Multi-Function Processor Termination Module

(NIMP01/02)

E96-401

WARNING notices as used in this instruction apply to hazards or unsafe practices that could result in

personal injury or death.

CAUTION notices apply to hazards or unsafe practices that could result in property damage. NOTES highlight procedures and contain information that assists the operator in understanding the

information contained in this instruction.

WARNING

INSTRUCTION MANUALS

DO NOT INSTALL, MAINTAIN, OR OPERATE THIS EQ UIPMENT WITHOUT READING, UNDERSTANDING, AND FOLLOWING THE PROPER DAMAGE MAY RESULT.

Elsag Bailey

INSTRUCTIONS AND MANUALS; OTHER WISE, INJURY OR

RADIO FREQUENCY INTERFERENCE

MOST ELECTRONIC EQUIPMENT IS INFLUENCED BY RAD IO FREQUENCY INTERFERENCE (RFI). CAUTION SHOULD BE EXERCISED WITH REGARD TO THE USE OF PORTABLE COMMUNICATIONS EQUIPMENT IN THE AREA AROUND SUCH EQUIPMENT. PRUDENT PRACTICE DICTATES THAT SIGNS SHOULD BE POSTED IN THE VICINITY OF THE EQUIPMENT CAUTIONING AGAINST THE USE OF PORTABLE COMMUNICATIONS EQUIPMENT.

POSSIBLE PROCESS UPSETS

MAINTENANCE MUST BE PERFORMED ONLY BY QUALIFIE D PER SONNEL AN D ONLY AFTE R SEC URING EQUIPMENT CONTROLLED BY THIS PRODUCT. ADJUSTING OR REMOVING THIS PRODUCT WHILE IT IS IN THE SYSTEM MAY UPSET THE PROCESS BEING CONTROLLED. SOME PROCESS UPSETS MAY CAUSE INJURY OR DAMAGE .

AVERTISSEMENT

MANUELS D’OPÉRATION

NE PAS METTRE EN PLACE, RÉPARER OU FAIRE FONCTIONNER L’ÉQUIPEMENT SANS AVOIR LU, COMPRIS ET SUIVI LES INSTRUCTIONS RÉGLEMENTAIRES DE CET ÉGARD POURRAIT ÊTRE UNE C AUSE D’ACC IDENT OU DE DÉFAILL ANCE DU MA TÉRIEL.

Elsag Bailey

. TOUTE NÉGLIGENCE À

PERTURBATIONS PAR FRÉQUENCE RADIO

LA PLUPART DES ÉQUIPEMENTS ÉLECTRONIQUES SONT SENSIBLES AUX PERTURBATIONS PAR FRÉQUENCE RADIO. DES PRÉCAUTIONS DEVR ONT ÊTRE PRISES LORS DE L’UTILISATION DU MATÉRIEL DE COMMUNICATION PORTATIF. LA PRUDENCE EXIGE QUE LES PRÉCAUTIONS À PRENDRE DANS CE CAS SOIENT SIGNALÉES AU X ENDROITS VO ULUS DANS VOTR E USINE.

PERTURBATIONS DU PROCÉDÉ

L’ENTRETIEN DOIT ÊTRE ASSURÉ PAR UNE PERSONNE QUALIFIÉE EN CONSIDÉRANT L’ASPECT SÉCURITAIRE DES ÉQUIPEMENTS CONTRÔLÉS PAR CE PRODUIT. L’AJUSTEMENT ET/OU L’EXTRACTION DE CE PRODUIT PEUT OCCAS IONNER DES À-COUPS AU PROCÉD É CONTRÔLE LORSQU’IL EST INSÉRÉ DANS UNE SYSTÈME ACTIF. CES À-COUPS PEUVENT ÉGALEMENT OCCASIONNER DES BLESSURES OU DES DOMMAGES M ATÉREILS.

NOTICE

The information contained in this docume nt is s ubj ect to change wi thout noti ce. Elsag Bailey, i ts af fili at es , em pl oye es , an d a gen ts, a n d th e a u thor s an d co ntr ib utors to this publ ica ti on specif-

ically disclaim all liabilities and warranties, express and implied (including warranties of merchantability and fitness for a pa rt icu lar p urp os e) , fo r the ac cur a cy, cur r en cy, co mple t en ess, an d/ o r r eliability of t he i nfo r mati on contained herein and/or for the fitness for any particular use and/or for the performance of any material and/ or equipment selected in whole or part with the user of/or in reliance upon information contained herein. Selection of materials and/or equipment is at the sole risk of the user of this publication.

This document contains proprietary i nformation of Elsag Baile y, Elsag Bailey Proces s Automation, and is issued in strict confidence. Its use, or reproduc tion for use, for the re verse engineering, de velopment or manufacture of hardware or software described herein is prohibited . No part of this docume nt may be photocopied or reproduced without the prior written c onse nt of El sag B aile y.

Preface

Termination modules provide a connection from the plant equipment to the INFI 90 Multi-Function Processor Termination Module terminates a multi-function processor, INFI-NET

process modules. The NIMP01

to computer transfer module, INFI-NET to INFI-NET transfer module or multi-function processor interface module. The NIMP01 Multi-Function Processor Termination Module provides a termination point for two RS-232-C lines or one RS-232-C line and one RS-485 line, plus a serial link to connect an analog control station or digital control station through an NICS01 Control I/O Termination Module.

The NIMP02 termination module is the interface for redundant multi-function processor modules. The NIMP02 termination module requires an NIMP01 termination module to operate. This product instruction explains how to install and use the NIMP01 and NIMP02 Multi-Function Processor Termination Modules.

® Registered trademarks of Elsag Bailey Process Automation.

I-E96-401A

List of Effective Pages

Total number of pages in this manual is 48, consisting of the following:

Page No. Change Date

Preface Original

List of Effective Pages Original

iii through vii Original

1-1 through 1-6 Original

2-1 through 2-12 Original

3-1 through 3-4 Original 4-1 through 4-2 Original

5-1 Original

A-1 through A-3 Original B-1 through B-4 Original C-1 through C-2 Original D-1 through D-2 Original E-1 through E-3 Original

Index-1 through Index-2 Original

When an update is received, insert the latest changed pages and dispose of the superseded pages.

NOTE:

gin of the page adjacent to the changed area. A changed figure is indicated by a vertical bar in the outer margin next to the figure caption. The date the update was prepared will appear beside the page number.

On an update page, the changed text or table is indicated by a vertical bar in the outer mar-

I-E96-401A
