Azio KB531RM Quick Start Guide

The Right Connection™ Model: KB531RM

Wireless RF Ke yboard & Mouse Combo

Quick Installation Guide

Copyright Statement

is the registered trademark of AZiO Corporation. All the products and
product names mentioned herein are the trademarks or registered trademarks of
their respective holders. Copyright of the whole product as integ ration, including its
accessories and softwa re, belongs to AZiO Corporation. Without the permission of
AZiO Corporation, any individual or party is not allowed to copy , plagiarize, imitate or
translate into other languages.

All the photos and product specifications mentioned in this manual are for
reference only. Actual throughput and operating distances will vary due to
software & hardware setup and environmental factors beyond our control. As
upgrade of software and hardware progresses, there may be changes to
specifications. AZiO is not responsible for informing of these changes in advance.
If you would like to know more about our product information, please visit our
website at www.aziocorp.com.

Welcome

Thank you for purchasing the AZIO KB531RM wireless USB keyboard & mouse .
The KB531RM utilizes 2.4GHz RF wireless technology in a slim, contemporary
design. The keyboard features built-in multimedia hotkey functions, and has
wireless RF working range of 30ft from the receiver. The mouse features a
sensitivity adjustment button “A” that the user can press to change mouse
sensitivity from 800 DPI to 1600 DPI.

Keyboard Features

 2.4GHz ISM b and radio frequ ency
 32 channels auto switching channels in 2.402GHz ~2.480GHz range.

 65536 possible unique identifiers
 Operating distance up to 30ft (10 meters)
 Advanced power saving management
 4 multimedia hotkeys
 Compatible with Windows 2000/XP/Vista/Win 7
 FCC,CE, R&TTE approved

Mouse and Receiver Features

 USB Nano receiver can be stored inside battery compartment
 2.4GHz, operating distance up to 30 ft
 Wireless carrier frequency: 2,402MHz-2,480 MHz
 64 wireless working channels, automatic frequency hopping.
 Power ON/OFF Switch.
 Low-voltage alarm fu nction
 Resolution: 800DPI and 1600DPI adjustable
 Scrolling wheel
 DPI-adjusting key

Establishing the communication link

Connect the receiver to a USB port of the computer. Ensure the batteries are
properly oriented and then turn on the mouse. Press the connect button at the
bottom of keyboard to establish a link.

Sleep Mode

To save power consumption, this keyboard will enter into sleep mode
automatically after two minutes if left unused. Press any key on the keyboard and
move the mouse to bring it back from sleep.

CE and FCC Approved

This device complies with the part 15 of th e FCC rules. O peration is subjec t to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
