Recent Locations 16

Travelling To Options 16

Favorite Locations 16

Saving a Location 17
Travelling to a Favorite Location 17
Creating Groups for Favorite Locations 18
Travelling To Options 18

Map Display 27
Map Selection 29

2. Settings 30

Configuration Wizard 30
POI Display 31
Voice Prompts 31
Units of Measure 33
Language 33
Time Display 34
QuickNav 34
Look & Feel 35
Demo Route 35
GPS Signal 36

Configuring GPS Settings 36

Help 37

Technical Support 38

810-694-4500 [e-mail] www.azentek.com 38

About 39

Index 40

4. Additional Destinator Features 19

Driving Directions 19

Showing Entire Route and Next Turn Maps 20
Road Type and Route Mode 21
Detours 22

1. Maps 23

Map Icons 24
Travel by Tapping the Map 26
Night Map View 26
Browse Map 27

8

Smart Mirror User’s Guide

Revision 1.1

2010

1. Introduction

Welcome to the world of mobile navigation! Simple operation, clear maps in 2D or 3D mode as well as numerous
innovative features and functions have made Destinator the essential guide for every traveler - whether in the car, on
foot or on a bike.

9

Smart Mirror User’s Guide

Revision 1.1

2010

Go – Lets you select a location to travel to

Map – Displays route and map options.

Settings – Lets you choose setting options.

Manage Route – Additional features that determine the route.

2. Menus

Displayed below are Destinator’s main menus.

10

Smart Mirror User’s Guide

Revision 1.1

2010

1. Tap

2. Tap

3. Select an address entry mode:

Town/City First displays cities first and is most commonly-used.

Street First displays the street list and then the cities list.

Intersections or Road Junctions lets you travel to a designated
cross-street location.

Postcode lets you select the postcode, street and address number.

4. Enter City

5. Enter Street

6. Enter Address Number
or Point on the Street

7. Tap Go

3. Creating a Route

Address

Creating a Route

11

Smart Mirror User’s Guide

Revision 1.1

2010

1. Tap Intersections

2. Select city and tap OK

3. Select a street and tap OK

4. Select a cross street
and tap OK

5. Tap Go

Selecting Address Intersection

You can instruct Destinator to create a route to a selected intersection.

Creating a Route

12

Smart Mirror User’s Guide

Revision 1.1

2010

1. Tap In Other Countries

2. Select state and tap OK

Changing State or In Other Countries

You can change from one state to another. The State screen shows the states that are available in the current map.
When using a European map, the Change State button becomes In Other Countries, which lets you create a route to a
location in another country.

Travelling To Options

You can select from the following options:

 Save – Store address to a selected folder.
 Start Point – Designate address as the starting point.
 Demo Route – Run simulated route to selected address.

Creating a Route

13

Smart Mirror User’s Guide

Revision 1.1

2010

1. Tap

2. Tap

3. Tap a Search Around
option (My Current
Location is selected by
default) and the
Category button

4. Tap a category

Search-Around Options:

My Current Location – Search near your current

location.

My Destination – Search near your destination.

Another City – Search in another city.

5. Tap a subcategory

6. Tap the location and OK

7. Tap Go

POI

Points of Interest (POI) are a collection of thousands of interesting or useful places organized into easy-to-find categories
and subcategories.

Searching by POI Categories
