AzureWave Technologies MF070 Users manual

WW-MF070

LTE PCIe M.2 Module card

Signaling test User Guide

Version 0.1

Document

release

Ver. 0.1 2014/7/16 Initial version Renton Tao Ivan Chen
Ver. 0.2 2014/7/18 Add antenna gain information Renton Tao Ivan Chen

Date Modification Initials Approved

- 1 -

Step1: Select power source

You can choose your power source by micro USB or 5V DC jack.

Step2: Connect with host device

Put in SIM card, connect antenna to base station and micro USB to your PC then you can start signaling
testing.

*AT commands are supported through USB interface.
