ASC290
Ultra-Portable Vacuum Cleaner
USER MANUAL
PLEASE KEEP THIS USER MANUAL FOR FUTURE USE
USER MANUAL CONTENTS
SAFETY INSTRUCTIONS......................................................................................2
PACKAGE CONTENTS......................................................................................5
PRODUCT OVERVIEW.......................................................................................5
USING THE PRODUCT.......................................................................................6
CLEANING & MAINTENANCE..........................................................................7
TECHNICAL SPECIFICATIONS.........................................................................11
SAFETY INSTRUCTIONS
IT IS STRONGLY ADVISED THAT YOU READ ALL OF THE PROVIDED SAFETY GUIDES AND
OPERATING INSTRUCTIONS IN THIS USER MANUAL FIRST BEFORE USING THE PRODUCT.
Personal Safety:
• Store indoors in a dry place out of the reach of children.
• Always use responsibly. This appliance can be used by children aged 10 years
and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
• Do not let children play with the appliance; supervise children using or
maintaining the appliance.
• Use only manufacturer’s recommended attachments as described in this
manual; misuse or use of any accessory or attachment other than those
recommended, may present a risk of personal injury.
• Take extra care when cleaning stairs.
• Keep the appliance and accessories away from hot surface.
• Do not block the appliances openings or hinder airow. Keep openings free
of any objects including dust, lint, clothing, ngers (and all parts of the body).
• Particularly keep hair away from openings and moving parts.
2
Electrical Safety:
• Only use batteries and chargers supplied by the manufacturer.
• Never modify the charger in any way.
• The charger has been designed for a specic voltage. Always check that the
main voltage is the same as stated on the rating plate.
• A charger that is suitable for one type of battery pack may create a risk of re
when used with another battery pack.
• Before use, check the charger cord for signs of damage or ageing. A
damaged or entangled charger cord increases the risk of re and electric
shock.
• Do not tug, knot, sharply bend, or otherwise abuse the cord.
• Never carry the charger by the cord.
• Do not pull the cord to disconnect from a socket, grasp the plug and pull to
disconnect.
• Do not wrap the cord around the charger when storing.
• Keep the charger cord away from hot surfaces and sharp edges.
• The supply cord cannot be replaced. If the cord is damaged, the charger
should be discarded and replaced.
• Do not handle the charger or the appliance with wet hands.
• Do not store or charge the appliance outdoors.
• The charger must be removed from the socket before removing the battery,
cleaning or maintaining the appliance.
Battery Safety:
• This appliance includes Li-ion batteries. Do not incinerate batteries or expose
to high temperatures, as they may explode.
• Liquid discharged from the battery may cause irritation or burns.
• In case of emergency, seek professional help immediately.
• Leaks from the battery cells can occur under extreme conditions. Do not
touch any liquid leaked from the battery. If the liquid comes in contact with
the skin, wash with soap and water immediately. If the liquid gets into the
eyes, rinse with clean water immediately for a minimum of 10 minutes and
seek medical attention. Wear gloves to handle the battery and dispose
immediately in accordance with local regulations.
• Shorting the battery terminals may cause burns or re.
• When the battery pack is not in use, keep it away from paper clips, coins,
keys, nails, screws or other small metal objects that could make a connection
from one terminal to another.
• When you dispose of the appliance, remove the battery and dispose of the
battery safely in accordance with local regulations.
3
Service:
• Before using the appliance and after any impact, check for signs of wear or
damage and repair as necessary.
• Do not use the appliance if any part is damaged or defective.
• Repairs should be carried out by a service agent or a qualied person in
accordance with relevant safety regulations. Repairs by unqualied persons
could be dangerous.
• Never modify the appliance in any way as this may increase the risk of
personal injury.
• Only use replacement parts or accessories provided or recommended by
manufacturer.
Intended Use:
• This appliance is designed for domestic dry vacuum cleaning only.
• Do not pick up liquids or use on wet surfaces.
• Do not pick up anything that is ammable, burning or smoking.
• Use as described in this manual only.
• Do not use on concrete, tarmacadam or other rough surfaces.
Warning:
• Do not use water, solvent, or polish to clean the outside of the appliance;
wipe clean with a slightly damp cloth.
• Never immerse the unit in water and do not clean in a dishwasher.
4
PACKAGE CONTENTS
• Aztech ASC290
• Charger
PRODUCT OVERVIEW
• 2-in-1 Crevice
• Wall Mount Bracket
COMPONENTS
12
• User Manual
• Warranty Policy
1 Main Unit 7 Dust Cup
2 Dust Cup Release Button 8 Dust Cup Cover Release Button
3 Tube Release Button 9 Conductive Aluminium Tube
4 Charging Port 10 Motorised Brush
5 Power Button 11 Speed Control Button
6 Handle 12 Motorised Bedding Brush
(Optional)
5
USING THE PRODUCT
STEP 1
Attach and secure the aluminium tube to the noz zle.
To detach the aluminium tube, press the Tube Release Button and pull the tube away
from the nozzle.
STEP 2
Attach and secure the motorised brush to the aluminium tube.
To detach the motorised brush, press the release button and pull the motorised brush
away from the tube.
6
STEP 3
Press the Power Button to switch on/off the vacuum.
Press the Speed Control Button to alternative between the two speed options.
Air Vent
Power
Button
IMPORTANT: Do not block the air vent. Keep it clean from dust, to prevent the motor from
overheating.
Speed
Control
Button
CLEANING & MAINTENANCE
EMPTYING THE DUST CUP
To empty the dust cup, press the Dust Cup Cover Release Button to open the cover.
7
MAINTAINING THE FILTER
STEP 1
Press the Dust Cup Release Button to detach the dust cup from the main unit.
STEP 2
Rotate the top of the dust cup counterclockwise to separate it from the dust cup.
8
STEP 3
Lift the lter case up, and remove the lter.
STEP 4
Gently rinse the lter case and HEPA lter thoroughly.
Ensure the lter case and HEPA lter are completely dry, before reassembling them.
9
CHARGING THE BATTERY
STEP 1
When the Battery Power Indicator is showing only one blinking blue LED, the battery is low.
Battery Power Indicator
LED Off
LED Off
Blinking LED
Charging
Port
STEP 2
Plug the charger into the charging port.
The battery is full when all three LEDs light up in solid blue.
10
Solid Blue
Solid Blue
Solid Blue
TECHNICAL SPECIFICATIONS
Battery 2000 mAh Li-ion battery
Voltage 22.2 V
Motor Power 120 W
Charging Time 4–5 hours
Usage Time 40 minutes (low speed), 25 minutes (high speed)
Suction Power 12 Kpa
Noise Level 70 db
Speed Options High & Low
Dust Capacity 0.8 L
Product Weight 2.08 kg
11
