None Winding Thermal 2: None
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Nameplate NP3155L
CAT.NO. CEL11304
SPEC. 34F867R141G1
HP .5
VOLTS 115/230
AMP 4.7/2.35 RPM 1725
FRAME 56C HZ 60 PH 1
SER.F. 1.25 CODE K DES N CL B
F.L. AVG. EFF. 76.2 PF 98
RATING 40C AMB-CONT
CC USABLE AT 208V 3.2 DE 6203 ODE 6203
ENCL OPEN SN
SFA 5.9/2.95
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Parts List
Part Number Description Quantity SA288046 SA 34F867R141G1 1.000 EA RA274247 RA 34F867R141G1 1.000 EA OC3030F11SP CAPACITOR 30 MFD 370 VAC 1.000 EA EC1324A02 ELEC CAP, 324-389 MFD, 125V, 1.48D X 3. 1.000 EA NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA 34CB3002A CB CAST W/.88 DIA HOLE 1.000 EA 51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA 11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA 51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 2.000 EA SP1006A01 TERM. BOARD, MODE 35 SW X H-23655 1.000 EA 34EP3210A01SP FR ENDPLATE, MACH 1.000 EA HW5100A03 WAVY WASHER (W1543-017) 1.000 EA 34CB3801 CAPACITOR BOX, DIE CAST 1.000 EA 51XB1214A08 12-14 X 1/2HX WS SL SR TYBX 2.000 EA 34GS5003A01 FOAM SLEEVE, ID = 2 1/16" X 4 3/8" 1.000 EA 51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA 34EP3401A01SP PU ENDPLATE, MACH 1.000 EA 34AD2000 BAFFLE PLATE, STAMPED 1.000 EA 60XW0632A06 6-32 X 3/8 TORX HEAD SCREW TAPTITE II 4.000 EA 34CB4517 CB LID 4 MTG HOLES .22 DIA STAMPED, FOR 1.000 EA 51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA HA7000A04 KEY RETAINER 0.625 DIA SHAFTS 1.000 EA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Parts List (continued)
Part Number Description Quantity MG1000Y03 MUNSELL 2.53Y 6.70/ 4.60, GLOSS 20, 0.014 GA HA3100A17 THRUBOLT 10-32 X 9.000 4.000 EA SP5181A01 MODEL 35 TORQ STATIONARY SWITCH LEAD ASS 1.000 EA LC0001A01 CONN LABEL / WARNING LABEL (LC0001 / LB1 1.000 EA MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA NP3155L ALUM SUPER-E UL CSA CC "SEMS" 1.000 EA 35PA1000 PKG GRP, PRINT PK1008A06 1.000 EA
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
AC Induction Motor Performance Data
Record # 47421 - Typical performance - not guaranteed values
Winding: 34WGR141-R002 Type: 3424LC Enclosure: OPEN
Nameplate Data
115 V, 60 Hz:
Low Voltage Connection Rated Output (HP) .5 Full Load Torque 1.51 LB-FT Volts 115/230 Start Configuration direct on line Full Load Amps 4.7/2.35 Breakdown Torque 4.01 LB-FT R.P.M. 1725 Pull-up Torque 3.75 LB-FT Hz 60 Phase 1 Locked-rotor Torque 6.42 LB-FT NEMA Design Code N KVA Code K Starting Current 31.9 A Service Factor (S.F.) 1.25 No-load Current 1.06 A
NEMA Nom. Eff. 76.2 Power Factor 98 LinelineRes.@25ºC
1.6786ΩAPh
2.0496ΩBPh
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 37°C S.F. Amps 5.9/2.95 Temp. Rise @ S.F. Load 55°C
Load Characteristics 115 V, 60 Hz, 0.5 HP
% of Rated Load 25 50 75 100 125 150 S.F. Power Factor 89 94 95 95 95 94 95 Efficiency 59.9 73 76.8 76.6 73.3 67.1 73.3 Speed 1782.8 1767.7 1748.6 1726.8 1694.2 1648.1 1694 Line amperes 1.56 2.34 3.34 4.39 5.8 7.69 5.8
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Performance Graph at 115V, 60Hz, 0.5HP Typical performance - Not guaranteed values
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
AC Induction Motor Performance Data
Record # 49328 - Typical performance - not guaranteed values
Winding: 34WGR141-R002 Type: 3424LC Enclosure: OPEN
Nameplate Data
230 V, 60 Hz:
High Voltage Connection Rated Output (HP) .5 Full Load Torque 1.51 LB-FT Volts 115/230 Start Configuration direct on line Full Load Amps 4.7/2.35 Breakdown Torque 4.01 LB-FT R.P.M. 1725 Pull-up Torque 2.84 LB-FT Hz 60 Phase 1 Locked-rotor Torque 4.87 LB-FT NEMA Design Code N KVA Code K Starting Current 14.97 A Service Factor (S.F.) 1.25 No-load Current 0.571 A
NEMA Nom. Eff. 76.2 Power Factor 98 LinelineRes.@25ºC
6.38ΩAPh
2.09ΩBPh
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 40°C S.F. Amps 5.9/2.95 Temp. Rise @ S.F. Load 53°C
Rotor inertia 0.057 LB-FT2
Load Characteristics 230 V, 60 Hz, 0.5 HP
% of Rated Load 25 50 75 100 125 150 S.F. Power Factor 89 93 95 96 95 94 95 Efficiency 57.8 71.3 75.5 75.6 72.6 66.9 72.6 Speed 1783 1768 1749 1727 1694 1648 1694 Line amperes 0.809 1.2 1.7 2.22 2.93 3.87 2.93
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Performance Graph at 230V, 60Hz, 0.5HP Typical performance - Not guaranteed values
Page 10 of 12
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Page 11 of 12
Product Information Packet: CEL11304 - .5HP,1725RPM,1PH,60HZ,56C,3424LC,OPEN,F1
Page 12 of 12
