Baldor CDRX40144T Product Information Sheet

Product Information Packet

CDRX40144T

100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Part Detail

Revision: - Status: PRD/A Change #: Proprietary: No Type: AC Elec. Spec: A40WG0692 CD Diagram: 416820-002 Mfg Plant: Mech. Spec: Layout: 617428-725 Poles: 04 Created Date: 05-22-2019 Base: Eff. Date: 05-29-2019 Leads: 3#2,6#4

Specs

Catalog Number: CDRX40144T Enclosure: TEFC Frame: 405TC Frame Material: Iron Output @ Frequency: 100.000 HP @ 60 HZ Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ Voltage @ Frequency: 460.0 V @ 60 HZ

230.0 V @ 60 HZ XP Class and Group: CLI GP C,D XP Division: Division I Agency Approvals: CCSA US

CSA CSA EEV

UL Auxillary Box: No Auxillary Box Base Indicator: Rigid Bearing Grease Type: Polyrex EM (-20F +300F)

Duty Rating: CONT Feedback Device: NO FEEDBACK Heater Indicator: No Heater Insulation Class: F Inverter Code: Inverter Ready IP Rating: NONE KVA Code: G Motor Lead Quantity/Wire Size: 3 @ 2 AWG Motor Type: A40064M Mounting Arrangement: F1 Power Factor: 87 Product Family: General Industrial Pulley End Bearing Type: Ball Pulley Face Code: C-Face Shaft Ground Indicator: No Shaft Grounding Shaft Rotation: Reversible Shaft Slinger Indicator: Shaft Slinger

Constant Torque Speed Range: 6-60

Speed Code: Single Speed

Page 2 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Current @ Voltage: 224.000 A @ 230.0 V

112.000 A @ 460.0 V Design Code: B Drip Cover: No Drip Cover

Motor Standards: NEMA Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: Normally Closed Thermostat XP Temp Code: T3C

Page 3 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Nameplate NP2496L

MOBIL POLYREX EM

Page 4 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Nameplate 000613006PC

CLASS I GROUP C D X NO.

CLASS II GROUP X X X

OPERATING TEMP CODE T3C

Page 5 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Nameplate NP3140L

SPEC NO. A40-7258-0692 CAT.NO. CDRX40144T FRAME 405TC

HP 100 VOLTS 230/460 PHASE 3 DESIGN B TYPE P

RPM 1785 AMPS 224/112 HZ 60 AMB 40 SF 1.00

DRIVE END BEARING 80BC03J30X DUTY CONT INSUL.CLASS F

OPP D.E. BEARING 80BC03J30X ENCL TEFC CODE G

SF 1.15 WK2 26.346 MAG CUR 28.6 RPM MAX 3600

CT HZ 6-60 VT HZ 0-60 CHP HZ 60-90 NEMA-NOM-EFF 95.4

SUIT FOR 55C AMB AT 1.00 SF IP55

SER.NO. MOTOR WEIGHT 1326

Page 6 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Parts List

Part Number Description Quantity SA369960 SA A40-7258-0692 1.000 EA RA359581 RA A40-7258-0692 1.000 EA 421948032 LABEL, MYLAR 1.000 EA NP2496L MOTOR LUBE NAMEPLATE 1.000 EA 000692000VD LABEL WARNING 1.000 EA LB1073 ALUM XP CAUTION LABEL 1.000 EA 000613006PC N/P U/L (REL QTY 500) 1.000 EA NP3140L INVERTER DUTY, SS, CC, CSA-C US, CSA EEV 1.000 EA HW4505A02 BREATHER/DRAIN-EXP PROOF-.250-18 PTF AIS 2.000 EA 609158001E SLGR - 400 1.000 EA 603284001Y SLGR - 400 1.000 EA 089416503A G400 STD BRKT MACHINING 6316 BE OR FE 1.000 EA 415072001B CLAMP 1.000 EA 083198101A G400 STD FAN COVER MACHINING 1.000 EA 034180012DA KEY 1X4X1/4X1-1/2 L 1.000 EA 078548001R FAN KB 234/150 (84) 400 1.000 EA 004824015A GREASE POLYREX EM 0.880 LB 032130022GB HSHCS 7/8-9X2-3/4 PLTD. 4.000 EA 032018008CK HHCS 3/8-16X1L PLATED 4.000 EA 032018030CK HHCS 3/8-16X3-3/4 PLATED 3.000 EA 415096002A CPLG 1/8 HEX TYPE 1.000 EA 415045002B SLGR 1.000 EA 410700000DA WAVY SPRING WASHER 1.000 EA 034000014AB WSH ID.406 OD.812 TH.065 4.000 EA

Page 7 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Parts List (continued)

Part Number Description Quantity 034530056BB P/NIP 1/4X7 SCHED 40 1.000 EA 034530052AB P/NIP 1/8X6-1/2 GALV. 1.000 EA 034690001AB 1/8" NPT SQHDPLG 1.000 EA 034631002AB BUSH 1/4 TO 1/8 PLTD. 1.000 EA 034690002AB PPLG 1/4" PLTD. 1.000 EA 089416508A G400 X/P C-FACE BRKT MCHG 6316 1.000 EA 032018032CK HHCS 3/8-16X4 PLATED 3.000 EA 415045002B SLGR 1.000 EA 034017014AB LCKW 3/8 STD. PLATED 3.000 EA 032130024GB HSHCS 7/8-9NC X 3" LONG PLATED 4.000 EA 16CB1001A01 CONDUIT BOX MACH GRP C MTRS 16CB1001 1.000 EA 16CB1501A01 CONDUIT BOX LID MACH.GRP C MTRS 16CB1501 1.000 EA 418150003A GREASE FITTING CAP 1.000 EA 406055001C GRFTG 1.000 EA 034017018AB 5/8 MED LOCK WASHER ZP 8.000 EA 034017014AB LCKW 3/8 STD. PLATED 4.000 EA 035000001A ALFTG 1/8" 1610-BL 1.000 EA 032130016EB HSHCS 5/8-11X2 PLTD. 8.000 EA 415000103H T/LUG #2AWG-4/0AWG 1.000 EA 406099000A PLUG - FAN COVER 320-440 1.000 EA 032018008DK HHCS 1/2-13X1 PLATED 1.000 EA 034017016AB LCKW 1/2" PLATED 1.000 EA 032130014CB HSHCS 3/8-16X1-3/4 PLTD. 4.000 EA 406055001C GRFTG 1.000 EA

Page 8 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

035000001A ALFTG 1/8" 1610-BL 1.000 EA 418150003A GREASE FITTING CAP 1.000 EA 004824003CEH WILKO PAINT 789.229 DARK GREY CHARCOAL T 0.380 GA 033775004EA DRSCR #6-1/4 304 S.S. 8.000 EA 034180045JA KEY,DE 1.000 EA 604797045 STD. 400 FRAME SKID 1.000 EA 032510024D CARRIAGE BOLT - 444 2.000 EA 034001014AB FLAT WASHER 3/8"PLATED 2.000 EA 034001016AB WSHR .562ID 1.375OD .109 2.000 EA 033300014AC HEX NUT, SHIPPING - 400 2.000 EA 604799003C PLASTIC BAG 42X32X46 1.000 EA

Page 9 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

405HPZ 100 P 3/60 1785 230/460

224/112 CONT 40/F 1.00 B G TEFC

596956 418142-33RE --- --- .0123/.0492

0 28.6 1800 5.49 0

25.0 39.2 1796 64.3 93.0

50.0 59.5 1792 82.5 95.4

75.0 84.6 1788 86.7 95.7

100 112 1783 87.4 95.4

125 141 1778 87.3 94.9

LB.-FT.

0 151 445 725

360 136 400 706

1721 250 735 382

1783 100 295 112

460. VOLT

TYPICAL DATA

NEMA NOM. EFF. 95.4 PCT

G. R. WEBB

W. L. SMITH

A40WG0692-R016

E.J.CHRISTIAN

09/29/15

11/07/19

Printed on 11/7/19 7:24 @ bengap01.baldor.com

REL.

S.O.

FRAME HP TYPE

PHASE/

HERTZ

RPM VOLTS

AMPS DUTY

AMB

C/

INSUL.

S.F.

NEMA

DESIGN

CODE

LETTER

ENCL.

E/S ROTOR

TEST

S.O.

TEST

DATE

STATOR RES.@25

C

OHMS (BETWEEN LINES)

PERFORMANCE

LOAD HP AMPERES RPM

%

POWER FACTOR

%

EFFICIENCY

NO LOAD

1/4

2/4

3/4

4/4

5/4

SPEED TORQUE

RPM

TORQUE

% FULL LOAD

TORQUE

AMPERES

LOCKED ROTOR

PULL UP

BREAKDOWN

FULL LOAD

AMPERES SHOWN FOR CONNECTION. IF OTHER VOLTAGE CONNECTIONS ARE AVAILABLE, THE

AMPERES WILL VARY INVERSELY WITH THE RATED VOLTAGE

REMARKS:

DR. BY

CK. BY

APP. BY

DATE

A-C MOTOR

PERFORMANCE

DATA

ISSUE DATE

Rotext2(0)

Page 10 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

1785 1.00 418142-33RE

405HPZ 230/460 B TYPICAL DATA

100 224/112 G ---

P CONT TEFC .0123/.0492

3/60 40/F 596956

Printed on 11/7/19 7:24 @ bengap01.baldor.com

REL S.O.

FRAME

HP

TYPE

PHASE/HERTZ

RPM

VOLTS

AMPS

DUTY

AMB

C/INSUL

S.F.

NEMA DESIGN

CODE LETTER

ENCLOSURE

E/S

ROTOR

TEST S.O.

TEST DATE

STATOR RES.@ 25

C

OHMS (BETWEEN LINES)

A-C MOTOR

PERFORMANCE

CURVES

DR. BY

CK. BY

APP. BY

DATE

ISSUE DATE

AMPERES SHOWN FOR

AMPERES WILL VARY INVERSELY WITH THE RATED VOLTAGE.

CONNECTION, IF OTHER VOLTAGE CONNECTIONS ARE AVAILABLE, THE

Rotext2(0)

460 VOLT

G. R. WEBB

W. L. SMITH

E.J.CHRISTIAN

09/29/15

A40WG0692-R016

11/07/19

0 200 400 600 800 1000 1200 1400 1600 1800

SPEED IN RPM,(FLT = 295 LB. FT.)

0 200 400 600 800 1000 1200

AMPS AT 460 VOLTS (1)

0 200 400 600 800 1000 1200

TORQUE IN LB. FT. (2)

1

2

0 20 40 60 80 100 120 140 160 180 200 220

HORSEPOWER

0 20 40 60 80 100 120 140 160

AMPS AT 460 VOLTS (1)

0 20 40 60 80 100

P.F.(2) & EFF.(3) IN %

1768 1772 1776 1780 1784 1788 1792 1796 1800

SPEED IN RPM (4)

1

2

3

4

FL

NEMA NOM. EFF. 95.4 PCT

Page 11 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

1785 1.00 418142-33RE

405HPZ 230/460 B TYPICAL DATA

100 224/112 G ---

P CONT TEFC .0123/.0492

3/60 40/F 596956

Printed on 11/7/19 7:24 @ bengap01.baldor.com

REL. S.O.

FRAME

HP

TYPE

PHASE/HERTZ

RPM

VOLTS

AMPS

DUTY

AMB

C/INSUL

S.F.

NEMA DESIGN

CODE LETTER

ENCLOSURE

E/S

ROTOR

TEST S.O.

TEST DATE

STATOR RES.@ 25

C

OHMS (BETWEEN LINES)

A-C MOTOR

PERFORMANCE

CURVES

REMARKS:

DR. BY

CK. BY

APP. BY

DATE

ISSUE DATE

AMPERES SHOWN FOR

AMPERES WILL VARY INVERSELY WITH THE RATED VOLTAGE.

VOLT CONNECTION, IF OTHER VOLTAGE CONNECTIONS ARE AVAILABLE, THE

1

2

3

4

56789

1

2

3

4

56789

1

2

3

4

56789

10

Rotext2(0)

0 200 400 600 800 1000 1200 1400

% FULL LOAD CURRENT

TIME IN SEC.

0

00

OVERLOAD

ACCELERATION

LOCKED-ROTOR

LOCKED-ROTOR, 40.C

MOTOR INITIAL TEMPERATURE:

100

C FOR OVERLOAD AND ACC.

100 C FOR LOCKED-ROTOR

THERMAL LIMIT CURVE

NEMA NOM. EFF. 95.4 PCT

460

G. R. WEBB

W. L. SMITH

E.J.CHRISTIAN

09/29/15

A40WG0692-R016

11/07/19

Page 12 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

1 OF 1

SHEET NUMBER

13.75

12.25

18.01

BA=6.62

N-W=

7.25

V=7.13

5.63

K'WY

.750

SQ. KEY

2.875

+-.000

.001

38.22

7.00

3/8-16 UNC 1/2-13 UNC

AH=

7.00±.03

13.75

AK=

12.500

+

-

.000

.005

BD=

13.15

BB=.28

6.00

1

2.00

16.00

3.60 3.60

8.00 9.50

19.00

16.78

12.27

10.00

+-.00

.06

45°

TYP.

8X

5/8-11 UNC - 2B

1.00

ON A

11.00 B.C.

1.77

1.23

33.49

21.48

11.12

5.24

3 NPT

6.88

8X

.81 THRU

(FOOT MOUNTING)

DUTY MASTER ALTERNATING CURRENT MOTORS

SQUIRREL-CAGE INDUCTION

G405T/G404T FRAME MOUNTING HOLES

GROUP C & D

1

OBSTRUCTION MUST NOT ENCROACH ON AIR INLET.

IF MOUNTING CLEARANCE DETAILS ARE REQUIRED, CONSULT FACTORY.

WEIGHT (LBS): 1400,

MOTOR WEIGHTS MAY VARY BY 15% DEPENDING ON RATING.

MAX PERMISSIBLE SHAFT RUNOUT WHEN MEASURED AT END OF STANDARD SHAFT EXTENSION IS .003" T.I.R.

DIMENSIONS ARE IN INCHES.

MAX FACE RUNOUT & ECCENTRICITY = .007 T.I.R.

CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT MOTOR PERFORMANCE IS SUITABLE IN THE APPLICATION.

ENCLOSURE: UNDERWRITERS LISTED

MOUNTING: FOOT, F-1

COOLING: FAN COOLED

D

C

B

A

B

C

D

1

2

3

4

5

6

7

8

7

6

5

4

3

2

1

E

F

E

F

C

617428-725

00

000001109207

617428-725

09:51:05 05/22/2019

-

USJEDIL

NEW DRAWING

617428-725

REF:

TDR:

VERSION:

MODEL NO.

REVISED:

BY:

REV:

REV. DESC:

G405/404TC XP TEFC F1 FOOT CAST IRON CONDUIT BOX/GROUP C&D

Material:

Page 13 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Page 14 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Page 15 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Marketing maintained PDF of MN408:

http://www.baldor.com/support/Literature/Load.ashx/MN408?ManNumber=MN408

Page 16 of 17

Product Information Packet: CDRX40144T - 100HP,1785RPM,3PH,60HZ,405TC,TEFC,F1

Marketing maintained PDF of MN416:

http://www.baldor.com/support/Literature/Load.ashx/MN416?ManNumber=MN416

Page 17 of 17
