AzureWave Technologies CM299 Users manual

AW-CM299

IEEE 802.11 1X1 ac/a/b/g/n

Wireless LAN + Bluetooth Module

Datasheet

Version 0.5

- 1 -

Document

release

Date

Modification

Initials

Approved

Version 0.1

2016/11/18

Draft version

Grace Liu

Daniel Lee

Version 0.2

2017/3/28

1-4. Specifications Table

5. Mechanical Information

Grace Liu

Daniel Lee

Version 0.3

2017/4/24

5. Mechanical Information

Grace Liu

Daniel Lee

Version 0.4

2017/5/16

1-2. Block Diagram
1-4. Specifications Table

4. Pin Definition

Grace Liu

Daniel Lee

Version 0.5

2018/1/30

1. Add 6. Shipping information

2. Modify input power information in
1-4. Specifications Table and

2.Electrical Characteristic

3. Modify ESD rating in 2.Electrical
Characteristic

4. Add Federal Communication
Commission Interference Statement

Grace Liu

Daniel Lee

- 2 -

1. General Description

1-1. Product Overview and Functional Description

AzureWave Technologies, Inc. introduces the IEEE 802.11ac/a/b/g/n 1X1 WLAN & Bluetooth module -

-- AW-CM299. The module is targeted to mobile devices including Notebook, TV, Tablet and Gaming
Device which need small package module, low power consumption, multiple interfaces and OS support.

By using AW-CM299, the customers can easily enable the Wi-Fi, and BT embedded applications with
the benefits of high design flexibility, short development cycle, and quick time-to-market.
Compliance with the IEEE 802.11ac/a/b/g/n standard, the AW-CM299 uses Direct Sequence Spread
Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM), DBPSK, DQPSK, CCK and
QAM baseband modulation technologies. A high level of integration and full implementation of the power
management functions specified in the IEEE 802.11 standard minimize the system power requirements
by using AW-CM286NF. In addition to the support of WPA/WPA2 and WEP 64-bit and 128-bit
encryption, the AW-CM299 also supports the IEEE 802.11i security standard through the implementation
of Advanced Encryption Standard (AES)/Counter Mode CBC-MAC Protocol (CCMP), Wired
Equivalent Privacy (WEP) with Temporal Key Integrity Protocol (TKIP), Advanced Encryption Standard
(AES)/Cipher-Based Message Authentication Code (CMAC), and WLAN Authentication and Privacy
Infrastructure (WAPI) security mechanisms.
For the video, voice and multimedia applications the AW-CM286NF support 802.11e Quality of Service
(QoS). The device also supports 802.11h Dynamic Frequency Selection (DFS) for detecting radar
pulses when operating in the 5GHz range.
For Bluetooth operation, AW-CM299 is Bluetooth 4.2 (supports Low Energy).
AW-CM299 supports SDIO for WLAN and BT to the host processor.
AW-CM299 module adopts Marvell’s latest highly-integrated dual-band WLAN & Bluetooth SoC--­88W8887. All the other components are implemented by all means to reach the mechanical specification
required.

- 3 -

1-2. Block Diagram

A simplified block diagram of the AW-CM299 module is depicted in the figure below.

- 4 -

1-3. Key feature:

 Small footprint: 22mm(L) x 11mm(W) x 2.3mm(H)Max
 IEEE 802.11ac compliant, 1x1 spatial stream with data rates up to MCS9 (433 Mbps)
 Bluetooth 4.2 (supports Low Energy (LE))
 SDIO 3.0 device interface may be used as host interface for WLAN/Bluetooth
 On board dual band chip antenna
 Multiple power saving modes for low power consumption
 Lead-free design

- 5 -

Model Name

AW-CM299

Product Description

Wireless LAN + Bluetooth Combo Module

WLAN Standard

IEEE 802.11ac/a/b/g/n, Wi-Fi compliant

Bluetooth Standard

Bluetooth 4.2 complaint with Bluetooth 2.1+Enhanced Data Rate (EDR)

Host Interface

 SDIO 3.0 device interface (SPI, 1-bit SDIO, 4-bit SDIO transfer

modes at full clock range up to 208 MHz)

Major Chipset

Marvell 88W8887

Dimension

22mm x 11mm x 2.3mm(Max)

Weight

TBD

Antenna

On Board Chip Antenna

Operating Conditions

Voltage

3.3V/1.8V+- 10%

Temperature

Operating: -20 ~ 85oC ; Storage: -40 ~ 85oC

Electrical Specifications

Frequency Range

2.4 GHz ISM radio band / 5 GHz Unlicensed National Information

Infrastructure (U-NII) band

Number of Channels

802.11a: USA, Taiwan – 12/4

Most European Countries –19
Japan – 4

802.11b: USA, Canada and Taiwan – 11

Most European Countries – 13
France – 4

802.11g: USA, Canada and Taiwan – 11

Most European Countries – 13
Japan – 13

802.11n(HT20): Channel 1~13(2412~2472)

802.11n(HT40): Channel 1~7(2422~2472)

Modulation

DSSS,OFDM,DBPSK,DQPSK,CCK, 16-QAM, 64-QAM 256-QAM for WLAN
GFSK (1Mbps), Π/4 DQPSK (2Mbps) and 8DPSK (3Mbps) for Bluetooth

Output Power

WLAN(conducted):
WLAN G band:
11b:16dBm +/- 2dB(11Mbps)
11g:14dBm +/- 2dB (54Mbps)
11n HT20:13dBm +/- 2dB(MCS7)
11n HT40:12dBm +/- 2dB(MCS7)
WLAN A band:
11a:13dBm +/- 2dB(54Mbps)
11n HT20:12dBm +/- 2dB(MCS7)
11n HT40:11dBm +/- 2dB(MCS7)
11ac VHT_20:11dBm +/- 2dB(MCS8)
11ac VHT_40:10dBm +/- 2dB(MCS9)
11ac VHT_80: 7dBm +/- 2dB(MCS9)

Bluetooth(conducted):
BDR/EDR:2dBm+-2dB(class2)

1-4. Specifications Table

- 6 -
