AW-NB101

IEEE 802.11b/g/n

Combo slim module

User’s Manual

[鍵入文字]

I. Introduction

i. Overview

Azurewave AW-NB101 combo wireless slim module is a highly integrated wireless local area

network (WLAN) solution to let users enjoy the digital content through the latest wireless technology without using extra cables and cords. It provides easy-to-use, high performance, cost effective and low power solution. Moreover, AW-NB101 enables compatible high-speed wireless connectivity within home, business and public access wireless networks.

Compliant with the IEEE 802.11b/g/n standard, AW-NB101 uses Direct Sequence Spread Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM), BPSK, QPSK, CCK and QAM baseband modulation technologies. When you are using AW-NB101, a high level of integration and full implementation of the power management functions specified in the IEEE 802.11 standard can minimize system power requirements.

The AW-NB101 802.11b/g/n Wireless Combo Slim Module provides up to 128-bit level of WEP security to your wireless data transfers. It is able to run in the operating systems of Windows XP/Vista in either Infrastructure mode or Ad-Hoc mode. Comparing to previous wireless technology, AW-NB101 got great improvements on speed and range. The wireless range increased up to two times wider and coverage area reduced the situation of dead spots. “Multiple In, Multiple Out” (MIMO) technology uses signal reflections to increase the range and maintain wireless connections up to five times farther; therefore, with MIMO, AW-NB101 is able to double the data rate up to 300Mbps.

ii. Features

 slim module  Compliant with IEEE802.11 b/g/n standard  2 Antenna to support 1(Transmit)  1 (Receive) technology and Bluetooth  Antenna WLAN RX diversity  High speed wireless connection up to 150 Mbps  Low power consumption and high performance  Enhanced wireless security  Fully qualified Bluetooth 4.0 and BT 3.0HS  Enhanced Data Rate(EDR) compliant for both 2Mbps and 3Mbps supported  Fully speed operation with Piconet and Scatternet support

[鍵入文字]

iii. Product Review

When the USB wireless module is transmitting data through connection, LED indicator will blink.

1. Connection Mode

◎Infrastructure Mode

Infrastructure mode needs an access point to establish the network, which can provide wireless accesses

within valid range for users to communicate with others or transmit data with a wired network. There are

several benefits of Infrastructure networking:

√ Roaming: a wireless LAN enabled computer can physically move from the operating range of one

access point to the other without losing connection. There is a quick association made between new access point and wireless device as the computer traverses from the coverage of one access point to another. √ Range Extension: each wireless LAN enabled computer within the range of access point can communicate with other wireless LAN enabled computers within the effective range from the access point. √ Wired to wireless LAN connection: the access point will establish a bridge between wireless LAN and other wired counterparts.

[鍵入文字]

Infrastructure Mode

◎Ad-hoc Mode

The difference between Ad-hoc mode and Infrastructure mode is that Ad-hoc mode does not need the

access point or router. When you use this mode, your computer will act as a server within the valid range

and connect directly to others in the same LAN workgroup.

Ad-hoc Mode

It is recommended to choose this mode when there is no access point showed on your wireless network.

[鍵入文字]

II. Installation

i. System Requirements

Before you install AW-NB101, please make sure your system meets the following requirements.

*Desktop or Laptop with USB 1.1/2.0 port *Minimum of 64MB system memory *Operating system: XP/Vista/Windows 7 *An optical drive/CD-ROM for utilities and driver installation

ii. Hardware Installation

1. Find an available USB 1.1/2.0 port on your desktop or laptop.

2. Plug AW-NB101 Wireless PCI-E Module into USB port of desktop or laptop.

iii. Operation Range

The operating range of AW-NB101 varies from the working environment. However, this device made improvement on speed and range, which also reduced dead spots in coverage area. AW-NB101 is two times wider than previous wireless products. By default, this USB wireless adapter will automatically adjust the data rate. The transmission speed may vary according to the environment. The closer the wireless stations are the better the signal and transmission speed they will receive.

[鍵入文字]

iv. Setup: Windows XP OS

If your computer is running a Windows operating system, it will automatically detect the AW-NB101 after the system boots up and displays a “Found New Hardware Wizard” window. Please click [Cancel] and proceed with the following steps.

1. Find out the Driver, and launch the Setup Wizard
