Azumi S A SP 002 User Manual
1
Contents
Safety ................................................................................................................ 3
Environment .................................................................................................... 4
1 Getting Started .............................................................................................. 5
1.1 Getting to know your touch phone................................................... 5
1.2 Installing the SIM card and storage card .......................................... 5
1.3 Charging the Battery ....................................................................... 6
1.4 Starting up the device ...................................................................... 6
1.5 Status Icons ..................................................................................... 7
2 Using phone features .................................................................................... 9
2.1 Turning the phone function on and off ............................................. 9
2.2 Making a call .................................................................................. 9
2.3 Answering and Ending a call ........................................................... 9
2.4 In-call options ............................................................................... 10
2.5 Using call history .......................................................................... 10
3 Setting on your device................................................................................. 10
4 ActiveSync ................................................................................................... 14
5 Contacts....................................................................................................... 16
6 Exchanging Messages ................................................................................. 18
7 Internet ........................................................................................................ 22
7.1 Ways of Connecting to the Internet ................................................ 22
7.2 Browser ......................................................................................... 22
8 Experiencing Multimedia ........................................................................... 23
8.1 Camera & Picture .......................................................................... 23
8.2 Music ............................................................................................ 23
8.3 FM Radio ...................................................................................... 26
8.4Sound recorder ............................................................................... 26
9 Other applications ...................................................................................... 26
(Model:IKU A55)
2
9.1 Calendar ........................................................................................ 26
9.2 Alarm Clock .................................................................................. 26
9.3 Calculator ...................................................................................... 28
SAR ................................................................................................................ 29
3
Safety
Never attempt to disassemble your phone. You alone are responsible for how
you use your phone and any consequences of its use.
As a general rule, always switch off your phone wherever the use of a phone is
prohibited. Use of your phone is subject to safety measures designed to protect
users and their environment.
Do not use your phone in damp areas (bathroom, swimming pool…). Protect it
from liquids and other moisture.
Do not expose your phone to extreme temperatures lower than - 10°C and
higher than + 55°C.
The physicochemical processes created by chargers impose temperature limits
when charging the battery. Your phone automatically protects the batteries in
extreme temperatures.
Do not leave your phone within the reach of small children (certain removable
parts may be accidentally ingested).
Electrical safety: Only use the chargers listed in the manufacturer’s catalogue.
Using any other charger may be dangerous; it would also invalidate your
warranty. Line voltage must be exactly the one indicated on the charger’s serial
plate.
Aircraft safety: When traveling by plane, you will need to switch your phone
off when so instructed by the cabin crew or the warning signs.
Using a mobile phone may be dangerous to the operation of the aircraft and may
disrupt the phone network.
Its use is illegal and you could be prosecuted or banned from using cellular
networks in the future if you do not abide by these regulations.
Explosive materials: Please comply with warning signs at petrol station asking
you to switch your phone off. You will need to comply with radio equipment
usage restrictions in places such as chemical plants, fuel depots and at any
location where blasting operations are under way.
Electronic equipment: To avoid the risk of demagnetization, do not let
electronic devices close to your phone for a long time.
Electronic medical equipment: Your phone is a radio transmitter which may
interfere with electronic medical equipment or implants, such as hearing aids,
pacemakers, insulin pumps, etc. It is recommended that a minimum separation
of 15 cm be maintained between the phone and an implant. Your doctor or the
4
manufacturers of such equipment will be able to give you any advice you may
need in this area.
Hospitals: Always make sure that your phone is switched off in hospitals when
so instructed by warning signs or by medical staff.
Road safety: Do not use your phone when driving. In order to give your full
attention to driving, stop and park safely before making a call. You must comply
with any current legislation.
Distance of operation: This phone model has been tested and meets
radiofrequency exposure guidelines when used as follows:
• Against the ear: Place or receive a phone call and hold the phone as you would
a wire line telephone.
• Body worn: When transmitting, place the phone in a carry accessory that
contains no metal and positions the phone a minimum of 2.5 cm form your body.
Use of other accessories may not ensure compliance with radiofrequency
exposure guidelines. If you do not use a body worn accessory and are not
holding the phone at the ear, position the phone a minimum of 2.5 cm from your
body,
• Data operation: When using a data feature, position the phone a minimum of
2.5 cm from your body for the whole duration of the data transmission.
Environment
Packaging: To facilitate the recycling of packaging materials, please obey the
sorting rules instituted locally for this type of waste.
Batteries: Spent batteries must be deposited at the designated collection points.
The product: The crossed-out waste bin mark affixed to the product means that
it belongs to the family of electrical and electronic equipment.
To promote the recycling and recovery of waste electrical and electronic
equipment (WEEE) and at the same time safeguard the environment, European
regulations require you to obey the sorting rules instituted locally for this type
of waste.
5
1 Getting Started
1.1 Getting to know your touch phone
1.2 Installing the SIM card and storage card
You need to remove the back cover before you can install the SIM card. Also,
make sure to always turn off the power before installing or replacing the SIM
card.
Note: The battery can’t be uninstalled.
To remove the back cover
1. Make sure your device is turned off.
2. Firmly hold the device with both hands and the front panel facing down.
3. Push the back cover up with your thumbs until it disengages from the device
and then slide it up to remove.
To install the SIM card
The SIM card contains your phone number, service details, and phonebook/
message memory.
1. Remove the battery if it is installed.
2. Locate the SIM card slot, and then insert the SIM card with its gold contacts
facing down and its cut-off corner facing out the card slot.
Note: The phone can be supported the double SIM cards. Your phone is
supported both 2G SIM card and 3G SIM card.
You can select primary card, primary card supports 3G/2G service, secondary
card only supports 2G service.
Some legacy SIM cards may not function with your device. You should consult
with your service provider for a replacement SIM card. There may be fees for
this service.
To install a memory card
To have additional storage for your images, videos, music, and files, you can
purchase a memory card and install it into your device.
1. Make sure that your device is turned off, and then remove the back cover.
2. Locate the memory card slot on the upper part of the exposed right panel.
3. Insert the memory card into the slot with its gold contacts facing down until it
clicks into place.
6
Note: To remove the memory card, press it to eject it from the slot.
1.3 Charging the Battery
New batteries are shipped partially charged. Before you start using your device,
it is recommended that you charge the battery. Some batteries perform best after
several full charge/discharge cycles.
Note: Only the AC adapter and USB sync cable provided with your device must
be used to charge the device.
Connect the USB connector of the AC adapter to the sync connector on your
device, and then plug in the AC adapter to an electrical outlet to start charging
the battery.
As the battery is being charged while the device is on, a charging icon appears
in the title bar of the Home screen. After the battery has been fully charged, a
full battery icon appears in the title bar of the Home screen.
Warning: • As a safety precaution, the battery stops charging before it overheats.
1.4 Starting up the device
Power on/off
To power off your phone, press & hold POWER. On release, the Phone options
menu opens. Select ‘Power off’ and confirm.
To power on again, press & hold POWER.
Silent mode
To silence your phone, press Settings > Audio Profiles, select ‘Silent’ check
box.
Screen sleep
After a period of inactivity, your screen will go to sleep (display will turn black).
In sleep, your phone uses less battery power. You can control this behavior:
Set screen timeout period
1. Select Settings > Display.
2. Select Sleep. Select a time from the menu.
Lock screen & put phone to sleep
Except when on a phone call, from any screen, press POWER (immediately).
While not on a call, to lock your control buttons and screen from accidental
touch activation, press POWER.
You can increase the security of your phone by setting a screen unlock pattern.
7
Once set, in order to unlock your screen, you’ll have to draw the correct unlock
GPRS service connected,
data flowing
Song is playing
pattern. You can set your screen unlock pattern as follows:
1. Select Settings > Security > Screen lock.
2. Set or change your unlock pattern by selecting either Set unlock pattern or
Change unlock pattern, as applicable.
3. Follow the prompts to define your pattern.
Note: You must slide your finger along the screen to create the pattern, not
select individual dots. Connect at least four dots.
Home screen
1. The Home screen actually extends beyond the screen width. On Home screen,
slide your fingertip left or right along the screen to reveal the full width of the
Home screen. This additional space gives you more room to customize Home
with applications, shortcuts, and widgets.
2. Create Home screen shortcuts and widgets:
•Touch & hold the Home screen to open ‘WIDGETS’.
• Select the widget you want to display on home screen, then touch & hold an
application icon. It can be added to the Home screen; back to the home screen to
see it.
3. To remove a shortcut or widget from your Home screen, touch & hold the
item to enter “remove”.
4. Move objects on the Home screen
• To move an icon or other item on the Home screen, you must first touch &
hold it to enter move mode. The object will magnify when it’s ready to be
moved.
• To move an item to a section of the Home screen not in view, move it to the
edge of the screen and hold it there for a moment. The screen view will shift;
position the object and release.
1.5 Status Icons
Connection status icons
Along the top of your phone screen is the status bar. Icons will appear, notifying
you of a new message, Missing call, or something else you should notice.
8
Bluetooth is on
Connected the PC
GPS is working
Ringer is off
(Vibrate only)
SMS/MMS
WLAN service connected
Call in progress
Wireless services are off
(Airplane mode)
Missed call
Phone on mute
Alarm is set
Connected the earphone
Battery electric quantity
Battery is charging
Read your notifications
When you see a notification in the status bar, touch the bar and slide your finger
down the screen to open the list of notifications displayed in the sliding window.
Ongoing notifications report activities such as call forwarding ON, current call
status, song playing.
Notifications report the arrival of new messages, calendar events, and alarms.
You can clear notifications list by selecting ‘Clear’ notifications at the top of the
notifications window.
To open the message, reminder, or other notification, you can touch the items.
To close the notifications window, slide your finger up the screen.
Notes: On the home screen, touch the bar and slide your finger down the
screen to open the list of notifications displayed in the sliding window, you
can touch the icon on the top of the screen (such as Wi-Fi, Bluetooth, Data
connection, Airplane mode, Brightness) to open or close the selected
function.
9
2 Using phone features
2.1 Turning the phone function on and off
To enable or disable Airplane Mode
In many countries, you are required by law to turn off the phone while on board
an aircraft. Another way to turn off the phone function is to switch your device
to Airplane Mode.
When you enable Airplane Mode, the phone function, Bluetooth, and WLAN on
your device are turned off.
1. Touch Settings > Network & Internet> Airplane mode.
2. Touch ‘Airplane mode’ to enable or disable.
When you disable Airplane mode, the phone function is turned back on and the
previous state of Bluetooth and WLAN are restored.
Adjusting the volume
Press Volume button on the side of the phone to show the volume screen.
If the phone is in vibrating mode, the voice will be muted automatically and the
device will vibrate when there is an incoming call.
2.2 Making a call
On Home screen, touch Phone to enter the dial screen.
Touch the on-screen dial pad to enter a number, touch ‘Delete’ button to delete
numbers you’ve entered. Touch & hold to delete all the numbers in the field.
To dial a number, touch ‘Voice Call’ button to select SIM1 card or SIM2 card to
make a call. To end a call, touch ‘END’ button (Red icon).
1. Call log tab: Select an entry listed in the log to call the number.
2. Contacts tab: Contacts with phone numbers are listed. Select a contact, and
then select the phone number to dial the call.
2.3 Answering and Ending a call
When you receive a phone call, the incoming voice call screen will appear,
allowing you to either answer or ignore the call.
1. To answer an incoming call, swipe up to answer.
2. To reject a call, swipe down to reject.
10
2.4 In-call options
While on a call, reveal the in-call options: Speaker, Mute, Hold, End.
Note that if Bluetooth services are on and you are connected to a hands-free
device, the more menu indicator will show Bluetooth on.
1. Speaker: To use the speaker, select ‘Speaker’ so it shows a white bar. To turn
it off, select it again so the bar is unfilled. The status bar will display this icon
when the speaker is on.
2. Mute: To mute your side of the conversation, select ‘Mute’ so it shows a
white bar. To turn it off, select it again so the bar is unfilled. The status bar will
display this icon when Mute is on.
3. Hold: To put an active call on hold, select ‘Hold’ so it become regain. To
resume the call, or take the call off hold, select it again so the bar is unfilled. If
you want to take a call while already on a call, you can hold the first call.
4. Add call: If you need to enter numbers while on a call, touch ‘Add call’.
5. Incoming call: During call in progress, if you are on a call (“call in progress”)
when another call comes in (“incoming call”), you have a few choices:
• Answer the incoming call and place the call in progress on hold.
• If you don’t want to interrupt your call in progress, then touch ‘END’.
2.5 Using call history
1. The missed call icon appears in the title bar when you missed a call.
2. Use ‘Call log’ tab to check who the caller was, or view all your dialed
numbers, and received calls. To open ‘Call log’ tab, touch ‘Call log’ button in
the phone screen to enter the call history list.
3. Scroll to select the contact or number you want to dial, touch ‘Call’ button.
4. Tap and hold the selected contact you want to call, and then you can make to
do the following options of call, edit number before call, copy to clipboard.
5. Touch contact you will see a list, then you can make send message, add to
blacklist and so on.
3 Setting on your device
Control phone-wide settings from Settings.
Loading...
