Baicells Technologies BRU3510 Users manual

BaiCells BRU3510 Base Station Installation Guide

V1.0

All rights reserved © BaiCells Technologies Co., Ltd.

1

Date

Version

Description

Author

30 Jun,2016

V1.0

Zhang Liuan

About This Document

This document is a user guide for the hardware installation of the base station
BRU3510.

Copyright Notice

BaiCells copyrights this specification. No part of this specification may be reproduced in
any form or means, without the prior written consent of BaiCells.

Disclaimer

This specification is preliminary and is subject to change at any time without notice.
BaiCells assumes no responsibility for any errors contained herein. For more information,
please consult our technical engineers.

Revision Record

Contact Us

Address: 555 Republic Drive, Suite 200 Plano, TX 75074, BaiCells Technologies Co., Ltd.
North America

E-mail: [e-mail]

Phone: [phone]

Website:

http://www.baicells.com/

1

Contents

1. Out-of-Box Audit ....................................................................................................... 5

Shipping List .............................................................................................................. 5 1.1

Appearance ............................................................................................................... 6 1.2

Base Station specifications ...................................................................................... 6 1.3

Base Station Accessories ......................................................................................... 7 1.4

2. Installation Preparation ............................................................................................ 8

Supporting Materials ............................................................................................... 8 2.1

Installation Tools ...................................................................................................... 8 2.2

Installation Environment ............................................................................................ 9 2.3

2.3.1 Locational Requirements .................................................................................... 9

2.3.2 Environmental Requirements ............................................................................. 9

2.3.3 Power Requirements .......................................................................................... 9

2.3.4 Grounding and Lightning Protection ................................................................ 10

3. Install Base Station .................................................................................................. 11

Installation Procedure............................................................................................ 11 3.1

Installation Steps ...................................................................................................... 11 3.2

3.2.1 Install on Wall ................................................................................................... 11

3.2.2 Install on Pole ................................................................................................... 13

3.2.3 Install Antenna Feeder System ......................................................................... 14

3.2.4 (Optional) Install GPS Antenna ......................................................................... 20

Connection Wire ...................................................................................................... 23 3.3

Power On .................................................................................................................. 24 3.4

Antennas Information .............................................................................................. 25 3.5

Regulatory Compliance ............................................................................................ 26 3.6

2

Content of Figure

Figure 1-1 Appearance of BRU3510 ............................................................................ 6

Figure 2-1 Grounding and Lightning Protection ......................................................... 10

Figure 3-1 Installation procedure of BRU3510 ........................................................... 11

Figure 3-2 Install on Wall ............................................................................................ 12

Figure 3-3 Drilling Locations on Wall .......................................................................... 12

Figure 3-4 Install Mounting Bracket on Base Station ................................................. 13

Figure 3-5 Install Mounting Bracket on Pole .............................................................. 13

Figure 3-6 Installation on Pole Complete ................................................................... 14

Figure 3-7 Omnidirectional Antenna Installation (1) ................................................... 15

Figure 3-8 Omnidirectional Antenna Installation (2) ................................................... 16

Figure 3-9 Assembling Procedure of Directional Antennas ....................................... 16

Figure 3-10 Transportation of the Antenna in the Height ........................................... 17

Figure 3-11 Directional Antenna Installation............................................................... 17

Figure 3-12 Antenna Waterproofing ........................................................................... 18

Figure 3-13 Antenna Waterproof Protection ............................................................... 19

Figure 3-14 Grounding Protection .............................................................................. 19

Figure 3-15 GPS Antenna Parts ................................................................................. 20

Figure 3-16 GPS Pole Installation .............................................................................. 21

Figure 3-17 GPS Cable Fixing ................................................................................... 22

Figure 3-18 GPS Connector Connect to Base Station .............................................. 22

Figure 3-19 Connect Antenna Feeder ........................................................................ 23

Figure 3-20 Connect Ethernet Cable ......................................................................... 23

Figure 3-21 Connect Power Cable ............................................................................. 24

Figure 3-22 LED Indicator .......................................................................................... 24

3

Contents of Table

Table 1-1 Shipping List ................................................................................................. 5

Table 1-2 Base Station Specifications .......................................................................... 6

Table 1-3 Base Station Accessories ............................................................................. 7

Table 2-1 Supporting Materials for Installing Base Station .......................................... 8

Table 2-2 Environmental Requirements of the Base Station ....................................... 9

Table 3-1 BRU3510 Indicator Description .................................................................. 24

Table 3-2 BRU3510 Antenna List ............................................................................... 25

4

Number

Item

Quantity

Description

1

BRU3510 base
station

1

Check the device’s tag to see if it is
consistent with the requirement

2

Power supply

1

100V~277V AC to -48V DC adaptor

3

Mounting bracket

2

Fixed accessories

4

Warranty

1

- 5 Certification

1

- 6 User guide

1

-

7

Waterproof
accessories

1

-

1. Out-of-Box Audit

Shipping List 1.1

Before opening the box, make sure the packaging cases are in good condition,
undamaged and not soaked. During the unpacking, avoid potential damaging impacts
from hits or excessive force.

Once unpacked, check the quantity to see if it is consistent with that in the shipping list
shown in Table 1-1.

Table 1-1 Shipping List

Note:

During the unpacking, if the outer package is damaged or soaked, stop unpacking and find the cause.

Report the issue to the vendor. For any shortage, miscarriage, or damage is identified, report the local

vendor within 10 days.

5

Item

Description

Working Mode

LTE TDD

Working Frequency

FCC: 2496MHz~2690MHz
IC: 2500MHz~2690MHz

Working Bandwidth

10MHz/20MHz

Max Tx Power

43dBm

Receiving Sensitivity

1. 10MHz: -102 dBm

2. 20MHz: -102 dBm

MIMO

2*2MIMO

Appearance 1.2

Figure 1-1 shows the appearance of BRU3510 base station.

Figure 1-1 Appearance of BRU3510

Dimension: 440mm (length) x 240mm (width) x 140mm (height)

Weight: about 11kg

Base Station specifications 1.3

Table 1-2 shows the specifications of the BRU3510 base station.

Table 1-2 Base Station Specifications

6

Accessory

Name

Power adaptor

Ethernet Cable
Size: 53mm*100mm*45mm

Installation Accessories
Including mounting bracket,
screw, nut, water-proof
tape, and so on.

Base Station Accessories 1.4

Table 1-3 shows the accessories of the BRU3510 base station.

Table 1-3 Base Station Accessories

7

Name

Description

Power line

< AWG16，e.g., AWG14
Shorter than 350m (1150 feet)

Antenna feeder

50 ohm feeder

Cable

Outdoor CAT5, CAT5e

Antenna

Omnidirectional, or directional antenna

Ground wire

16mm² yellow/green wire

GPS

GPS antenna, N type cable, and GPS mounting bracket

Level bar

Marking pen

Knife

Vice

Wrench

Percussion drill and

some drill heads

hammer

Cross
screwdriver

Cable vice

Tape measure

5mm L-shape allen

hexagon wrench

Water-proof

tape

Insulating tape

Ladder

2. Installation Preparation

Supporting Materials 2.1

Prepare accordingly the following supporting materials, given as Table 2-1.

Table 2-1 Supporting Materials for Installing Base Station

Installation Tools 2.2

The following tools are needed during the installation.

8
