Bag End TA6002-R Specifications

ACOUSTIC AND ELECTRICAL

Enclosure:

15 mm 11-ply birch plywood

Low Frequency Transducers:

2 - 6.5" Cone

1.5" Voice coil
30 oz. Magnet

High Frequency Transducer:

1" Exit compression driver

1.8" Titanium diaphragm
15 oz. Magnet
Radial horn

Input Connectors:

1 - Dual banana
2 - 1/4" Phone
2 - Neutrik Speakon

Grille:

16 Gauge black powder coated
perforated steel

Standard Hardware:

Rigging points
1 - 35 mm Stand adapter

Optional Hardware:

Forged steel eyebolts
Steel yoke kit
High impact abrasion resistant
UHMW polyethylene
bumper set

SYSTEM COMPONENTS

PHYSICAL

System Type:

2-way vented 0.6 ft

3

Impedance:

8 Ω

Finish:

Black textured paint

Dimensions:

22.5"h x 9"w x 11"d
58 cm x 23 cm x 28 cm
Trapezoidal, 10

0

taper per side

Weight:

27 lbs.
13 kg

Shipping Dimensions:

28" x 16" x 16"
72 cm x 41 cm x 41 cm

Shipping Weight:

34 lbs.
16 kg

TA6000-R TIME-ALIGN

®

BAG END

SPECIFICATIONS

APPLICATIONS:

Portable PA Systems

Audio Visual Presentations

Home Theater

Foreground Music Systems

Under Balcony Reinforcement

Church Sound Reinforcement

T

A6000-R

The TA6000-R is a compact portable speech range
loudspeaker system offering both high fidelity and high ef ficiency.
The Time-Aligned

™

studio quality sound provides detail and clarity
not found in other designs. For high power applications, the addi­tion of an INFRA

™

subwoofer extends the capabilities to full range
sound reinforcement. The TA6000-R is made from durable birch
plywood coated with black textured paint. Included are rigging
attachment points, a stand adapter and a rugged steel grille.

About T

ime-Align®Time-Align®assures that the fundamental

and overtones of a complex, transient, acoustical signal are pre­sented to the listener in the same relationship as the electrical
signal at the input terminals of the loudspeaker.

The conventional loudspeaker spreads out the sound in time:
when a rapid series of transients occur the results are blurring
and lost detail. With Time-Align

®

, a transient is presented as a
tight package of energy, with the same time relationships as the
natural sound. This means that a rapid series of transients will
be heard clearly.

True Time-Alignment

™

requires much more than just physically lin­ing up the loudspeaker components. It requires consideration of
the driver placement, driver delay and adjustment of the
crossover delay parameters. This achieves the precise simulta­neous acoustical arrival time of each driver throughout the
crossover region.

Along with state-of-the-art laboratory instruments, the propri­etary Time-Align

®

generator, built by Ron Wickersham, is used

in designing our loudspeaker systems. The Time-Align

®

gener­ator is founded upon different underlying mathematical princi­ples than are used in the more common Fourier based mea­surement equipment.

When comparing a genuine BAG END Time-Aligned

™

speaker sys­tem to any other, our additional design work is easy to hear and
appreciate. The dramatic clarity, realism, and overall pleasant
sound of our Time-Aligned

™

loudspeakers is noted throughout the

world.

Time-Align®, Time-Aligned™, Time-Alignment™ are trademarks of E.M. Long Associates.

BAG END Loudspeakers

22N272 Pepper Road

Lake Barrington, Illinois

60010 USA

Voice 847 382 4550

Fax [phone]

www.bagend.com

Crossover Network:

Passive Time-Align®equalizer
type at 2.1 kHz

Time Offset Between Drivers:

< ± 25 Microseconds

Frequency Response:

95 Hz to 20 kHz ±3 dB
(4π Steradians)

Sensitivity:

95 dB SPL (1W @ 1m)

Dispersion:

80

O

Horizontal (-6 dB)
60OVertical (-6 dB)
(Horn may be rotated 90Ofor
a 60O H x 80O V dispersion)

Power Handling:

150 W continuous sine wave
600 W instantaneous peak

JACKPLATE
ASSEMBLY
Z−320

LOGO
Z−307

GRILLE

POWDER
COATED STEEL
T6000G−1

WASHER
#8 BLACK
NYLON
Z−110 (4)

HF DRIVER
E−600

HORN
E−601

LF DRIVER
E−6A (2)

STAND ADAPTER
SSD−35

CROSSOVER

T6000X−1
HELD WITH SCREWS
#8 x 3/4" PHIL PH SMS
Z−101 (4)

SCR

EW
#10 x 1 1/4"
PHIL PH SMS
Z−104 (3)

SCREW
#8 x 3/4"
PHIL FH SMS
Z−103 (4

)

SCREW
#8 x 1/2"
PHIL PH SMS
Z−100 (8)

SCREW
#8 x 3/4"
PHIL PH SMS
Z−101 (4)

SCREW
#8 x 3/4"
PHIL PH SMS
Z−101 (8)

SYSTEM SCHEMATIC

JACKPLATE ASSEMBLY

SLEEVE

NEUTRIK
SPEAKON
NL4MP

HF DRIVER
AND HORN

− GREEN

+ ORANGE

BANANA JACK

LF DRIVER

LF DRIVER

TIP

1/4" PHONE

+ RED

+ RED

+ RED

− BLACK

− BLACK

+ RED

− BLACK

− BLACK

CROSSOVER

NOT SHOWN:
ACOUSTIC DAMPENER Z−500 (2)

PACKING FOAM SET Z−578 (1)
PLASTIC BAG Z−626 (1)
SHIPPING CARTON Z−644 (1)

BAG END Loudspeakers 22N272 Pepper Road Lake Barrington, Illinois 60010 Phone [phone] Fax [phone]

RIGGING BRACKET
Z−213 (2)

BOLT

5/16"−18 x 1 1/4"
HEX SOCKET FH CAP
Z−120 (3)

ACOUSTIC FOAM
Z−528

GASKET TAPE
Z−516

The Neutrik Speakon NL4MP connector is a keyed, high current, four conductor device which allows both the high and low frequency
signals for a bi-amped loudspeaker system to run through the same 4-conductor cable. Note that all four conductors on both connec­tors are wired in parallel, but only two conductors are connected to the drivers in the enclosure. This permits an easy parallel connec­tion to other similar loudspeakers (if your amplifier can handle the low impedance load!) and allows the use of a short “jumper”
between the subwoofers and the mid/high speakers in a bi-amped system. Banana and 1/4" phone jacks are also provided.

TA6000-R

RUBBER SEAL
1/4" X 21"
Z−515 (2)

GASKET
LOOP
Z−519

RIGGING
POINT
