AzureWave Technologies CU282 User Manual

AW-CU282

Wireless LAN Module IC

MFG Tool Command User Guide

Version 0.1

Document

release

Ver. 0.1 2013/3/17 Initial version Renton Tao Ivan Chen

Date Modification Initials Approved

- 1 -

Step1: Initial Command

As the information showed on your screen, please enter these commands below to start your test.

Command: 1 Wi-Fi testing mode

Step2: Generate 802.11 b/g/n Packet

(1)Command: 22 1 12 1

22: Initial transmit power in the antenna

1: Set the wanted channel (1~14 for B/G/N mode)

12: Set the wanted power, typically G mode: 12 dBm/ B mode: 15 dBm

1: Set the mode, 1G mode & N mode , 0 B mode

(2)Command: 112 0 (only for N mode)

112: N mode HT20/40.

0: for HT20/40. 0HT20, 1HT40

(3)Command: 25 1 13

25: Set duty cycle, packet mode.

1: Data rate enable

13: Data rate set up

A mode &B mode & G mode

1Mbps 5.5Mbps 11Mbps 6Mbps 9Mbps 12Mbps 18Mbps 24Mbps

1 3 4 6 7 8 9 10

36Mbps 48Mbps 54Mbps

11 12 13

N mode

MCS0 MCS1 MCS2 MCS3 MCS4 MCS5 MCS6 MCS7 MCS8

15 16 17 18 19 20 21 22 23

After you type above command, you can measure the 802.11b/g/n packet by your RF test instrument (exp:

Agilent 4010, IQview…).

(4) Command: 25 0

Stop transmitting packet signal.
