Product Information Packet
CEBM3546T
1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
Part Detail
Revision: N Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGL007 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 35E567 Layout: 35LYE567 Poles: 04 Created Date: 03-24-2015
Base: RG Eff. Date: 03-13-2019 Leads: 9#18
Specs
Catalog Number: CEBM3546T
Enclosure: TEFC
Frame: 143TC
Frame Material: Steel
Output @ Frequency: 1.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 460.0 V @ 60 HZ
230.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CSA
CSA EEV
UR
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Inverter Code: Inverter Ready
IP Rating: NONE
KVA Code: N
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3522M
Mounting Arrangement: F1
Power Factor: 62
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
Blower: None
Shaft Extension Location: Pulley End
Page 2 of 10
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
Current @ Voltage: 1.700 A @ 460.0 V
3.400 A @ 230.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Brake Mounting
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: F
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
Nameplate NP1259L
CAT.NO. CEBM3546T
SPEC. 35E567L007G1
HP 1
VOLTS 230/460
AMP 3.4/1.7
RPM 1760
FRAME 143TC HZ 60 PH 3
SER.F. 1.15 CODE N DES B CL F
NEMA-NOM-EFF 85.5 PF 62
RATING 40C AMB-CONT
CC 010A USABLE AT 208V
DE 6205 ODE 6203
ENCL TEFC SN
Page 4 of 10
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
Parts List
Part Number Description Quantity
SA295806 SA 35E567L007G1 1.000 EA
RA281864 RA 35E567L007G1 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
35CB3007 35 CB CASTING W/.88 DIA. LEAD HOLE 1.000 EA
36GS1000SP GASKET-CONDUIT BOX, .06 THICK #SV-330 LE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
35EP3900T02 SPL FACE MTD FR EP-ENCL-W/STEARNS BRAKE 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3307D00 MASTER DE,205 BRG,.998SH,#26 DRN,GRSR 1.000 EA
HW4500A01 1641B(ALEMITE)400 UNIV, GREASE FITT 1.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
HA1014A02SP SPL SPACER FOR FAN COVER MTD ON BRAKE 3.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 3.000 EA
BR1003A01 BRAKE RELEASE LEVER 1.000 EA
HW2501D08 KEY, 3/16 SQ X .875 AUTO 1.000 EA
84XN3816J28 HEX SOC HD, 3/8-16 X 1.75 LONG 2.000 EA
NP1259L ALUM SUPER-E UL CSA-EEV CC NEMA PREMIUM 1.000 EA
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
35FH5000A08 FAN COVER ASSY FOR BRAKE MTRS,W/ PRIMER 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
35CB4521GX CONDUIT BOX LID KIT **ORDER INDIV PARTS 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
Page 5 of 10
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
Parts List (continued)
Part Number Description Quantity
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
35FN3002A01SP EXFN, PLASTIC, 6.376 OD, .625 ID W/FLAT 1.000 EA
MG1000Y03 MUNSELL 2.53Y 6.70/ 4.60, GLOSS 20, 0.017 GA
HA3100A15 THRUBOLT 10-32 X 8.375 4.000 EA
76BK2100BQF 1-056-021-00-BQF BRAKE TDR# 79345 1.000 EA
LB1404 BRAKE CONNECTION LABEL 1.000 EA
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
G7PA1000 PKG GRP, PRINT PK1034A06 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
PE-0000001 ZRTG PE ASSEMBLY 1.000 EA
Page 6 of 10
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
AC Induction Motor Performance Data
Record # 61951 - Typical performance - not guaranteed values
Winding: 35WGL007-R024 Type: 3522M Enclosure: TEFC
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 1 Full Load Torque 2.95 LB-FT
Volts 230/460 Start Configuration direct on line
Full Load Amps 3.4/1.7 Breakdown Torque 16.5 LB-FT
R.P.M. 1760 Pull-up Torque 8.45 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 11.4 LB-FT
NEMA Design Code B KVA Code N Starting Current 15.7 A
Service Factor (S.F.) 1.15 No-load Current 1.3 A
NEMA Nom. Eff. 85.5 Power Factor 62 LinelineRes.@25ºC 10.6Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 35°C
S.F. Amps Temp. Rise @ S.F. Load 39°C
Locked-rotor Power Factor 51.4
Rotor inertia 0.13 LB-FT2
Load Characteristics 460 V, 60 Hz, 1 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 25 41 53 62 69 74 66
Efficiency 69 80.5 84.2 85.8 86.2 85.8 86
Speed 1793 1785 1778 1770 1761 1752 1765
Line amperes 1.34 1.42 1.57 1.74 1.96 2.2 1.87
Page 7 of 10
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
Performance Graph at 460V, 60Hz, 1.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
3-15 FT/LB = 5 59
20-25 FT/LB = 6 01
510-528 = 12 31
529-535 = 13 19
536-546 = 14 56
13
2 12
8750
8745
4 500
4 497
4 00
5 00
2 78
7 19
6 49
5 94
50
13
2 75
GREASE FITTING
EACH END
6 HOLES
34
19 KEY
1 38 LONG
BRAKE RELEASE
LEVER
NAMEPLATE
5 74
45° 45°
6 62
2 75 2 75
4 63
3 50
3 44
6 81
3 25
6 50
LEAD HOLE
88
4 HOLES
38-16 TAP ON
5 88 B C
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
35LYE567
B
STD HORZ 143-5TC TEFC 35M W/76BK BRAKE
SH 1 of 1
REV. DESC
REV
BY
REVISED
MODEL NO.
VERSION
TDR
REF
35LYE567
LOAD INOPC CREATED SWD DRG INTO BUS - PACKAGE 29
USBUFRA
L
07 26 16 07/25/2019
-
000001114730
05
35LYE567
CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION
BALDOR - RELIANCE
®
Page 9 of 10
Product Information Packet: CEBM3546T - 1HP,1760RPM,3PH,60HZ,143TC,3522M,TEFC,F1
