OSO W-D
Wireless DMX transmitter / receiver kit
User manual
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Introduction
Thank you for purchasing the Ayra OSO W-D. This practical kit, consisting of two wireless DMX 'pens' and 2
matching power adapters, is used to transmit DMX signals from a lighting controller or interface to your DMX
enabled lighting fixtures. One of the devices is the transmitting device, the other one is the receiver. This
user manual provides you with all the information you need to get the best out of the features this device has
to offer.
Read this user manual before you set up the device and familiarise yourself with the product and its
accessories. Also check the box contents to make sure the device has not been damaged and all
accessories are included as they should.
If you encounter any problems during unpacking, installation or use, contact your local dealer for more
information and help.
The OSO W-D kit can be extended with the use of one of the OSO DIS-H wireless DMX splitters. This way,
upon arrival of the wireless signals, the signal can be splitted in several isolated outputs. This gives users the
flexibility of making multiple DMX groups, without having to pull cables from and to every fixture.
The OSO W-D makes use of special technology to ensure that the wireless transmitted signal is as strong
and stable as possible. However, the reliability of the system depends on the surrounding environment,
something which can not always be controlled. It is therefore recommended to use cables to connect your
DMX devices where possible and practical, as technically this is always a more stable and reliable solution.
For situations where the use of cables is impossible, dangerous or difficult, the OSO W-D is an useful
problem-solver.
Please note before use:
The OSO W-D works on the 2.4 GHz frequency. This is a global free to use frequency, also used by
equipment such as wireless microphones, Bluetooth speakers, smartphones, tablet computers, microwaves,
WiFi-routers and so on. When used for applications such as large festivals, the OSO W-D will be surrounded
with a lot of devices who make use of the same frequencies.
Thankfully, the OSO W-D is equipped with modern electronics, preventing interference as much as possible.
As the surroundings with every use of this product vary, 100% stable operation of this product can not be
guaranteed in all circumstances.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Safety instructions
This unit must be operated by, or under the supervision of an adult. This device is not suitable for children.
Every person involved with the installation, operation and maintenance of this device has to:
- Be qualified
- Follow the instructions of this manual
- Make sure there is no damage caused by transport. If the device seems damaged from the outside, do not
use it and contact your dealer for more information.
- To make sure the device remains in perfect condition and for safe operation, the user must follow the
instructions and warning notes of this user manual.
- Damage caused by improper use or modifications to the device are not covered by the warranty.
- This device does not have any user-serviceable parts inside. This device must be serviced by qualified
technicians.
Important notes regarding health and safety:
- Never let the power cord come in contact with other cables. Handle the power cord and all mains
connectors with caution.
- Never remove any warning or informative labels from the unit.
- Never leave cables lying around.
- Do not open the device and do not modify any hardware or software.
- Do not connect this device to a dimmer pack.
- Do not switch the system on and off frequently, as this will reduce the lifespan of the device.
- Only use this device indoors, avoid contact with water, moisture and other liquids (apart from fog fluids). Do
not place items filled with liquids on top of the unit.
- Avoid nearby flames or heat sources, do not place this device near flammable liquids, gas or flammable
items.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
WARNING!
Always keep this device away from damp or wet conditions! Hazardous electric shocks may
occur!
WARNING!
Only connect this device to a matching power outlet. This device is intended to work on a
specified AC current. Connecting this device to power outlets with other voltages may result in
permanent damage and/or hazardous situations, like fires or electric shocks!
WARNING!
Be careful with the operation of this device. Touching live wires inside and outside the unit may
cause hazardous electric shocks!
- Always disconnect the device when it is not in use for a longer period or time, when servicing is needed, or
when the device needs cleaning.
- Only handle the power cord by its connectors. Never pull the cable to remove a connector from its socket,
as this could lead to damage and electric shocks.
- Always operate this device with a stable AC current.
- Never use other types of cables other than those specified in the manual, do not use defective or
malfunctioning cables. Contact your dealer if the included or required cables do not work properly with this
device.
- If the device has been exposed to considerable temperature changes (for example, transport from outdoors
to indoors), do not connect the device immediately. Do not activate the unit until it has reached room
temperature as moisture might build up inside the unit, which may cause it to short-circuit and/or cause
electric shocks.
Guidelines and types of use:
- This device is intended to be used by adults for in locations such as community centres, bars, dancing
schools, roller skating rinks, bowling alleys, theatres etc.
- This device is not suitable for use by children and must always be operated by an adult.
- Only use the device when the environment is suitable and will not cause any damage. Do not use the
product in damp or dusty environments, or where long-term damage may occur such as:
- indoor swimming pools where chlorine is used.
- Beaches, where sand and salt are present.
- Outdoors.
- Indoor areas where intense heat sources are present or where the temperature exceeds levels that
are comfortable for humans.
- Use only the included power adapter and only connect the device to a suitable power outlet with the correct
output voltage. Connecting the device to a power outlet with the wrong type of voltage or using the product
with a wrong type of power supply may cause permanent damage to the device.
- Avoid shocks and collisions during use and transport. Do not transport the device while in use. Avoid brute
force during the installation and operation of this device.
- Familiarise yourself with the functions of the device before use. Do not allow operation of the device by
unskilled or unqualified people.
- Use of the device in ways other than described in this user manual may cause damage and injury. Ayra
cannot be held responsible for any damage or injury caused by improper use.
Storage and transport:
- This device is intended for mobile use as well as fixed installations. During transport, use the original
packaging of the product, or a fitting flight case, preferably filled with foam.
- If the device is not used for a longer period of time, disconnect it from its power source and store it in its
original packaging, or in a fitting flight case.
- Store the device in dry conditions indoors, and do not expose the device to extreme temperature changes.
Housing:
- Inspect the housing of the device frequently. Severe dents, cracks and missing screws should be prevented
at all costs. Do not use the device when the housing is not in optimal condition. Contact your dealer or a
skilled technician when in doubt about the state of the device.
- Check the fixture and screws for corrosion. Corrosion should not be present on the fixture. Contact your
dealer or a skilled technician when corrosion is found on the fixture.
- Every power or signal chassis/connector should be mounted tightly. Do not use the device when connectors
are loose.
- Do not use the power adapter if the conductors are visible. The cable can not be replaced by the user and
should only be repaired or replaced by a skilled technician.
- Prevent the build-up of dust and dirt. Clean the exterior of the fixture every month with a dry or damp cloth.
If the device is intensively used, the cleaning frequency must be increased. Disconnect the fixture when it is
going to be serviced.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Symbol clarification:
WEEE: Dispose of this product properly. This product is part of the WEEE directive – the
Waste Electrical and Electronic Equipment directive. The requirements stated in this directive
apply to all manufacturers and producers of electronic equipment in the EU.
Do not dispose of this product together with regular household rubbish. Contact your local
government representative for more information about proper disposal and recycling of
electronic products in your region. By recycling this product properly after use, we can work
together to enjoy these products and also protect our environment from being polluted.
CE: The CE mark indicates that the product complies with applicable European directives and
regulations.
Indoor use only: This device is designed to only be used indoors. The maximum ambient
temperature should not exceed 40 degrees Celsius (104 degrees Fahrenheit)
Contact:
Ayra professional lighting products
Verrijn Stuartweg 18
4462 GE Goes
The Netherlands
Please do not send any products directly to this address. If you wish to return a product for a refund or
repair, please contact your local dealer for an RMA (Return Material Authorisation)
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Box contents
Box contents
1x wireless DMX transmitter
1x wireless DMX receiver
2x wireless antenna
2x power adapter for transmitter or receiver
Unit and accessory inspection
- If the unit is not going to be used for a longer period of time, disconnect it from the power supply and store it
in a dust-free environment.
- Always check the unit for possible damage before use. If you suspect that something is wrong with the unit,
do not connect it to a power source! When you suspect that your unit is broken or damaged, contact your
local dealer or a certified technician to inspect the unit.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Device overview
1. Wireless antenna
2. antenna connector
3. power adapter input
4. transmitter housing
5. receiver housing
6. ID configuration button and LED
7. male 3p XLR connector
8. female 3p XLR connector
9. power adapter
10. power adapter cable
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
1
2
3
4
5
6
7
8
9
10
1
2
3
6
Setting up and using the OSO W-D
OSO W-D mounting
Upon arrival and unpacking, the OSO W-D requires a little bit of assembly before it can be used.
The 2 seperate antennas which are included, can be mounted on the corresponding connector. Twist the
connector clockwise in place until you feel it has been tightened.
The antenna of the OSO W-D can be angled, which can be easier for use in some settings. Please note that
the antennas should point at the same direction (either up or down) for the best signal transfer.
Powering the unit
Connect the power adapter (both are identical) to either the transmitter or receiver and plug the adapter into
a suitable wall outlet. Once power is detected, the units will start up.
The units will both blink when powered up to determine their status.
Common status:
Transmitter status:
- red blinking: sending wireless DMX signal
- red full on: No DMX signal
Receiver status:
- green blinking: receiving wireless DMX signal
- green full on: no wireless signal
The transmitter can be plugged directly into a lighting console or DMX computer interface. The receiver can
be plugged into one of your DMX lighting fixtures. It’s also possible to connect the transmitter somewhere
else in the signal chain, in case you wish to transfer the signal further from a lighting fixture near your setup.
It may be practical to use a standard XLR cable between the wireless DMX transmitter/receiver and the
console or lights to be able to position the devices better. This has no influence on the operation of the
devices.
To ensure a connection between the transmitter and receiver, make sure both devices are set to the same
ID. You can do this by pressing the red button on the unit. When pressing, the unit will go to the next ID and
show the corresponding colour. There are 7 ID’s, each coloured differently by an RGB LED. Once the
desired ID shows up, the device will go back to showing the current status.
Once a connection has been established, the transmitter will blink red, the receiver will blink green. DMX
data can now be transferred from the lighting console to the DMX lighting fixtures.
Stability and reliability when in use
Please note that the OSO W-D works on the global free to use 2.4 GHz band. The system makes use of the
7 ID’s to ensure that up to 7 systems can work together.
However, please be aware that the 2.4 GHz band is also used by lots of other equipment, such as:
- laptops
- smartphones
- Bluetooth enabled devices
- WiFi enabled devices (also routers)
- tablet computers
- microwaves
To prevent signal loss, the OSO W-D continuously seeks for stable signals in 126 different channels in the
2.4 GHz band it operates in.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Next to the various other types of devices working on the same frequency, other influences may have effect
on the signal stability and reliability. Such as:
- walls blocking or decreasing signal strength
- objects or humans blocking or decreasing signal strength
- weather influences on long distance
To prevent this from happening, make sure that the transmitter and receiver are able to ‘see’ each other
properly. This means that when pulling an imaginary straight line or wire from the transmitter antenna to the
receiver antenna, no objects, humans or walls should be able to block this line.
In case your controller or DMX fixture blocks the signal physically and the system is used on a large
distance, an extra XLR cable can be pulled in such a way that the transmitter and receiver establish a better
connection. As the weight of the transmitter and receiver is very limited, these could be mounted to a lighting
stand, truss system or microphone stand with cable velcro strips, zip ties or similar.
In the most ideal situation, the transmitter and receiver could be placed up to 300 meters apart from each
other and still send and receive DMX signals. But in practice, there will always be negative influences which
will decrease signal strength and stability. Some will alter the reliability more than others.
Therefore it is important to think about your setup before setting up the wireless DMX system. When the
application is critical, the distance is quite long, the signal needs to pass lots of objects or audience and lots
of other 2.4 GHz equipment is present between the transmitter and receiver, you might need to reconsider if
this is the best solution.
Even though the best technologies have been used in order to create the OSO W-D, nothing is more reliable
than a cable because it either works or doesn’t. Therefore the OSO W-D is the best solution for applications
where you wish to pull a cable, but where this is not possible because of dangerous situations or impossible
positioning.
As every situation and application of every user is different, Ayra can not ensure problem free operation,
because lots of unpredictable influences may alter the reliability.
Using OSO W-D with DMX controllers
The OSO W-D works with nearly all kinds of DMX controllers, lighting consoles and even USB to DMX
interfaces. It also works with products sending less channels out than the standard 512. This means that also
192-channel, 12-channel or even 6-channel DMX controllers can be used together with the OSO W-D.
Spare parts
This unit has no user-serviceable parts inside. When any damage to components occur, contact your local
dealer or a specialised technician in order to repair or replace the fixture.
Cleaning:
Clean the housing of the fixture frequently with a damp cloth, to remove dust and/or dirt. The machine must
be cooled down, turned off and removed from any power source when doing so.
WARNING: Always disconnect the fixture from your wall outlet or other power supply and let the fixture dry
before reconnecting it. This prevents possible electric shocks.
Check-up
To prevent dangerous situations, make sure your fixture is in optimal condition before using it. Check your
fixture frequently by using the following check list:
- All screws must be mounted tightly.
- Check all screws and metal parts for corrosion. No visible corrosion should be present.
- The exterior of your fixture must be in optimal condition. Check your fixture for dents, cracks or missing
parts.
- The area in which the device will be used or mounted must be in optimal condition. Check this installation
spot for corrosion, cracks, dents and strength.
- Electrical components (connectors and cables) must be in optimal condition. No form of damage (cuts,
exposed wire cores or any other irregularities) should be visible.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
If any visual or mechanical damage is detected, contact your local dealer or a specialised technician. Do not
use a damaged or failing fixture.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Wireless DMX troubleshooting
If you have any problems with your wireless DMX system, consult this troubleshooting section to solve any
difficulties with your product. If this troubleshooting section does not solve your problem, contact your dealer
for more information and help.
This troubleshooting section contains the most frequent problems and is not a complete collection of possible
faults, defects and solutions. The troubleshooting section applies to the Ayra OSO wireless DMX products. It
is possible that not all the described problems, causes and solutions apply to your situation as details may
vary from product to product.
Problem Possible Cause Solution
Transmitter or receiver can not be
turned on
Electrical problem in wall outlet or
splitter box
Check wall outlet or splitter box to
ensure they provide proper voltage
Power adapter not inserted in wall
outlet or splitter box
Plug power adapter into a wall
outlet or splitter box
Power adapter broken Use another power adapter to
make sure the problem is not
present in the unit. If the adapter is
broken, contact your local dealer
and arrange a new one.
Device broken Contact your local dealer or a
skilled technician to have the
device fixed or replaced.
No established connection
between transmitter and receiver
One of both devices is not turned onCheck if the transmitter and
receivers are turned on.
Both devices not set to the same
working ID
Ensure that both the transmitter
and receiver are set to the same
working ID (colour)
No DMX input Ensure the transmitter is
connected to a proper DMX output
on a lighting console or
Lighting fixtures do not respond to
commands
Receiver not properly connected to
lighting fixtures
Ensure the receiver is properly
inserted and/or connected to a
lighting fixture.
Blackout activated on controller Make sure the ‘blackout’ feature
on your DMX console is disabled.
Check polarity settings on DMX
controller
Use a cable to connect your DMX
lighting to your console and check
if the right polarity setting has been
selected.
Flickering lights, devices turning to
blackout or automatic mode or odd
fixture behavior
2.4 GHz stability problem Ensure that the transmitter and
receiver are connected and
positioned in such a way that no
human or object is blocking the
signal path.
Decrease the distance between
the transmitter and receiver
DMX stability problem Apply a DMX terminator
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
(connector with 110 Ohms resistor
between pins 2 and 3) on the DMX
output of the last connected
lighting fixture
DMX wired signal strength
problem
Apply a DMX booster or splitter
directly behind the receiver, or use
the OSO DIS-H wireless DMX
splitters.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Technical specifications
- wireless DMX system consisting of a DMX transmitter and DMX receiver
- compact ‘pen’-shaped design
- antennas included
- power adapters included
- status LED for transmitter and receiver
- operated by a single button to change the operating ID
- 3-pin XLR male/female connectors
- can be directly plugged into your DMX console and DMX lighting
- 2.4 GHz band operation
- 7 user selectable ID’s (7 colours, to be set manually on the transmitter/receiver)
- switches automatically between 126 channels in the 2.4 GHz band
- easy to operate and easy to use
- can be used with DMX controllers, lighting consoles or even USB to DMX interfaces
- also works with devices sending out less than 512 DMX channels
Technical information:
- connection voltage: 100 - 240V AC, 50/60 Hz
- power adapter: 9V DC, 1A max.
- power consumption: 0,5A
- max. amount of DMX-channels: 512 (1 universe)
- frequency band: 2.4 GHz (2400 – 2525 MHz)
- GFSK modulation – 126 channels
- antenna output: 20 dB / 100 mW
- theoretical max. operating distance: 300 meters
- recommended max. operating distance: 30 meters*
- receiver sensitivity: -106 dBm
Included:
- wireless DMX receiver
- wireless DMX transmitter
- 2x antenna
- 2x EU power adapter
*The recommended max. operating distance is an estimated situation where normal and reliable
operation of the system takes place and the following realistic conditions apply:
- the transmitter and receiver are placed in line without objects or humans blocking the shortest
possible signal (drawing an imaginary straight line from the transmitter to the receiver)
- some signal disturbing sources are present nearby, such as phones from your audience,
microphone systems on the same frequency and tablet computers or laptops.
Increasing the distance between transmitter and receiver may still result in a proper working system,
but the chance of signal disturbance will increase and is therefore not recommended for critical
applications where signal drops can not take place. (For example in theatre environments)
Ayra chooses to inform the user about the theoretical max. operating distance as a reference, but
please be aware that similar ideal circumstances will usually never be present during actual and
expected use of the product without signal drops. The recommended operating distance provides the
most optimal signal while still being useful and reliable.
The information and illustrations shown in this user manual are subject to change without notice.
User manual version: 2.0 Creation date + author initials: 27-01-2016 RV Revision date + author initials: 23-07-2016
Loading...
