BAKERS

PRIDE

HIGH PERFORMANCE

COUNTER TOP

GAS CHAR BROILER

Model CTB-24R with optional warming rack

SPECIFICATIONS

Counter-top char broiler is designed for high volume char broiling in
natural or LP gas. CTB-R Series includes 14-gauge stainless steel
radiants/heat deflectors above each burner for maximum heat
distribution to cooking surface. The CTB-GS series features Glo
Stones for extra high heat and flame-flare. Radiants and Glo Stones
are interchangeable without tools and may be mixed and matched
on the same broiler. Additional
deflectors are located between each burner for even heat
distribution.

High performance, clog-proof, aluminized steel burners
are rated at 20,000 BTUH each and located approximately every 6".
Each burner features a separate, independent, operator-controlled
valve.

Standard grates are fabricated of 1/2" diameter steel floating-rods.
A variety of different style grates are optional and may be mixed or
matched. Each grate may be adjusted independently in any of four
tilting positions. Broiler grates are 24" deep (610mm) for maximum
production. The front grate surface is 19 1/2" high (495mm) from
broiler base.

Top trim, outer sides, back, splash and front deck are constructed
of heavy-duty stainless steel. Interior combustion chamber is
constructed of, heat tolerant, aluminized steel. Broiler cabinet
construction is double walled with fully insulated sides, back and
bottom.

The exterior measures 27" deep (686mm) plus 6” (152mm)
stainless steel work deck by 19 1/2" high (495mm) from base to
front broiling surface and 24" high (610mm) in rear. Widths are
available in 6 sizes from 24" to 72".

Standard features include a 6" deep stainless steel, front mounted
work deck, stainless steel front mounted grease trough, 3 1/4"
deep, stainless steel slide-out grease and water pans, rear gas
connection and pressure regulator. Broiler may be used with or
without standard 4" legs.

One year limited parts & labor warranty.

stainless steel radiant heat

Job ____________ Item # ___________

GAS COUNTER TOP CHAR BROILERS

RADIANT MODELS

q Model CTB-24R
q Model CTB-30R
q Model CTB-36R
q Model CTB-48R q Model CTB-48GS
q Model CTB-60R q Model CTB-60GS
q Model CTB-72R q Model CTB-72GS

STANDARD FEATURES

q

Stainless steel top trims, back, sides and splash

q

16-Gauge, aluminized steel combustion chamber

q

Double-walled, fully insulated construction

q

High performance, 20,000 BTUH burners

q

Up to 220,000 BTUH per broiler, natural or LP gas

q

Independently controlled, adjustable valves for each burner

q

Heavy-duty 14-gauge stainless steel radiant heat deflectors
above each burner or Glo Stones

q

Stainless steel radiant heat deflectors between each burner

q

3 1/4" Stainless steel, slide out grease drawer & water pans

q

Stainless steel slide out water pans

q

Individually adjustable, 4-position tilting, floating rod type
grates, cast iron & meat grates available at no extra charge

q

Rear gas connection

q

Pressure regulator

q

One year limited parts & labor warranty

OPTIONS & ACCESSORIES

q

Glo Stones or radiants (field convertible)

q

Flame failure safety pilot valves (standard on CE models)

q

Slide out warming racks

q

Natural woodsmoke essence drawers, drop-down log rack or
log holders

Removable, steel griddle plate / breakfast griddle

q

q

Fish, meat, cast iron, square-rod grates or Fajita grates

q

Char broiler utensils including grate brush, steak turner,
spatula, meat fork, grease trough scrapper and grate lifter

Extra deep stainless steel work decks

q

Cut outs in extra deep work decks for sauce pans

q

q

48" Gas connector hoses with or without restraining cable

q

Stainless steel stand with or without casters

q

All stainless steel construction

q

Stainless steel splash guards

q

Overhead back shelves with additional grates

q

Condiment rail

CERTIFICATIONS

G

I

S

N

E

D

C

D

E

E

R

I

T

I

F

GLO STONE MODELS

q Model CTB-24GS
q Model CTB-30GS
q Model CTB-36GS

®

CERTIFIED

G

BAKERS

PRIDE

BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
www.bakerspride.com

Continuous product improvement is a policy of Bakers Pride Oven Company.

Therefore, specifications and design are subject to change without notification

ALL DIMENSIONS NOMINAL

FRONT VIEW SIDE VIEW

24" (610mm)

TOP VIEW

SHIPPING INFORMATION

Model

CTB-24R

CTB-30R

CTB-36R

CTB-48R

CTB-60R

CTB-72R

Under 500 lbs = Shipping Class # 70
Over 500 lbs = Shipping Class # 85

CTB-24GS

CTB-30GS

CTB-36GS

CTB-48GS

CTB-60GS

CTB-72GS

SPECIFICATIONS

Model

CTB-24R

CTB-30R

CTB-36R

CTB-48R

CTB-60R

CTB-72R

BAKERS

PRIDE

CTB-24GS

CTB-30GS

CTB-36GS

CTB-48GS

CTB-60GS

CTB-72GS

BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
www.bakerspride.com

Shipping Weight Crate Size

Lbs.

Kilos

118

260

150

330

182

400

200

440

266

585

377

830

Broiling Area

in.

534 x 610

21 x 24

686 x 610

27 x 24

838 x

33 x 24

1143 x

45 x 24

1448 x

57 x 2

1753 x

69 x424

Carton Dimensions

Width Depth Height

Inches

33

52.5

52.5

52.5

69

76.5

Inches Inches

mm mm mm

902

35.5

838

902

39.5

1334

902

39.5

1334

902

39.5

1334

889

35

1753

1016

40

1913

#Top

#of

Grates

mm

610

610

610

610

Burners

4

3

4

5

5

6

7

8

9

11

11

13

Cubic

Cubic

Feet

Meter

889

23.73

35

940

44.40

37

940

37

940

37

711

28

851

33.5

Width Depth* Height*

Inches

24

30

36

48

60

72

1.40

44.40

1.40

44.40

1.40

39.13

1.24

59.32

1.87

Overall Dimensions*

Inches Inchesmm mm mm

610

762

915

1219

1524

1829

*Depth includes 6" (152 mm) work deck
* Height without 4” legs

.75

MINIMUM CLEARANCES — all models

Non-Combustible Construction* Combustible Construction**

Inches Inches

Left Side

Right Side

Rear

Bottom

* In European Community Countries and North America.
** In European Community Countries only. NOT for North America.

0

0

0

4

mm mm

0

0

0

102

10

10

10

6

254

254

254

152

GAS SUPPLY

Model

838

838

838

838

838

838

24

610

24

610

24

610

24

610

610

24

610

24

Therefore, specifications and design are subject to change without notification

33

33

33

33

33

33

CTB-24R

CTB-30R

CTB-36R

CTB-48R

CTB-60R

CTB-72R

Continuous product improvement is a policy of Bakers Pride Oven Company.

CTB-24GS

CTB-30GS

CTB-36GS

CTB-48GS

CTB-60GS

CTB-72GS

BTUH KW CONNECTION

60,000

17.68

80,000

23.44

100,000

29.30

140,000

41.02

180,000

52.74

220,000

64.48

3/4"

3/4"

3/4"

3/4"

1"

1"

TS:11/02
